Removing a
Mounted ZT
Controls Group
507 E. Michigan Street
P.O. Box 423
Milwaukee, WI 53201
12 Zone Terminal Installation Sheet
Use a large flat-head screwdriver and insert it in the bottom where the ZT
and mounting base come together. Gently pry the ZT out of the mounting
base. As you push the screwdriver in, the ZT slides up and then out.
Figure 11: Removing Mounted ZT
REMOVAL
Issue Date 0495
Printed in U.S.A
