If you are having issues with the :MOVE mini, try the steps below!
THE SERVOS ARE MISBEHAVING
- Is the orange servo wire at the bottom of the connector?
- Check all connections are secure.
- Are the screws holding the electronics together tight?
- Review your code, are you outputting to the correct pin(s)?
:MOVE MINI WON'T DRIVE IN A STRAIGHT LINE
- You may need to recalibrate your servos (see page 17).
- Review your code, are you outputting the correct values?
ZIP LED ISSUES
- Check all screw connections are tight.
- Review your code, are you outputting to the correct pin?
POWER ISSUES
- Is it switched on?
- Are the batteries flat?
- Check all screw connections are tight.
DRAWING ISSUES
- Try a felt tip pen, these tend to work best.
- Try adding some weight to the top of the pen.
- Try using a rubber band to secure the pen.
If this hasn't solved your issue, visit
kitronik.co.uk/moveminimk2
