8-Port Gigabit Ethernet
10" rack-mount Switch
Manual
DN-80114
Introduction
The DN-80114 is a compact Ethernet desktop switch that provides wire-speed, a
Gigabit Ethernet switching function which allows high-performance, low-cost
connections to 10M/100M/1000Mbps Ethernet network. The Ethernet Switch
delivers all the advantages of a switching hub in a compact desktop size and is ideal
for small office or SOHO network users. This switch provides 8 auto-sensing
10/100/1000Mbps Ethernet RJ-45 ports, which automatically detect the speed of the
devices that you plug into them. This switching function allows Full/Half-duplex
devices to communicate on the same network without having to replace any
infrastructure. This flexible feature allows your network a timely, economical
migration to DIGITUS network switch.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Digitus professional DN-80114
Summary of Contents for Digitus professional DN-80114
- Page 1 Manual DN-80114 Introduction The DN-80114 is a compact Ethernet desktop switch that provides wire-speed, a Gigabit Ethernet switching function which allows high-performance, low-cost connections to 10M/100M/1000Mbps Ethernet network. The Ethernet Switch delivers all the advantages of a switching hub in a compact desktop size and is ideal for small office or SOHO network users.
- Page 2 AC power cord IMPORTANT: If any piece is missing or damaged, please contact your local dealer or reseller for service. Product Specifications DN-80114 (8-Port 10/100/1000 Base-TX Gigabit Ethernet Switch) Ports: 8-Port 10/100/1000Base-TX MAC Address: 8K Mac address table LED Indicator:...
- Page 3 Hardware Description The Front Panel The front panel consists of LED Indications. LED Indicators Per Device: Power Per Port: LINK/ACT (Link/Activity) Figure 1. Front panel view Status Color Description Power Green The switch is supplied with suitable power. LINK/ACT The port is not linked successfully with the device. Figure 2.
- Page 4 Troubleshooting The Switch can be easily monitored through panel indicators to assist in identifying problems. This section describes common problems you may encounter and possible solutions. Power If the power indicator does not light when the power cord is plugged in, you may have a problem with the power outlet or cord.
