Ingersoll-Rand 5L Maintenance Information
Air drill, screwdriver and angle wrench
Hide thumbs
Also See for 5L:
- Product information (17 pages) ,
- Maintenance information (12 pages) ,
- Product information (17 pages)
Related Manuals for Ingersoll-Rand 5L
Summary of Contents for Ingersoll-Rand 5L
- Page 1 16572620 Edition 1 August 2008 Air Drill, Screwdriver and Angle Wrench 5L and 5RL Maintenance Information Save These Instructions...
- Page 2 Note: When reading the instructions, refer to exploded diagrams in parts Information Manuals when applicable (see under Related Documentation for form numbers). Lubrication Each time a Series 5L or 5RL Angle Drill, Angle Wrench or Angle Work approximately 0.5 cc to 1 cc of Ingersoll Rand No. 67 Grease Screwdriver is disassembled for maintenance and repair or into the Lower Spindle Bearing (119 or 213).
- Page 3 Install the Jacking Nut on the Jacking Bolt near the head of the Bolt. NOTICE Position the Bearing Removal Sleeve on the face of the Angle Head with the large open end toward the Spindle. With the Angle Head This is left-hand thread. nested in the shallow counterbore of the Sleeve, screw the Jacking Bolt into the Spindle through the sleeve.
- Page 4 Rotor Bearing, closed end first, into the bearing recess of the Motor Housing (1) until it is about .050” (1.27 mm) below flush. Inject 0.5 cc of Ingersoll Rand No. 28 Grease into the Bearing. 16572620_ed1...
- Page 5 For H ratio, slide the Rotor Pinion Spacer (33) followed by the 18. Wipe each Vane (21) with a film of Ingersoll Rand No. 10 Oil and Rotor Pinion (32) onto the spline shaft on the Rotor (20).
- Page 6 7. Work 3 cc to 6 cc of the recommended grease into the gear train. 12. Install the Clutch Housing Assembly into the Gear Case 8. Insert the Spindle Assembly into the front end of the Gear Assembly (36), matching the spline of the Clutch Housing with Case (36), making certain the Assembly is seated in the recess in that of the Gear Case.
- Page 7 4. For 7L1A1, 7L1A3, 7L1A4, 7L1B1, 7L1B4, 7L2A4, 5L2D5 or i. Insert the required number of shims, as determined from step 6L2D6 Angle Head, lubricate the Bevel Pinion Thrust (g) into the upper bearing recess of the Angle Head. Bearing (112 or 211) as instructed under LUBRICATION. Install See Dwg.
- Page 8 Place shims between Bevel Gear and marked side of Bearing. Bearing Inserting Sleeve Installation Sleeve Guide Shoulder Stop Correct Bearing Depth (Dwg. TPD787) m. Apply a small drop of Loctite No. 601 to the small outside Pull Bevel Pinion back diameter at the upper end of the Spindle.
-
Page 9: Troubleshooting Guide
Troubleshooting Guide Trouble Probable Cause Solution Loss of Power Low air pressure Check air supply. For top performance, the air pressure must be 90 psig (6.2 bar/620 kPa) at the inlet. Plugged Inlet Bushing Screen or Air Strainer Clean the screen in a clean, suitable, cleaning solution. If the Screen Screen cannot be cleaned, replace it. - Page 10 Notes:...
