Mounting the ZT
Behind a Window
Enclosure in the
UPM
The Panel Unit in Poteau, Oklahoma has a bracket available for mounting
the ZT behind a window that allows control equipment to be mounted
behind the ZT, thereby maximizing the use of the UPM. Contact the
Panel Unit for more information.
Johnson Controls Panel Unit wires and configures units, complete with
accessories, to your specifications. The ZTU internal mounting bracket is
also available. Contact:
FAX: (918) 647-4895 (Customer Service)
Figure 10: Bracket for Mounting the ZTU Internally in the UPM
Panel Unit -- Poteau
3100 North Broadway
P.O. Box 1088
Poteau, OK 74953
(918) 647-2195
Bottom View of UPM
ZT
UNT
A LA RM
