ASSEMBLING THE SERVO:LITE PCB
Micro:bit sold separately
STEP 1: Use a small Phillips screwdriver to screw the five M3 machine
screws through the micro:bit and spacer into the nuts mounted on the PCB.
ZIP LEDs
Servo Connections
On/Off Switch
PCB Mounted Nuts
Spacer
