LIST OF SWITCHES AND COMPONENTS, STAND

Switches

Switch
S1/D801
S1/Object table 1 3-17/2A
S1-1-4/D802
S1-5/D802
S1-S6/D807
S1-S4/D808
S2/Object table 1 3-17/2A
S860
S861
S862
S867
S869
S880
S881
S882
S883
S884
S890
S891
S894
S895
S896
S897
S3
S1
S2
S3
Siemens AG
Medical Solutions
Page Description
3-6/1D Reset switch for stand CPU.
Grid out switch located in the object table 1.
n.a. Current limit switches: 1=+3%, 2=+6%, 3=+12%, 4=+24%.
n.a. Tacho On/Off switch for rotation motor drive.
n.a. Control switches for lamp, lift- and rotation movement. Left and right side.
n.a. Control switches for lift- and rotation movement. Left and right side.
Cassette inserted switch.
3-17/3C Stereo lever switch.
n.a. Compression limit switch, compression unit.
n.a. Decompression limit switch, compression unit.
3-16/3G Filter / mirror disk micro switch.
n.a. Tacho optoswitch
n.a. Emergency stop, switches off 24VAC and 14VAC, machine blocked.
n.a. Lift up limit switch, rotating unit.
n.a. Limit switch, distance tube head - floor <50 mm, switches off 24VAC,
machine blocked.
n.a. Collision protection switch, risk of collision when tubehead is less than
120 mm from the floor.
n.a. Lift down limit switch, rotating unit.
3-17/3C AEC in position switch (Wing 1) (Not used).
3-17/3C Object table locked in position (Wing1).
3-17/4C Select wing 1 switch.
3-17/4C Select wing 2 switch.
n.a. Tilt opto-switch. 0° or ±10
3-16/2G Diaphragm switch.
n.a. Decompression button.
3-17/1A Grid out switch located in object table 2.
3-17/2A Grid front switch located in object table 2.
3-17/2A Grid rear switch located in object table 2.
