Toslon X-Pilot Quick Start Manual page 6

3.1 X-Pilot Setting
Wiring Test
NOTE: before making the test, please check [Boat Option] in Chapter 3.2 and
choose the relative boat option according to the type of your boat.
After you finished all the connections between X-Pilot and your boat, please use the [Wiring
Test] to test the motor (or rudder) to sure the sytem could control the boat properly.
Go Forward: test if the boat can go forward correctly
Turn Left: test if the boat can turn left correctly.
Turn Right: test if the boat can turn right correctly .
NOTE: after one test option was confirmed with [Enter]
key, a message-box will appear:
NOTE: if you find the motor (or rudder) does
not run at the correct way, please enter
[Advanced Set.] / [CH Reverse] menu to
reverse the relative channel.
RF Channel
When more than one user operate the X-Pilot at the same time, it is necessary to choose a
different channel for each user to avoid the possible radio interferance.
Steering sens.
Used to set the sensitivity of boat to keep it steering in a straight way when using with the device.
If boat is light and flexible, sent the senvivity in a low value. Otherwise, set it in a higher value.
Compass Cali.
Used to make the calibration of compass. After install X-Pilot to a new boat or move to
an new enviroment, strongly recommend to re-calibarate the compass.
NOTE: DO NOT calibirate the compass in a house or car!
Compass Test
Used to check if compass working normal or not
Ready to Test ...
X-Pilot Setting
Wiring Test
RF Channel
Steering sens.
Compass Cali.
Compass Test
Wiring Test
Go Forward
Turn Left
Turn Right
