Johnson Controls METASYS Series Installation Sheet page 8

Zone terminal
Hide thumbs

Advertisement

Attach the base, pulling the telephone jack type cord through the opening
as shown below. Plug the cord into the back of the ZT, and snap the ZT
into position.
ENCMTBAS
Figure 7: Connecting and Mounting the ZT
8 Zone Terminal Installation Sheet
