  • Page 1 Elite SE 110 Dual Fuel FSD Users Guide Installation & Service Instructions U103980-07A...

  • Page 3: Table Of Contents

    Contents Be safe Page 4 Hotplate Burners Page 5 The Griddle Page 6 The Wok cradle Page 7 The Ovens Page 8 The Clock Page 9 Multi-function oven Page 12 The Handygrill Page 13 Oven shelves Page 14 Oven light Page 15 Storage Page 15...

  • Page 4: Be Safe

    Be safe Warning Accessible parts will become hot in use. To avoid burns and scalds children should be kept away. You need clean fresh air - so does your cooker. Burner flames produce exhaust gases, heat and moisture. Make sure that the kitchen is well ventilated: keep natural ventilation holes open or install a powered cooker hood that vents outside.

  • Page 5: Hotplate Burners

    Hotplate Burners The drawing by each knob indicates which burner that knob controls. There is a spark ignition system that works when the knob is pressed in. Each burner also has a special safety device that stops the flow of gas if the flame goes out.

  • Page 6: The Griddle

    The Griddle Preheat the griddle for a maximum of 5 minutes before The griddle fits the centre left pan support, front to back. adding food. Leaving it longer may cause damage. The It is designed for cooking food on directly. Don’t use pans controls can be turned to a lower position simply by of any kind on it.

  • Page 7: The Wok Cradle

    The Wok cradle Make sure the cradle is stable and that the Wok is sitting level in the ring. The Wok cradle is designed to fit a Typhoon Professional 35cm Wok (Part Code 13840S) The cradle will get very hot in use - allow plenty of time This is available from leading retailers.

  • Page 8: The Ovens

    The Ovens During use the appliance becomes hot. Care should be taken to avoid the touching heating elements inside the oven. Before using for the first time, to dispel manufacturing odours turn the ovens to 200°C and run for an hour. To clear the smell make sure the room is well ventilated to the outside air, by opening windows or turning on a cooker hood for example.

  • Page 9: The Clock

    The Clock Use the Adjusting knob to set the time you need. You can use the timer to turn the ovens on and off. The clock must be set to the time of day before the ovens will work. Setting the time of day You can turn the knob back to the ( ) manual setting to keep an eye on the time of day or leave it in the ( ) minute minder position as the time ticks down.
  • Page 10 Clock Special Features - Key Lock Turn the Timer knob to the ) position. When the key lock is activated, the clock can be operated as usual but the ovens are locked and will not come on. This means that your child could select a cook program but the program will not be activated and ovens will not switch on.
  • Page 11 Cooking using the timer and containers away from the sides of the oven, as overbrowning of the food may occur. The timer can be used to turn just one oven or both on and off automatically. The start and stop Cooking high moisture content foods can create a time must be the same for both ovens but different ‘steam burst’...

  • Page 12: Multi-Function Oven

    Multi-function oven Fan oven cooking is particularly suitable for baking on several shelves at one time and is a good ‘all- round’ function. It may be necessary to reduce the The left hand oven of your cooker is Multi-function. temperature by approximately 10°C for recipes It has many varied uses.

  • Page 13: The Handygrill

    Fan Grilling together, using the cooler zone in the lower half of the oven and hotter area to the top. Fanned grilling is carried out with the oven door closed. Browning element The racking on the inside of the Multifunction Oven door (left hand oven) allows you to position the This function uses the element in the top of Handygrill at any of four different levels.

  • Page 14: Oven Shelves

    To fit the Handygrill Pull the shelf forward Line up the ends of the Handygrill rack with a pair of until the back of the shelf holes in the mounting brackets on the oven door. is stopped by the shelf stop bumps in the oven sides.

  • Page 15: Oven Light

    Oven light The oven light comes on as soon as the thermostat is turned on. If one of the oven lights fail, turn off the power supply before you change the bulb. See the ‘Troubleshooting’ section for details on how to change an oven light bulb.

  • Page 16: Multi-Function Oven Cooking Guide

    Multi-function Oven cooking guide Remember - not all functions will be suitable for all food types. The oven control settings and cooking times given are intended to be used only as a guide. Individual tastes may require the temperature to be altered to provide a preferred result.

  • Page 17: Cooking Chart - Conventional And Full Fan Oven Functions

    Cooking chart - Conventional and full Fan oven functions Convection Oven Fan Oven Shelf Position Food Temperature Temperature Approximate Cooking Time FISH 190°C 180°C Fillets 15-20mins. 190°C 180°C Whole 10mins.per 500g + 10mins. 190°C 180°C Steaks according to thickness. ROAST MEATS Beef with bone 160°C 150°C...

