Code :Move Mini To Move - Kitronik BBC Micro Bit move Mini Mk2 Manual

8

CODE :MOVE MINI TO MOVE

DRIVE IN A STRAIGHT LINE
STEP 1: Create this code.
WHAT THIS MEANS
When button A is pressed, drive full speed forwards. When
button B is pressed, drive full speed backwards.
NOTE: Because the servos are mounted on opposite sides of the :MOVE mini,
one has to turn clockwise (Value 0), and one anti-clockwise (Value 180) to
drive the :MOVE mini in a straight line.
STEP 2:
24
NOTE: If the move mini does not travel
in a straight line then you can adjust the
values to make the servos run at the
same speed. You may also need to re-
adjust the trimmer (see pg.17).
Download Upload
