Related Manuals for Vent-Axia ACH100B
Summary of Contents for Vent-Axia ACH100B
- Page 1 In-Line Centrifugal Duct Fans Installation and Wiring Instructions Stock Ref. N° ACH100B ACH125B ACH150B ACH200B ACH250B ACH315B 220-240V~50Hz PLEASE READ INSTRUCTIONS IN CONJUNCTION WITH THE ILLUSTRATIONS. PLEASE SAVE THESE INSTRUCTIONS...
- Page 2 C. Ensure that the mains supply (Voltage, Frequency, and Phase) complies with the rating label. D. The Fan should only be used in conjunction with the appropriate Vent-Axia products. E. It is recommended that the connection to the fan connecter terminals is made with flexible cable.
- Page 3 WIRING. WARNING: THE FAN AND ANCILLARY CONTROL EQUIPMENT MUST BE ISOLATED FROM THE POWER SUPPLY DURING THE INSTALLATION / OR MAINTENANCE. THE ACH FANS ARE CLASS 1 AND MUST BE EARTHED. 1. Remove terminal box cover and put to one side. 2.
- Page 4 Vent-Axia guarantees its products for two years from date of purchase against faulty material or workmanship. In the event of any part being found to be defective, the product will be repaired, or at the Company’s option replaced, without charge, provided that the product:- •...
