M15 ISO Ball Valve
1. General
safety information
2. General
product information
3. Installation
4. Commissioning
5. Operation
6. Maintenance
7. Spare parts
© Copyright 2002
IM-P133-41
ST Issue 1
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Spirax Sarco M15 Series
Summary of Contents for Spirax Sarco M15 Series
-
Page 1: Safety Information
BAC 13309 IM-P133-41 ST Issue 1 M15 ISO Ball Valve Screwed, SW, BW and flanged versions Installation and Maintenance Instructions 1. General safety information 2. General product information 3. Installation 4. Commissioning 5. Operation 6. Maintenance 7. Spare parts IM-P133-41 ST Issue 1 Printed in the UK ©... - Page 2 Before attempting any maintenance consider what is or may have been in the pipeline. Ensure that any pressure is isolated and safely vented to atmospheric pressure before attempting to maintain the product, this is easily achieved by fitting Spirax Sarco depressurisation valves type DV (see separate literature for details). Do not assume that the system is depressurised even when a pressure gauge indicates zero.
- Page 3 The integral ISO body mounting allows the valve to be automated without losing seal integrity, as the body does not require disassembly. Manual to remote control may therefore be safely and easily accomplished by the ISO range of Spirax Sarco ball valves. Available types Note: The nomenclature will be followed with either FB (full bore) or RB (reduced bore) i.e.
- Page 4 2.2 Sizes and pipe connections ¼", 2", ½", ¾", 1", 1¼", 1½", 2", (2½" only available with reduced bore). Screwed BSP, BSPT, NPT, SW, BW full bore and reduced bore. DN15 - 50 (DN65 only available with reduced bore). Flanged ANSI 150 and ANSI 300, full bore and reduced bore. Flanged DIN PN40, full bore and reduced bore.
- Page 5 3. Installation Note: Before actioning any installation observe the 'Safety information' in Section 1. Although the valve has great structural integrity, severe misalignment and /or the pulling effect of incorrect pipe length will have a detrimental effect on the valve and must be avoided. Particular attention should be paid to correct pipe alignment such that the inlet pipework and valve are all on the same axis.
-
Page 6: General Information
4. Commissioning After installation or maintenance ensure that the system is fully functioning. Carry out tests on any alarms or protective devices. 5. Operation The valve is operated manually by a handle, or automatically by an actuator. Special care must be taken to ensure that the movement is made in the correct direction. - Page 7 Fig. 4 ¼" - ¾" shown Table 1 Recommended tightening torques Item no. Part Size (lbf ft) ¼", 2", ½" RB ½" FB ¾" RB Securing bolts ¾" FB 1" RB 18.0 Nuts 1" FB 1¼" RB 18.0 1¼" FB 1½" RB 30.0 1½"...
- Page 8 7. Spare parts The spare parts available are shown in heavy outline. Parts drawn in broken line are not supplied as spares. Available spares Ball Seat, seals, 'O' ring and body gasket set 5, 6 and 6A, 7, 14, 15 How to order spares Always order spares by using the description given in the column headed 'Available spares' and state the size and type of ball valve.
