Network Setting
http://<the Monitor's IP address>/index.html
HINT:
The default IP address is assigned automatically to the monitor.
The exclusive application can be downloaded from our website.
NOTE
If the MONITOR NETWORK SETTINGS screen does not appear
:
in the web browser, press the Ctrl+F5 keys to refresh your web
browser (or clear the cache).
If the monitor appears to be slow in response to commands or
clicks on buttons in the browser, or the general speed of operation
is unacceptable, this may be due to network traffic or the settings
on your network. Should this happen, consult your network
administrator.
The monitor may not respond if the buttons shown on the browser
are repeatedly pressed in rapid intervals. Should this happen, wait
a moment and repeat. If you still can't get a response, turn the
monitor off and then back on.
To control a monitor please use the control command. See "Control
command diagram".
Preparation Before Use
Connect the monitor to the network, using a commercially available LAN
cable, before attempting to use browser operations.
Operation with a browser that uses a proxy server may not be possible
depending on the type of proxy server and the setting method.
Although the type of proxy server will be a factor, it is possible that items
that have been set will not be shown, depending on the effectiveness of
the cache, and the contents set from the browser may not be reflected in
operation. It is recommended that a proxy server is not used unless the
network environment requires it.
Handling of the Address for Operation via a Browser
A host name can be used in the following cases (corresponding to the IP
address of the monitor):The host name must be registered in the domain
name server (DNS) by the network administrator. You can then access the
network settings of the monitor via this registered host name by using a
compatible browser.If the host name has been configured in the "HOSTS" file
of the computer being used, you can then access the network settings of the
monitor via this host name by using a compatible browser.
Example 1: When the host name of the monitor has been set to "pd.nec.
co.jp", access is gained to the network setting by specifying
http://pd.nec.co.jp/index.html for the address or the entry column
of the URL.
Example 2: When the IP address of the monitor is "192.168.73.1", access is
gained to the mail alert settings by specifying
http://192.168.73.1/index.html for the address or the entry column
of the URL.
English-57
