9.

Technical specifications idOil-OIL oil sensor

TECHNICAL SPECIFICATIONS idOil-OIL
Operating principle
Enclosure
Weight
Temparature
Supply voltage
Cable
EMC
ATEX and IECEx
Ex classification
Special terms (X)
Exi connection values
See system diagram Appendix A
Manufacturing year:
Please see the serial number on the type
plate.
Conductance
Enclosure class: IP 68
Materials: PVC, AISI 316, PA, CR, NBR
395 g (incl. 5 m cable)
Operation: 0ºC...+60ºC
Environment: -30ºC...+60ºC
7,5...16 V DC
2
2 x 0.75 mm PUR
IEC/EN 61000-6-2
IEC/EN 61000-6-3
EESF 19 ATEX 001X
IECEx EESF 19.0001X
II 1 G Ex ia IIA T5 Ga (idOil-OIL)
II 1 G Ex ia IIB T5 Ga (idOil-OIL-S)
Ta = -30°C...+60°C
Ui = 16 V, Ii = 80 mA, Pi = 400 mW
Ci < 5.2 nF, Li < 1.6 mH
xxxxxxx x xxx xx YY x
where YY = manufacturing year
(e.g. 18 = 2018)
