- Page 1 ACOUSTIC TWIN FAN Installation and Wiring Instructions Stock Ref. N° ATQ 100-12C ATQ 200-12C ATQ 400-14C ATQ 125-12C ATQ 250-12C ATQ 500-14C ATQ 150-12C ATQ 315-12LC ATQ 160-12C ATQ 315-14HC 220-240V/1/50Hz READ INSTRUCTIONS IN CONJUNCTION WITH ILLUSTRATIONS READ AND SAVE THESE INSTRUCTIONS...
- Page 2 C. Ensure that the mains supply (Voltage, Frequency and Phase) complies with the rating label. D. The fan should only be used in conjunction with the appropriate Vent-Axia products. E. It is recommended that the connection to the terminal box is made with flexible cable/conduit.
- Page 3 If the fan is handling dust laden air, it is recommended that a filter is installed. 2. All Vent-Axia acoustic fan motors are fitted with sealed for life bearings and do not require lubrication. OVERHEATING PROTECTION The fan motor is fitted with Standard Thermal Overload Protection.
- Page 4 STOCK REFERENCE NUMBERS: ATQ 100-12C, ATQ 125-12C, ATQ 150-12C, ATQ 160-12C, ATQ 200-12C ATQ 250-12C, ATQ 315-12LC, ATQ 315-14HC, ATQ 400-14C. NOTE: The ITC and ITC-DS controller operate by detecting the current flowing to the fan. If it is necessary to switch the fan On/Off for any reason;...
- Page 5 STOCK REFERENCE NUMBERS: ATQ 100-12C, ATQ 125-12C, ATQ 150-12C, ATQ 160-12C, ATQ 200-12C ATQ 250-12C, ATQ 315-12LC, ATQ 315-14HC, ATQ 400-14C. NOTE: The ITC and ITC-DS controller operate by detecting the current flowing to the fan. If it is necessary to switch the fan On/Off for any reason;...
- Page 6 Fig. 4 ATQ ACOUSTIC SINGLE PHASE (WITHOUT TK CONNECTIONS) FAN WIRING DETAILS STOCK REFERENCE NUMBER: ATQ 500-14C. NOTE: The ITC and ITC-DS controller operate by detecting the current flowing to the fan. If it is necessary to switch the fan On/Off for any reason; e.g. fan Off at night, this switch operation must be done via the ITC and ITC-DS controller by making or breaking a contact connected across S1-SG.
- Page 7 Fig. 5 ATQ ACOUSTIC SINGLE PHASE FAN (WITHOUT TK CONNECTIONS) AND 5 STEP AUTO-TRANSFORMER WIRING DETAILS STOCK REFERENCE NUMBER: ATQ 500-14C. NOTE: The ITC and ITC-DS controller operate by detecting the current flowing to the fan. If it is necessary to switch the fan On/ Off for any reason;...
- Page 8 'Guarantee Claim' stating the nature of the fault and providing proof of date and source of purchase. ********************************************************************** As part of the policy of continuous product improvement Vent-Axia reserve the right to alter specifications without notice. Head Office: Fleming Way, Crawley, West Sussex RH10 9YX...
