PREVIOUS REFERENCE NO. IM-P133-74
XXXXXXX/X
IM-P167-16-EN-ISS1
CMGT
M10HPi ISO Ball Valve
Screwed, SW and BW versions
Installation and Maintenance Instructions
1. Safety information
2. General product information
3. Installation
4. Commissioning
5. Operation
6. Maintenance
7. Spare parts
© Copyright 2018
1
IM-P167-16-EN-ISS1 CMGT
Printed in GB
Advertisement
Table of Contents
Related Manuals for Spirax Sarco M10HPi ISO Series
Summary of Contents for Spirax Sarco M10HPi ISO Series
- Page 1 PREVIOUS REFERENCE NO. IM-P133-74 XXXXXXX/X IM-P167-16-EN-ISS1 CMGT M10HPi ISO Ball Valve Screwed, SW and BW versions Installation and Maintenance Instructions 1. Safety information 2. General product information 3. Installation 4. Commissioning 5. Operation 6. Maintenance 7. Spare parts © Copyright 2018 IM-P167-16-EN-ISS1 CMGT Printed in GB...
-
Page 2: Safety Information
Determine the correct installation situation and direction of fluid flow. iv) Spirax Sarco products are not intended to withstand external stresses that may be induced by any system to which they are fitted. It is the responsibility of the installer to consider these stresses and take adequate precautions to minimise them. -
Page 3: Pressure Systems
1.9 Tools and consumables Before starting work ensure that you have suitable tools and/or consumables available. Use only genuine Spirax Sarco replacement parts. 1.10 Protective clothing Consider whether you and/or others in the vicinity require any protective clothing to protect against the hazards of, for example, chemicals, high/low temperature, radiation, noise, falling objects, and dangers to eyes and face. -
Page 4: Residual Hazards
Customers and stockists are reminded that under EC Health, Safety and Environment Law, when returning products to Spirax Sarco they must provide information on any hazards and the precautions to be taken due to contamination residues or mechanical damage which may present a health, safety or environmental risk. -
Page 5: General Product Information
The integral ISO body mounting allows the valve to be automated without losing seal integrity, as the body does not require disassembly. Manual to remote control may therefore be easily accomplished by the ISO range of Spirax Sarco ball valves. Available types M10HPi2 ISO Zinc plated carbon steel body and caps. -
Page 6: Pressure/Temperature Limits
80 °C @ 210 bar g (176 °F @ 3 046 psi g) Minimum operating temperature -29 °C (-20 °F) Note: For lower operating temperatures consult Spirax Sarco. Maximum differential pressure is limited to the PMO Designed for a maximum cold hydraulic test pressure of: 1.5 x PMO... -
Page 7: Installation
3. Installation Note: Before actioning any installation observe the 'Safety information' in Section 1. Although the valve has great structural integrity, severe misalignment and/or the pulling effect of incorrect pipe length will have a detrimental effect on the valve and must be avoided. Particular attention should be paid to correct pipe alignment such that the inlet pipework and valve are all on the same axis. -
Page 8: Operation
4. Commissioning After installation or maintenance ensure that the system is fully functioning. Carry out tests on any alarms or protective devices. 5. Operation The valve is operated manually by a handle. Special care must be taken to ensure that the movement is made in the correct direction. - Page 9 Table 1 Recommended tightening torques Item no. Part Size (lbf ft) ¼", 3/8", ½" RB ½" FB ¾" RB ¾" FB 1" RB Securing screws 1" FB 1¼" RB 1¼" FB 1½" RB 1½" FB 2" RB ¼", 3/8" RB ½", ¾"...
-
Page 10: Spare Parts
Always order spares by using the description given in the column headed 'Available spares' and state the size and type of ball valve. Example: 1 - Seat, seals, body/cap 'O' ring and seat 'O' ring set for a Spirax Sarco ½" M10HPi2FB ISO ball valve. - Page 11 IM-P167-16-EN-ISS1 CMGT...
- Page 12 IM-P167-16-EN-ISS1 CMGT...
