Southbend 45lb Specification Sheet

Standard Features

- Standard (2) years limited parts and labor warranty (reference
http://www.southbendnc.com/#SBvservice.html for limited
warranty details).
- Available in 45lb and 65lb capacity
- 9" front rail to match Sectional Range
- Stainless steel tank and cabinet
- Two twin plated, mesh fry basket with plastic coated, heat
resistant handles
- Quick recovery is provided to eliminate waiting between loads
- Wide spacing tube frypot -allows more heat to be transferred to
oil and easy cleaning
- 1-1/4" full port drain valve helps eliminate clogging
- Large cold zone captures food particles, reduces flavor transfer
and extends oil life
- Single unit combination gas shut-off, pressure regulator
and pilot ignition system
- 6" adjustable legs front, 6" fixed casters rear
- 1-1/4" front manifold with 1" rear gas connection for P16PF-45
- 1-1/4" front manifold with 3/4" rear gas connection for P20-PF65
- 100% safety shut off
- Adjustable legs in front and rigid caster in rear
New Pitco Solstice burner/baffle design:
- Increases cooking production.
- Lowers flue temperature.
- Improves working environment.
- Generates more production per BTU.
* 24" MINIMUM FLUE RISER REQUIRED *
Exterior Finish: Stainless steel front.
Frypot: 16-gauge, type 430 #3 Welded tank
with an extra smooth peened finish ensures easy
cleaning. Long-lasting, high-temperature alloy
stainless steel heat baffles are mounted in the heat
exchanger tubes to provide maximum heating and
combustion efficiency. Front access, quick opening
1-1/4" drain valve.
Gas Control System: Includes manual shut-off,
100% safety shut-off pilot gas filter, pilot adjustment
and 200° to 400° adjustable thermostat. High limit
control automatically shuts down main burner and
pilot if oil temperature exceeds 475°F.
Form PSF Rev 6 (September/2011)

Standard COnStrUCtIOn SPECIFICatIOnS

Optional Oil Filtration: Simple two-step operation:
1. Blue handle valve is opened to drain oil into filter pan.
2. Red handle valve is opened to return oil from filter to fryer.
- Self-aligning filter piping makes it easy to assemble and
disassemble.
- Larger 3" (7.6 cm) drain line allows for faster draining
without clogging.
- Light-weight, removable filter pickup assembly, with built-in
handle, for fast media cleaning under busy conditions.
- High flow pump and large return lines produce faster oil
refill times.
- Large filter media collects more debris, which extends time
between changes.
www.yatesgd.com www.yatesgraphicdesign.com
S
ectional
16" 45lb and 20" 65lb Sectional Fryer
45 lb Sectional Fryer 65 lb Sectional Fryer
P16-PF45
by
(shown with 36" high flue riser)
D F
eep ryer
P20-PF65
