Toslon X-Pilot Quick Start Manual page 4

2.2 Start Autopilot & Back to Home
NOTE: after connecting the X-Pilot to the boat, please refer the [Wiring Test] in
charpter 3.1 and confirm the wiring before start autopilot model.
1) set a HOME point, which is generally the point where you start the autopilot
1) Push the [Down] key, then appears an
message-box to confirm if you would like to set
the current location as HOME point.
2) Select [Yes] to confirm.
2) load an prestored target point to start the autopilot
1) Push the [Autopilot] key, the cursor would
blink and point to the target.
2) Move the [Up ] / [Down] key to select an
Quick Reach Target then push [Autopilot] or
[Enter] key to confirm the selction. An
message-box appears to remind if you will start
the autopilot.
3) Select [Yes] to start the autopilot.
Messages
From: 0° 0.0000' / 0° 0.0000'
To: 32° 15.7354' / 118° 42.0948'
Distance is 224.6m
Start Autopilot?
Yes
NOTE: during the autopilot, push & pull the joystick of your remote to MAX / MIN
position could stop the autopilot mode.
3) back to Home
After the boat arrived the target, autopilot will be finished automaticly. Then
you could choose guiding the boat back to HOME point.
Like the operation in step 2, please chose Home
as the target and start the autopilot. The boat will
run back to the HOME accordingly.
No
Messages
SET AS HOME?
Yes No
H 0427-161201
2 0615-161004
3 0930-160842
4 XXXX - XXXX
5 XXXX - XXXX
Home
Home
