7
ATTACHING ELECTRONICS
STEP 2: Clip the Servo:Lite board
under the hooks on the inner side
plates and slide it between the
outer plates.
22
STEP 1: Plug the servo cables back into the
Servo:Lite board. The left servo should plug
into the left-hand side of the board and vice
versa. The cables should be threaded down the
gaps on either side as shown below.
