Installation & Operations Manual
Including Parts Lists
Manual 1189468 Rev 0 (03/07)
$30..00
Fryer
Model P16-PF45, P20-PF65
IMPORTANT FOR FUTURE REFERENCE
Please complete this information and retain
this manual for the life of the equipment:
Model #: _________________________
Serial #: _________________________
Date Purchased: _________________
P16-PF45 & P20-PF65 Fryer

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P16-PF45 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Southbend P16-PF45

Summary of Contents for Southbend P16-PF45

  • Page 1 Manual 1189468 Rev 0 (03/07) $30..00 Fryer Model P16-PF45, P20-PF65 IMPORTANT FOR FUTURE REFERENCE Please complete this information and retain this manual for the life of the equipment: Model #: _________________________ Serial #: _________________________ Date Purchased: _________________ P16-PF45 & P20-PF65 Fryer...
  • Page 2 THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE DO NOT store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other appliance. Improper installation, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment.

  • Page 3: Checking Your New Fryer

    CHECKING YOUR NEW FRYER Your new fryer has been carefully packed into one crate. Every effort has been made to ensure that your fryer is delivered to you in perfect condition. As you unpack your new fryer, inspect each of the pieces for damage. If something is damaged, DO NOT sign the bill of lading.

  • Page 4: Electrical Connection

    Quick Disconnect Gas Connection Gas fryers equipped with casters must be installed with connectors that comply with the Standard for Connectors for Movable Gas Appliances, ANSI Z223.1 Latest Edition, and Addenda Z21.69A Latest Edition. This connection should include a quick disconnect device that complies with the Standard for Quick Disconnect Devices for Use With Gas Fuel , ANSI Z223.1 Latest...

  • Page 5: Lighting Instructions

    LIGHTING INSTRUCTIONS a. Fill kettle before lighting. b. Turn combination gas valve knob to “PILOT” position. c. Depress valve knob and light pilot. With pilot burning, hold knob depressed for 60 seconds. d. Release knob, pilot should remain lit. e. DO NOT TURN COMBINATION GAS VALVE KNOB TO THE “ON” POSITION UNTIL VESSEL IS FULL OF WATER OR SHORTENING.

  • Page 6: Thermostat Calibration

    Turn the fryer gas valve knob to the “ON” position. Allow the fryer to bring the water to a low boil and add one packet of fryer cleaner or a mild, low sudsing detergent and allow water to continue to boil for a minute, making sure water does not boil over.
  • Page 7 Filling the Fryer With Solid Shortening a. Make sure the drain valve is completely closed. b. Remove the screen covering the tubes. c. Cut the shortening into cubes no larger than 1". ALWAYS pack the shortening below, between, and on top of the burner tubes.
  • Page 8 TOPIC EXHAUST HOODS POWER VENTILATORS FILTER UNIT TYPES OF FIRE EXTINGUISHERS AND DETECTION EQUIPMENT DRY CHEMICAL WATER FOAM SPRINKLERS SMOKE DETECTORS FIRE DETECTION THERMOSTATS IF MAINTENANCE IS REQUIRED, CONTACT YOUR LOCAL FACTORY SERVICER, LOCAL FACTORY EPRESENTATIVE, OR THE FACTORY TO OBTAIN SERVICE. Page 8 Installation &...

  • Page 9: Filter Procedures

    The fryer is now ready for use. DRAINING A TANK The filter system is also used to drain the fryers. You will need a container capable of holding 400°F oil and protective gloves.

  • Page 10: Filter Media Replacement

    The power supply must be disconnected before servicing or cleaning the appliance. FILTER MEDIA REPLACEMENT The filter module stores neatly under the fryer when not in use. The unit is very easy to use and allows for quick installation and filtration, even under the busiest conditions.

