Page 1
OPERATOR’S MANUAL Free-Standing, Floor Model GFS Series Tube Fryers Model GFS35 Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operating and maintenance instructions thoroughly before 1100 Old Honeycutt Road, Fuquay-Varina, NC 27526...
Southbend GFS Series Tube Fryers are intended for commercial use only. Not for household use. Warranty will be void if service work is performed by other than a qualified technician, or if other than genuine Southbend replacement parts are installed Be sure this Operator’s Manual and important papers are given to the proper authority to retain for...
Congratulations! You have purchased one of the finest pieces of heavy-duty commercial cooking equipment on the market. You will find that your new equipment, like all Southbend equipment, has been designed and manufactured to meet the toughest standards in the industry. Each piece of Southbend equipment is carefully engineered and designs are verified through laboratory tests and field installations.
Page 4
PECIFICATIONS PECIFICATIONS Dimensions Model GFS65 Shown Front View Width Depth Model 15.7" 14.2" 31.0" GFS35 (399) (361) (787) 15.7" 14.2" 31.0" GFS45 (399) (361) (787) 19.6" 18.2" 34.3" GFS65 (498) (462) (871) Top View Side View Height 14.7" 47.6" 36.2"...
Page 5
Supply pressure should be greater than 7" W.C. for natural gas or greater than 11" W.C. for propane. One 3/4" NPT male connector located on back (see illustrations on pages 4 and 7). Model Burners Gas Type Natural Main Propane GFS35 Natural Pilot Propane Natural Main Propane GFS45...
NSTALLATION NSTALLATION Installation must conform with local codes, or in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1, Natural Gas Installation Code, CAN/CGA-B149.1, or the Propane Installation Code, CAN/CGA-B149.2, as applicable. These installation procedures must be followed by qualified personnel or warranty will be void. Local codes regarding installation vary greatly from one area to another.
Page 7
NSTALLATION GFS S ERIES RYERS Installation Flue Riser Gas Connection Leg Attachment Pad ’ 1182026 PERATOR ANUAL...
Page 8
NSTALLATION Step 3: Install the Legs (or Casters) and Restraints A set of legs or casters is packed with the fryer. A threaded pad is fastened to the base frame at each corner (see illustration on page 7). Each leg or caster has a similar mating thread. When casters have been ordered, the casters are provided with a Zerk fitting for proper lubrication when required.
Page 9
Step 4: Check Clearances and Ventilation Select a firm, level location for your Southbend fryer. Leave clearance, whenever possible, so that access from the rear is possible to permit cleaning. If the unit is to be set on non-combustible flooring, such as a concrete slab, 3 inches minimum toe room must be provided to prevent restriction of the air opening in the bottom of the unit.
Page 10
A millivoltage circuit diagram is located inside the front door of the fryer. All Southbend equipment is adjusted at the factory; however, pilot height should be checked at installation and adjusted, if necessary (see page 22).
Page 11
NSTALLATION GFS S ERIES RYERS CAUTION IF YOU SMELL GAS DURING THE LIGHTING PROCEDURE, IMMEDIATELY SHUT OFF THE GAS SUPPLY UNTIL THE LEAK HAS BEEN CORRECTED. ’ 1182026 PERATOR ANUAL...
These procedures must be followed by qualified personnel or warranty will be voided. All Southbend GFS Series Tube Fryers are immersion tube fryers. This is the most efficient method of transmitting heat into the oil. The tubes are actually large heat exchangers. Each tube is heated by a burner at its front that propels its flame and heat into the tube, toward the rear, where it is vented into a flue box.
Page 13
2. When the fryer is new, fill the frypot with water and clean thoroughly (see “Weekly Cleaning” on page 18) in order to remove protective coatings and any foreign matter. 3. The recommended solid shortening capacity for the fry pot is 35 pounds for Model GFS35, 45 pounds for Model GFS45, and 65 pounds for Model GFS65.