  • Page 18: Cleaning Your Cooker

    Cleaning your cooker Essential information Before thorough cleaning isolate the electricity supply. Remember to switch on the electricity supply and reset the clock before using the cooker. Never use paint solvents, washing soda, caustic cleaners, biological powders, bleach, chlorine based bleach cleaners, coarse abrasives or salt. Don’t mix different cleaning products - they may react together with hazardous results.
  • Page 19 Control Panel and Doors Avoid using any abrasive cleaners including cream cleaners, e.g. Cif, on brushed Stainless Steel surfaces. For best results use a liquid detergent e.g. Domestos Multi Surface Cleaner. The control panel and control knobs should only be cleaned with a soft cloth wrung out in clean hot soapy water.
  • Page 20 Cleaning Table Hotplate Part Finish Recommended Cleaning Method Hotplate Top Enamel or Hot soapy water, soft cloth. Any stubborn stains Stainless Steel remove gently with a nylon scourer. Pan Supports, Wok Cradle (some Enamel coated Cif Cream Cleaner- Faberge Lever and a nylon scourer. models only) Cast Iron or Dishwasher.

  • Page 21: Troubleshooting

    Troubleshooting shelf. Check that the door seal is not damaged and that the door catch is adjusted so that the door is held firmly Steam is coming from the oven against the seal. When cooking foods with a high water content (e.g. A dish of water when placed on the shelf should be oven chips) there may be some steam visible at the the same depth all over.

  • Page 22: General Safety Instructions

    General Safety Instructions In the UK: The cooker must be installed by a Gas Safe registered engineer. In the Republic of Ireland: The installation must be carried out by a Competent Person. Taking care to protect your fingers in case the bulb The installation must be in accordance with the should shatter, unscrew the old bulb.
  • Page 23 Take care when touching cooker, to minimize the Take great care when heating fats and oils, as they possibility of burns, always be certain that the will ignite if they get too hot. controls are in the OFF position and that it is cool Use a deep fat thermometer whenever possible to before attempting to clean the cooker.

  • Page 24: Installation

    Installation For LP Gas - BS 5482-1:1994 (when the installation is in a permanent dwelling), BS 5482-2:1977, (when the installation is in a caravan or other non Dear Installer permanent dwelling), or BS 5482-3:1999 , (when Before you start your installation, please complete the installation is in a boat).
  • Page 25 INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Conversion 7. 4mm & 3mm Allen keys 8. Spirit level All models are supplied set for use on group H natural gas. 9. Pencil A conversion kit for LP gas is included with the appliance. 10.
  • Page 26 INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. We recommend a gap of 1110mm between units to allow for moving the cooker. If a flush fit is required, fit the cooker up to the unit at one side then fit the 75mm 75mm 650mm...
  • Page 27 INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Make sure you lower BOTH REAR ROLLERS. There are Lift up the ends of the plastic clips (one each side) to two adjusting nuts, one for each roller, at both the release the catches holding the drawer to the side front bottom corners of the cooker.
  • Page 28 INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Gas Connection Leave the levelling tool in the storage drawer, so that the customer can use it if they wish to move the Must be in accordance with the relevant standards. A cooker.
  • Page 29 INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. After completing the gas connection, check the your electrical supply type (see fig.). Check that the cooker is gas sound with a pressure test. When links are correctly fitted and that the terminal screws checking for gas leaks do not use washing up are tight.
  • Page 30 INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Customer care Check that the oven light is working. Note: The oven light bulb is not included in the Please complete your contact details in the front of guarantee.
  • Page 31 INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. I 2H I 3+ 37mbar 20mbar 29mbar 3.65 A - tap bypass screw Remove the tap bypass screw and replace with the correct screw. See the table for the correct bypass screws.

  • Page 32: Servicing

    SERVICING - WARNING Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished. Servicing To Remove the Hotplate top Disconnect from the electricity supply. When servicing or replacing gas carrying Pull cooker forward to gain access. components disconnect from gas before Remove the control panel see 1.
  • Page 33 SERVICING - WARNING Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished. 12 To Remove an Oven Door Pull the unit forward to access the rear of the cooker. Remove the both cover boxes by removing the fixing Open the oven door.
  • Page 34 SERVICING - WARNING Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished. 16 To Adjust the Oven Door Catch Keeper that secure the inner back to the oven rear. Lift the Open the oven door and slacken the locknut at the removable panel away.
  • Page 35 Remove the element fixings and withdraw element. Replace the element and re-assemble parts in reverse order. Top Element Open the LH oven door and undo the fixings that secure the heat shield. Remove the top element bracket fixings and withdraw element. Replace the element and re-assemble parts in reverse order.

  • Page 36: Circuit Diagram

    Circuit diagram P033458 P028728 The connections shown in the circuit diagram are for single-phase. The ratings are for 230V 50Hz. Code Description Code Description Colour Code Left-hand MF oven thermostat Right-hand fan oven thermostat Blue Left-hand MF oven function control Right-hand fan oven control Brown Right-hand fan oven element...

  • Page 37: Technical Data

    Technical data This cooker is category II2H3+ It is supplied set for group H natural gas. A conversion kit from NG to LP gas is packed with the cooker. INSTALLER: Please leave these instructions with the User. DATA BADGE LOCATION: Cooker back, serial number repeater badge below oven door opening. Country of Destination: GB/IE Electric (Rp ½...
  • Page 40 Clarence Street, Royal Leamington Spa, Warwickshire, CV31 2AD, England. Tel: +44 (0) 1926 457000 Fax: +44 (0) 1926 450526 E-mail: consumers@rangemaster.co.uk w w w.ran gemaster.co. uk...
