SPECIFICATIONS ..........................3 RP/4-RP/5 AND RP/6 RAKE ASSEMBLY INSTRUCTIONS ............... 4 ASSEMBLING ............................4 MOUNTING OF RP/4 AND RP/5 RAKE TO TRACTOR ..............7 RP/8-RP/10 AND RP/12 V-RAKE ASSEMBLY INSTRUCTIONS............7 ASSEMBLING ............................8 ON THE FIELD WITH RP/4-RP/5 AND RP/6 ..................9 RAKING..............................10...
OPERATOR'S MANUAL MOUNTED SIDE-DELIVERY RAKES: RP/4-RP/5-RP/6-RP/8-RP/10-RP/12. 1.1 INTRODUCTION This manual includes full instructions for a correct use and maintenance of the machinery, and the recom- mended spare parts list. In order to prevent any possible damage of the machine and/or the operator(s) you are kindly requested to go through this manual for a proper knowledge of the assembly of the implements, their use on the field, and their maintenance.
Here are the advantages 1) Having a R.H. RP/4 rake or a R.H. RP/5 rake or a R.H. RP/6 rake you can convert them into a L.H. RP/4 or L.H. RP/5 or L.H. RP/6 rake by replacing all wheel arms marked RIGHT with those marked LEFT.
OPERATOR'S MANUAL 1.6 RP/4-RP/5 AND RP/6 RAKE ASSEMBLY INSTRUCTIONS To room in the container we supply the partly knocked down. Here be-assembly instructions. For refer to the enclosed breakdown. 1.7 ASSEMBLING 1.7.1 Position the parking stand (15) in its housing and...
Page 7
(53-54-30) (pict. 1.3) 1.7.4 Attach the two central wheels (RP/4) or the three central wheels (RP/5) or the four central wheels (RP/6) to the supplied arm flanges (38-55) and both them with the supplied bolts (pict. 1.4). when bolting the wheels...
Page 8
OPERATOR'S MANUAL 1.7.5 Lift the wheels (x) from the ground until they are in the working position (pict. 1.5). 1.7.6 Unlock the primary structure with the supplied lever (33) and pin (36), turn it by 90 degrees and lock it again with the same pin.
- no 1 L.H RP/4 or RP/5 or RP/6 rake, duly assembled as above. IMPORTANT ! On the R.H. and L.H. RP/4 and RP/5 and RP/6 rakes only the wheel arms and the wheels are specific, all other parts are interchangeable for both rakes. The spe-...
OPERATOR'S MANUAL 2.1 ASSEMBLING 2.1.1 Attach the hitches (4-12) and relevant counterplates (5) to both ends of the main frame (1) - in the position show in picture 2.1 - with bolts (6-7-8) Attach hitches (4-12) to the opposite side of the tractor's hitches weld- ed on the frame (1) (pict.
(11) the split pins (10). Attach the upper hitch (4) to the cap (18) the pin (9) and the split pin (10). IMPORTANT ! For the V-rake transport please refer to the RP/4 and RP/5 and RP/6 rake transport. Picture 2.5 below show the transport position of RP/8 and RP/10 and RP/12 V-rakes.
OPERATOR'S MANUAL 3.1 RAKING (pict. 3.2) Turn the main pipe (37) with the bend to the left. Turn the wheel arms (38) (on RP/5 turn the wheel arm 55 as well) with the bend to the left. 3.2 SPREADING (pict. 3.3) Turn the main pipe (37) with the bend to the left.
RP/8 and RP/10 and RP/12 V-rakes are properly designed for windrowing, as ideal implement to comple- ment the big balers. Slide the RP/4 or RP/5 or RP/6 on the frame (1) to get different working widths. Below (pict. 4.1-4.2) the ideal positioning of the rake for a swath suitable for a 55 pick-up baler.
OPERATOR'S MANUAL FEATURES Our hayrakes are basically made of a primary structure of bent steel pipes, which make the Implement par- ticularly sturdy and flexible. Tines are also very flexible, many are the possible adjustments of the rake, and the implement can work fast and successfully even on slopes or on stony and rough soils. The wheel hubs are made of pressed steel and are equipped with taper roller bearings, protected with a dust cover, so that the wheels can properly turn.
Page 15
OPERATOR'S MANUAL TROUBLES CAUSES REMEDIES 1) Wheel does not unload 1) New tine, too much paint on it. 1) Have the wheels be turning hay. 2) Mud on tine point due to moist on gravelly soil until the tine soil. is clean again.
Page 17
TAB LE P AR T NO 920.255 ITEM Q.ty P AR T NO DES CR IP TION NOTE 200.055 R P /8 F R AM E 200.047 P IN 600.017 S P LIT P IN 200.056 UP P ER LINKAGE 200.057 C OUNTER P LATE 600.001...
Page 19
TABLE P AR T NO 920.254 ITEM Q.ty P ART NO DES CR IP TION NOTE 200.081 R P /10 F R AM E 200.047 P IN 600.017 S P LIT P IN 200.056 UP P ER LINKAGE 200.057 C OUNTER P LATE 600.001 S C REW M 12x140 600.018...
Page 21
TABLE PART NO 920.248 ITEM Q.ty PART NO DESCRIPTION NOTE 200.081 FRAME 200.047 600.017 SPLIT PIN 200.056 UPPER LINKAGE 200.057 COUNTERPLATE 600.001 SCREW M12x140 600.018 SPRING WASHER ø13 DIN 127B 600.008 NUT M12 200.058 600.019 SPLIT PIN 200.059 200.060 LOWER LINKAGE 600.020 SPLIT PIN 200.061...
Page 23
TAB LE P AR T NO 920.146 ITEM Q.ty P AR T NO DES C R IP TION NOTE 210.575 P IP E 600.020 S P LIT P IN 600.075 NUT M 14 DIN 980 200.064 S UP P OR T 200.067 P IN 600.021...