  • Page 11: Parts Lists

    Parts Lists Installation & Operations Manual 1189468 Rev 0 (03/07) Page 11...
  • Page 12 Item Part# A1406702 Clamp High Limit/Thermostat Screw 10-24 x 5/8 Pan Head SST Thred Forming 1188545 P16-PF45 36" Deeo Flue Front 1188546 P16-PF45 36" Deep Flue Rear 1188556 P16-PF45 42" Deep Flue Front 1188557 P16-PF45 42" Deep Flue Rear 1188585 P20-PF65 36"...
  • Page 13 Tank Assembly and Thermostat Installation & Operations Manual 1189468 Rev 0 (03/07) Page 13...
  • Page 14 Item Part# B8039101 Burner Manifold Weldment P16-PF45 B8029801 Burner Manifold Weldment P20-PF65 60127501 Fitting Adaptor Flared 15/16-16 UN-2A x 1/2" FNPT BRASS Plug 1/8" NPT 3/16" Hex Socket Steel P6071353 Orifice Tip, #53 - LP P6071341 Orifice Tip, #41 - NAT...

  • Page 15: Burner Assembly

    Burner Assembly Installation & Operations Manual 1189468 Rev 0 (03/07) Page 15...
  • Page 16 Item Part# 60128015 Tubing, Flexible With Fittings, 22 Gas 60128101 Valve, Gas Supply, Shut-Off 60127401 Fitting, Elbow Male Flare X MPT 60127601 Fitting, Adapter Female Swivel X 1/2 MPT 60126502 Conversion Kit, NAT to LP VR820 60126501 Conversion Kit LP to NAT VR820 60125201-C Millivolt Gas Valve, VS820 NAT 60125202-C Millivolt Gas Valve, VS820 LP 60119001...

  • Page 17: Gas Valve Assembly

    Gas Valve Assembly Installation & Operations Manual 1189468 Rev 0 (03/07) Page 17...

  • Page 18: Filter Pump Assembly

    Item Part# 60132201 Teflon Hose 3/4" NPT Female Swivel x 3/4 MPT B6677001 Filter Inlet Coupling 60131307 Nipple 3/4 NPT x 12 Black Iron A7029201-C Filter Pump Mounting PLate 60143501 Pump Assembly 8GPM .3hp 115/230V (50/60hz) 60143503 Pump Assembly 8GPM .3hp 208/240V (50/60hz) 60143505 Pump Motor Only 8GPM .3hp 115/230V (50/60hz) 60143506...
  • Page 19 Filter Pump AssemblyTank Assembly and Thermostat Installation & Operations Manual 1189468 Rev 0 (03/07) Page 19...
  • Page 20 Item Part# A7028701-C Filter Pump Box Housing B6748701 Filter Pump Box Wiring 60148401 Power Inlet/Outler IEC-320 Nut 10-24 (KEP) PP11058 Relay SPST 30A 24VAC (115V) 60104701 Relay DPST 30A 24VAC (208/220/240V) Screw 10-24 x 3/8 60130301 Transformer 5VA 120V 60130302 Transformer 5VA 240V 30130303 Transformer 5VA 208V...
  • Page 21 Filter Pump Contol Box Installation & Operations Manual 1189468 Rev 0 (03/07) Page 21...
  • Page 22 Item Part# P6674401 Filter Drain Line Spout - P16-PF45 P6674001 Filter Drain Line Spout - P20-PF65 B6671401 Filter Drain Fixed Elbow B6675801 Filter Drain Tee PP10177 Vinyl Screw Protection Cap 60127702 Quick Release Band Clamp A7022401 Drain Line Tube PF65 - PF65...
  • Page 23 Drain Line and Filter Pan Installation & Operations Manual 1189468 Rev 0 (03/07) Page 23...
  • Page 24 Item Part# B2101501-C Tank Cover - P16-PF45 B2101502-C Tank Cover - P20-PF65 1186915 Basket Hanger - P16-PF45 - 36" Deep Flue 1188591 Basket Hanger - P20-PF65 - 36" Deep Flue 1189464 Basket Hanger - P16-PF45 - 42" Deep Flue 1189465 Basket Hanger - P20-PF65 - 42"...
  • Page 25 Accessories Installation & Operations Manual 1189468 Rev 0 (03/07) Page 25...
  • Page 26 NOTES Page 26 Installation & Operations Manual 1189468 Rev 0 (03/07)
  • Page 27 NOTES Installation & Operations Manual 1189468 Rev 0 (03/07) Page 27...
  • Page 28 When service is needed, contact a Southbend Authorized Service Agency, or your dealer. To avoid confusion, always refer to the model number, serial number, and type of your appliance.
