Juniper Mesa Rugged Notepad Quick Start Manual

rugged notepad
1
Install screen protector.
3
Place battery pack into the
compartment.
5
Plug charger into Mesa. Follow
on-screen instructions.
© 2015 Juniper Systems, Inc. All rights reserved. Mesa is a trademark of Juniper Systems, Inc.
Quick Start Guide
2
Loosen quarter turn latches to
open battery compartment door.
4
Close battery compartment.
Replace door, tighten latches.
1
2
3
8 9 10
The anatomy of your Mesa Rugged Notepad
1 Stylus and Handstrap
2 Touch Screen
3
Power Button
4 Camera Lens
5 Battery Doors
6 SD Card Slot
7 SIM Card Slot
EN, ES, FR, DE, PT
www.junipersys.com/Juniper-Systems-Rugged-Handheld-Computers/
support/Documentation/Mesa-Rugged-Notepad
11 12 13 14
8 Handstrap Tethers
9 12V DC Jack
10
Mic/Speaker Jack
11 9-pin Serial Port
12 USB Host
13 USB Client
14 Antenna Bumper (Geo Model)
part# 20503-02
4
5
6
7
