DC Electronic Load Booster
PEL-3211(H)
QUICK START GUIDE
GW INSTEK PART NO. 82EL-32110ME1
ISO-9001 CERTIFIED MANUFACTURER

Advertisement

loading
Need help?

Need help?

Do you have a question about the PEL-3211 and is the answer not in the manual?

Questions and answers

Related Manuals for GW Instek PEL-3211

Summary of Contents for GW Instek PEL-3211

  • Page 1 DC Electronic Load Booster PEL-3211(H) QUICK START GUIDE GW INSTEK PART NO. 82EL-32110ME1 ISO-9001 CERTIFIED MANUFACTURER...
  • Page 2 This manual contains proprietary information, which is protected by copyright. All rights are reserved. No part of this manual may be photocopied, reproduced or translated to another language without prior written consent of Good Will Corporation. The information in this manual was correct at the time of printing.

  • Page 3: Afety Instructions

    AFETY INSTRUCTIONS This section contains the basic safety symbols that may appear on the accompanying User Manual CD or on the instrument. For detailed safety instructions and precautions, please see the Safety Instructions chapter in the user manual CD. Safety Symbols These safety symbols may appear in the user manual or on the instrument.

  • Page 4: Power Cord For The United Kingdom

    Power Cord for the United Kingdom When using the instrument in the United Kingdom, make sure the power cord meets the following safety instructions. NOTE: This lead/appliance must only be wired by competent persons. WARNING: THIS APPLIANCE MUST BE EARTHED IMPORTANT: The wires in this lead are coloured in accordance with the following code: Green/ Yellow: Earth...

  • Page 5: Etting Started

    The Getting started chapter introduces the instrument's main features, appearance, and set up procedure. Overview The PEL-3211(H) Booster is designed to be used with the PEL-3111(H) Electronic Load for parallel load applications to increase the current sinking capacity. Up to 4 booster packs can be connected as slave units to a PEL-3111(H), which acts as the master unit.
  • Page 6 PEL-3000H series only), monitor out cover x 1(for PEL-3021H, PEL- 3041H, PEL-3111H only) Flexible terminal cover: 2x rubber PEL-013 sheeting, 4x Velcro fasteners.(for PEL-3211(H) only) J1/J2 Protection plug x2 (It is PEL-014 installed on the device) 300mm frame link cable GTL-255...
  • Page 7 Optional Accessories Item Part Number Rack mount bracket for booster GRA-413 PEL-3211(H) (EIA+JIS) Dust filter PEL-010 Front Panel LINK STBY Description 1. Air inlet 2. LINK/STBY indicators Rear Panel Description 1. Frame control ports, J1, J2 2. Rear panel input terminals 3.
  • Page 8 Power Up The PEL-3211(H) has a STBY indicator on the front panel to indicate when the power is on. 1. Insert the AC power cord into the power socket.
  • Page 9 Conduct or Ohms per Max amps for Gauge Diameter mm chassis wiring 0000 11.684 0.16072 10.4038 0.2027 9.26592 0.25551 8.25246 0.32242 7.34822 0.40639 6.54304 0.51266 5.82676 0.64616 5.18922 0.81508 4.62026 1.02762 4.1148 1.29593 3.66522 1.6341 3.2639 2.0605 2.90576 2.59809 2.58826 3.27639 2.30378 4.1328...
  • Page 10 Using the Rear Panel Terminals The rear panel input terminals accept up to M8-sized crimped terminals. The rear terminals come with a load input terminal cover for safety. 1. Turn the power off from the rear panel. 2. Turn the power off from the DUT. 3.
  • Page 11 Using the Terminal Cover (PEL-011) The rear panel terminal cover should be used to prevent electric shock. The rear panel terminal covers should always be used when connecting a load to the rear panel terminals. Ensure the power is off before making Warning any connections to the booster pack.
  • Page 12 Using the Terminal Cover (PEL-013) The rear panel terminal cover should be used to prevent electric shock. The rear panel terminal covers should always be used when connecting a load to the rear panel terminals. The flexible rear panel terminal cover should be used when the load wiring becomes too thick to be used with the PEL-012 terminal cover.
  • Page 13 Connection The PEL-3111(H) can control up to 4 PEL-3211(H) booster units in parallel. Excluding the master unit, other PEL-3000(H) units cannot be used in parallel with the booster packs. Master unit settings for response rate, response speed and so on will be adopted by any connected booster packs.
  • Page 14 Frame Link Connections The J1 and J2 connectors on the rear panel are used to control the booster packs for parallel operation. The GTL-255 frame link cable is used to connect the J1 and J2 connectors. The GTL-255 frame link cable is used for units that are stacked vertically.
  • Page 15 1. Make sure the master unit and booster packs are turned off. 2. Make sure the DUT is turned off. 3. Connect the load units to the DUT.  Ensure the wire gauge is sufficient to handle the increase in current. ...
  • Page 16 3. Connect the sense cables from the DUT to the master unit.  Connect a sense cable from the positive sense terminal to the positive potential of the DUT.  Connect a sense cable from the negative sense terminal to negative potential on the DUT. ...
  • Page 17 PERATION Configuration When using the booster packs all the basic settings are adopted from the master unit. 1. Ensure the master unit, booster packs and DUT are connected in parallel. 2. Turn the booster packs and master unit on. 3. On the master unit, press >...
  • Page 18 Turning the Load On 1. Turn the slave and master units on. 2. Set the operation mode and settings on the master units.  The master's settings will be used by the booster packs. 3. Turn the load on from the Master unit. ...
  • Page 19 PECIFICATIONS Operating Area PEL-3211 Booster Pack PEL-3211H Booster Pack...
  • Page 20 PEL-3211(H) Specifications Rating 0V-150V (0V-800V) Voltage 420A(105A) Current 1.5V at 420A(5V at 105A) Min. Operating Voltage 2100W Power ±(1.2% of set + 1.1% of f.s.) Current Setting Accuracy M range applies to the full scale of H range PEL-3211only has H or M current Note ranges.
  • Page 21 EC Declaration of Conformity(PEL-3211) GOOD WILL INSTRUMENT CO., LTD. No.7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan PEL-3211 satisfies all the technical relations application to the product within the scope of council: Directive: 2014/30/EU; 2014/35/EU; 2011/65/EU; 2012/19/EU The above product is in conformity with the following standards or other normative documents: ◎...
  • Page 22 EC Declaration of Conformity(PEL-3211H) GOOD WILL INSTRUMENT CO., LTD. No.7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan PEL-3211H satisfies all the technical relations application to the product within the scope of council: Directive: 2014/30/EU; 2014/35/EU; 2011/65/EU; 2012/19/EU The above product is in conformity with the following standards or other normative documents: ◎...