Page 14
In the event the fryer shuts down due to this condition, the oil must be cooled to below 400 F before the pilot burner can be re-ignited. When the oil has cooled, use the “Lighting” procedure on page 12 to place the fryer back in operation. If the problem persists, contact your Southbend Service Representative or the Southbend Service Department.
Page 15
GFS S ERIES RYERS OOKING INTS User Tips • Smoking oil means that the temperature is too high, or that the oil has broken down. • Gum in frypot denotes a need for thorough cleaning (see “Weekly Cleaning” on page 18) •...
Page 16
Typical Production Potatoes — Raw to Finished — Blanched to Finished Chicken — Raw to Finished — Blanched to Finished Model GFS35 Model GFS45 65-70 lbs. per hour 100-105 lbs. per hour 280-285 lbs. per hour 320-325 lbs. per hour 40-45 lbs.
RYERS LEANING Southbend equipment is constructed with the best quality materials and is designed to provide durable service when properly maintained. To expect the best performance, your equipment must be maintained in good condition and cleaned daily. Naturally, the frequency and extent of cleaning depends on the amount and degree of usage.
Page 18
Semiannual Cleaning 1. Examine and clean the venting system. 2. Have your Southbend Authorized Service Agency or another qualified service technician clean and adjust the unit for maximum performance. Consult the Southbend Authorized Parts/Service Distributor list for the Authorized Service Representative in your area or contact Southbend at 1-800-348-2558.
Page 19
LEANING GFS S ERIES RYERS Darkened areas, called “heat tint,” sometimes appear on stainless steel surfaces where the area has been subjected to excessive heat. These darkened areas are caused by thickening of the protective surface of the stainless steel and are not harmful. Heat tint can normally be removed by the above cleaning techniques, but tint which does not respond to that procedure calls for a vigorous scouring in the direction of the polish lines, using SCOTCH-BRITE scouring pads or a STAINLESS scouring pad in combination with a powered cleanser.
Adjustments and service work may be performed only by a qualified technician who is experienced in, and knowledgeable with, the operation of commercial gas cooking equipment. However, to assure your confidence, contact your Southbend Service Representative (or the Southbend Service Department) for reliable service, dependable advice or other assistance, and for genuine factory parts.
Page 21
GFS S ERIES RYERS Checking and Adjusting Pressure Regulator The combination gas valve and pressure regulator is factory set at 4" W.C. for natural gas and 10" W.C. for propane gas. To check the manifold pressure, do the following: 1. Turn thermostat “OFF” (lowest position) and combination gas valve knob to the “PILOT” setting. 2.
Page 22
The kit comes with five LP gas orifice spuds; Model GFS65 uses all five spuds, model GFS45 uses four, and model GFS35 uses three. In the following procedure, refer to the parts diagram on page 28 for Model GFS35, on page 30 for Model GFS45, or on page 32 for Model GFS65.
GFS S ERIES RYERS Troubleshooting Problem Burners do not come on Pilot will not stay ignited Pilot produces carbon deposits Burners produce carbon deposits NOTE: Vibrations or shock caused by shaking or pounding baskets on top surface or by slamming door may cause Hi-Limit Control Switch to open.
ERVICE Wiring Diagram GAS INLET PILOT PILOT GAS THERMOPILE PILOT ADJUSTMENT CAP COMPONENT LEADS Notes: 1. High limit switch is set to 450 F. 2. Voltage measured across TP/TH and TP with main burner on should be greater than 100 mV. REGULATOR ADJUSTMENT COMBINATION...
For parts not listed, consult a Southbend Authorized Parts Distributor or Southbend Authorized Service Agency. Consult the Southbend Authorized Parts/Service Distributor list for the Authorized Parts supplier in your area. If this list is not available, call Southbend at 1-800-348-2558 to obtain this list. Index of Parts Diagrams...
