PEL-3000H
Assembly Guide
REVISION A JUL 2019
This assembly manual contains proprietary information, which is protected by copyrights.
All rights are reserved. No part of this manual may be photocopied, reproduced or
translated to another language without prior written consent of Good Will company.
The information in this manual was correct at the time of printing. However, Good Will
continues to improve products and reserves the rights to change specification, equipment,
and maintenance procedures at any time without notice.
Good Will Instrument Co., Ltd.
No. 7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan.
ISO-9001 CERTIFIED MANUFACTURER

Advertisement

loading
Need help?

Need help?

Do you have a question about the PEL-3000H Series and is the answer not in the manual?

Questions and answers

Related Manuals for GW Instek PEL-3000H Series

Summary of Contents for GW Instek PEL-3000H Series

  • Page 1 PEL-3000H Assembly Guide REVISION A JUL 2019 This assembly manual contains proprietary information, which is protected by copyrights. All rights are reserved. No part of this manual may be photocopied, reproduced or translated to another language without prior written consent of Good Will company. The information in this manual was correct at the time of printing.
  • Page 3 (Included PEL-005) PEL-009 11EL-00900101 Bus Bar Connector (Included PEL-005) GRA-413-E 01RA413E000T PEL-3111 3U Frame (Optional) GRA-414-E 01RA414E000T PEL-3111 3U Frame (Optional) Note Refer to the PEL-3000H Series Rack Parts details_EN.doc for the other models. Final Assemble Front View Rear View Result...
  • Page 4 PEL-3000H Series Parallel Assembly Guide Rear View with Note Isolated ventilation door Isolated ventilation door It is highly recommended to install the isolated of vent door on the back.
  • Page 5 PEL-3000H Series Parallel Assembly Guide SSEMBLE PROCEDURE Step 1 Put the 1st PEL-3211H on the bottom of the rack followed by fastening the 4 screws for side bracket in the front but not tightening them completely.
  • Page 6 PEL-3000H Series Parallel Assembly Guide Step 2 Screw the L-shape brackets in the interior side of rack. An approx. 1mm distance between the bottom of brackets and the top of PEL-3211H is required. L-shape bracket The L-shape brackets screwed on the interior side of rack Approx.
  • Page 7 PEL-3000H Series Parallel Assembly Guide Step 4 Repeat the previous steps in order to install the rest of PEL-3211Hs and further install the bracket (GRA-414-3) of PEL-3111H on the upper side followed by installing the PEL-3111H onto the top of the bracket.
  • Page 8 PEL-3000H Series Parallel Assembly Guide OPPER TICK SSEMBLY Step 1 Assemble the L-type copper stick (PEL-005) onto the output terminal in the rear side of each unit as the figure below shown. L-type copper stick assembly L-type copper sticks assembly completion...
  • Page 9 PEL-3000H Series Parallel Assembly Guide...
  • Page 10 PEL-3000H Series Parallel Assembly Guide ARALLEL CABLES INSTALLATION Step 1 Install the parallel cables in accord with the following figure. Note The last cable connecting to the last unit cannot be clipped with core. When only one PEL-3111H connects to a PEL-3211H (Booster) in parallel, the cable...
  • Page 11 PEL-3000H Series Parallel Assembly Guide ONNECT TO POWER CORD Step 1 Refer to the figure below; connect the AC power cords for all units to the power sockets in the rear side individually followed by powering on the power switch that is underneath the power socket (─ indicates power ON).
  • Page 12 PEL-3000H Series Parallel Assembly Guide YSTEM IN SERIAL SETTING Step 1 Power on the power switch in the Master front panel and the indicator lights up in green as figure below shown: Step 2 Main Press > Configure[F5] > Next Manu[F4] in the front panel followed by selecting “4”...
  • Page 13 PEL-3000H Series Parallel Assembly Guide Step 3 Properly confirm if the indicator in the front panel of all PEL-3211H (Booster) lights up with LINK in green, which means the software setting connects to Booster appropriately. Refer to the figure below.
  • Page 14 PEL-3000H Series Parallel Assembly Guide URRENT SINK CURRENT DIVISION CHECKUP Description The current sink power of PEL-3111H and PEL-3211H is 1KW:2KW; therefore, the ratio of current sink will always be the exactly 1:2. E.g., PEL-3322H (3KW); when current sink is set 30A, Master (PEL-3111H) will sink current by 10A, whilst Booster (PEL-3211H) will sink current by 20A.
  • Page 15 PEL-3000H Series Parallel Assembly Guide IV. Based on the connection method in the figure below, connect current sink cable to the unit followed by setting current sink value for unit. Measure the currents from both the current sink cable of Master positive pole and the current sink cable of Booster positive pole, via current probe, to validate the accuracy of currents.
  • Page 16 PEL-3000H Series Parallel Assembly Guide Step 3 The 2nd Booster current checkup: I. Connect the parallel cable to the J2 connector in the rear of PEL-3111H in one end and the J1 connector in the rear of PEL-3211H in the other end.
