Summary of Contents for Toslon TF520
-
Page 2: Check The Content
Check the content Monitor Transducer (Optional) (Optional) 1) Transducer 2) Knobs 3) Rubber Note: the rubber is different according to different bait boats SonarBox 1) SonarBox 520W 2) Power cable (DC5.5-2.1) positive electrode negative electrode 3) Transducer adapter connector 4) Antenna for monitor 5) Antenna for SonarBox 6) SMA radio cable 7) Valcro... -
Page 3: Installation
Installation (transducer) 1) For general boats, like Carp Madness, Anatec Monocoque, you need to drill a hole on the boat bottom to fix the transducer. 2) For boats of Carplounge/- Waveruner/ Vegaboat/Carpboat etc, there is a transducer groove on the bottom. So, you only need to simply match the transducer to the boat... - Page 4 Installation (antenna & wiring) Antenna Installation 1) Drill an hole (5mm diameter) antenna for SonarBox SMA radio cable on the selected position. 2) Install the SMA cable in the hole and lock the nut of SMA connector with washer. 3) Screw the antenna on boat. Wiring After all the installation are finished, please connect the...
- Page 5 Powering For Monitor For SonarBox 9 ~15V 9 ~12V Recomended voltage Absolute Maximum voltage 16.0V 14.8V Note: overvoltage may burn the elements in the device! From bellow shows the voltage range of the most popular batteries in the market: Battery Type Voltage Permission 12V Lead-acid...
-
Page 6: Using Instruction
Using Instruction 1. Please do not put the display on ground during the operation, which could cause a short R/C distance. It is recommended to install the monitor on a tripod, which can ensure that the monitor is at least 1.2 meters above the ground. -
Page 7: Key Function
Key function Menu Open Menu settings; Switch between menus Finalizes menu selections; confirm a setting Up arrow Move up to select menu; increase a value of option Down arrow Move down to select menu; decrease a value of option Power & Exit Turns unit on/off. -
Page 8: What's On The Display
What’s on the display Upper depth range Depth readout Water temp. Voltage of bait boat Fish-arc Fish symbol Real-time echo window Bottom Structure Voltage of monitor Lower depth range signal indicator... -
Page 9: Menu Operation
Menu Operation In most time the default setting is enough. However in some situation, to achieve the best performance of the system, you need adjusting the menu setting. 1. Sensivity Determines how echoes will be displayed on the screen. Increasing the sensitivity will make you see more details on the screen. - Page 10 Menu Operation 3. Fish ID Sens. Fish ID. Sens. adjust the threshold of fish size display. Selecting a higher setting allows weak returns being being displayed as fish, which is helpful especially when you are intending to find smaller fish species or bait fish. Selecting a low setting will prevent weak sonar returns being displayed as fish, which will be very helpful when you are seeking large species of fish.
- Page 11 Menu Operation 5. Radio Bind For the TF520, each SonarBox has an "Identity Card". It only can be connected with one monitor. And for all the TF520 we sold, the autorization process has been done in advance by our factory.
- Page 12 Menu List Sensivity Controls the level of details shown on the display. Surface Clarify Reduces surface clutter by decreasing the sensivity of the receiver near the surface. Adjust the threshold of fish size display. Higher setting allows weak returns being Fish ID.
-
Page 13: Specifications And Features
Stable wireless performance even in bad condition Full two-year warranty; extended warranties avaiable *Note: [1] Not available with TF520 version B, which with a power-adjustable radio system. [2] For version B, please ensure the TX power compliant with local radio regulations before increasing the radio power.