Page 26
ARTS Cabinet Parts for GFS35 and GFS45 Part Number Description 1-2849 Knob, Door 1182216 Cover Splasher Rear 1182212 Fry Panel 1182209 Splasher Spot Weld 1182205 Door 1182025 Bracket, Bottom Door 1182024 Bracket, Top Door Weld Assembly 1182016 Panel, Inner Door...
Page 27
GFS S ERIES RYERS Cabinet Parts for GFS65 Part Number Description 1-2849 Knob, Door 1182246 Cover Flue Rear 1182228 Door 1182031 Panel Inner Door 1182025 Bracket, Bottom Door 1182024 Bracket, Top Door Weld Assembly 1182008 Fry Panel 1182007 Splasher Weld Assembly 1172650 Leg Pad 1178205...
Page 28
ARTS Gas Train Parts for GFS35 See drawing on following page. Part Number Description P5239-4 Union, Black, 1/2" 1182155 Burner, Fryer, 6 inch 1182154 Thermopile 1182152 Valve, Combination, Natural Gas 1182153 Valve, Combination, LP Gas 1182151 Thermostat, Regulating 1182150 Thermostat, Limiting...
Page 29
GFS S ERIES RYERS Gas Train Parts for GFS35 See parts list on previous page. ’ PERATOR ANUAL 1182026 ARTS...
Page 30
ARTS Gas Train Parts for GFS45 See drawing on following page. Part Number Description P5239-4 Union, Black, 1/2" 1182237 Manifold, 4 Burner 1182155 Burner, Fryer, 6 Inch 1182154 Thermopile 1182152 Valve, Combination, Natural Gas 1182153 Valve, Combination, LP Gas 1182151 Thermostat, Regulating 1182150 Thermostat, Limiting...
Page 31
GFS S ERIES RYERS Gas Train Parts for GFS45 See parts list on previous page. ’ PERATOR ANUAL 1182026 ARTS...
Page 32
ARTS Gas Train Parts for GFS65 See drawing on following page. Part Number Description P5239-4 Union, Black, 1/2" 1182243 Manifold, 5 Burner 1182155 Burner, Fryer, 6 Inch 1182154 Thermopile 1182152 Valve, Combination, Natural Gas 1182153 Valve, Combination, LP Gas 1182151 Thermostat, Regulating 1182150 Thermostat, Limiting...
Page 33
ARTS GFS S ERIES RYERS Gas Train Parts for GFS65 See parts list on previous page. ’ 1182026 PERATOR ANUAL...
Page 34
ARTS Frypot Parts for GFS35 Part Number Description 1182262 Baffle Weld Assembly 1182258 Frypot Weld Assembly 1182238 Valve, Ball, 1-1/4 in 1036618 Thermostat Bulb Clamp 1140700 Screen, Tube Covering P9181 Basket, Single 1176845 Drain Pipe Extension 1176846 Clean Out Rod (optional) * not shown on drawing.
Page 35
GFS S ERIES RYERS Frypot Parts for GFS45 Part Number Description 1182262 Baffle Weld Assembly 1182238 Valve, Ball, 1-1/4 in 1182221 Frypot Weld Assembly 1036618 Thermostat Bulb Clamp 1140700 Screen, Tube Covering P9181 Basket, Single 1176845 Drain Pipe Extension 1176846 Clean Out Rod (optional) * not shown on drawing.
Page 36
ARTS Frypot Parts for GFS65 Part Number Description 1182238 Valve, Ball, 1-1/4 in 1182021 Baffle Weld Assembly 1182005 Frypot Weld Assembly 1036618 Thermostat Bulb Clamp 1140701 Screen, Tube Covering P9183 Basket, Single 1176845 Drain Pipe Extension 1176846 Clean Out Rod (optional) * not shown on drawing.
Page 37
GFS S ERIES RYERS ’ 1182026 PERATOR ANUAL...
Page 38
When service is needed, contact a Southbend Authorized Service Agency, or your dealer. To avoid confusion, always refer to the model number, serial number, and type of your unit.
