Southbend 4FR-45 Operator's Manual

Free-standing, floor model restaurant range fryer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Free-Standing, Floor Model
4FR-45 Restaurant Range Fryer
Improper installation, adjustment, alteration, service or maintenance can cause property damage,
injury or death. Read the installation, operating and maintenance instructions thoroughly before
(800) 348-2558 or (919) 552-9161 FAX (800) 348-2558 or (919) 552-9798
M
1182128
ANUAL
$10.00
OPERATOR'S MANUAL
!
installing or servicing this equipment.
1100 Old Honeycutt Road, Fuquay-Varina, NC 27526
WARNING
4FR-45 RESTAURANT RANGE FRYER
IMPORTANT FOR FUTURE REFERENCE
Please complete this information and retain this
manual for the life of the equipment:
Model #: __________________________
Serial #: __________________________
Date Purchased: ___________________
MANUAL SECTION SR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4FR-45 and is the answer not in the manual?

Questions and answers

Related Manuals for Southbend 4FR-45

Summary of Contents for Southbend 4FR-45

  • Page 1 OPERATOR’S MANUAL Free-Standing, Floor Model 4FR-45 Restaurant Range Fryer Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operating and maintenance instructions thoroughly before 1100 Old Honeycutt Road, Fuquay-Varina, NC 27526 (800) 348-2558 or (919) 552-9161 FAX (800) 348-2558 or (919) 552-9798...
