The Model 7807R and 7807R–EU Angle Drill is designed to drill holes in metal in close
quarters.
Ingersoll–Rand is not responsible for customer modification of tools for applications
on which Ingersoll–Rand was not consulted.
IMPORTANT SAFETY INFORMATION ENCLOSED.
READ THIS MANUAL BEFORE OPERATING TOOL.
IT IS THE RESPONSIBILITY OF THE EMPLOYER TO PLACE THE INFORMATION
IN THIS MANUAL INTO THE HANDS OF THE OPERATOR.
FAILURE TO OBSERVE THE FOLLOWING WARNINGS COULD RESULT IN INJURY.
PLACING TOOL IN SERVICE
Always operate, inspect and maintain this tool in
accordance with all regulations (local, state,
federal and country), that may apply to hand
held/hand operated pneumatic tools.
For safety, top performance, and maximum
durability of parts, operate this tool at 90 psig
(6.2 bar/620 kPa) maximum air pressure at the
inlet with 3/8" (10 mm) inside diameter air supply
hose.
Always turn off the air supply and disconnect the
air supply hose before installing, removing or
adjusting any accessory on this tool, or before
performing any maintenance on this tool.
Do not use damaged, frayed or deteriorated air
hoses and fittings.
Be sure all hoses and fittings are the correct size
and are tightly secured. See Dwg. TPD905–1 for a
typical piping arrangement.
Always use clean, dry air at 90 psig maximum air
pressure. Dust, corrosive fumes and/or excessive
moisture can ruin the motor of an air tool.
Do not lubricate tools with flammable or volatile
liquids such as kerosene, diesel or jet fuel.
Do not remove any labels. Replace any damaged
label.
The use of other than genuine Ingersoll–Rand replacement parts may result in safety hazards, decreased tool
performance, and increased maintenance, and may invalidate all warranties.
Repairs should be made only by authorized trained personnel. Consult your nearest Ingersoll–Rand Authorized
Servicenter.
Refer All Communications to the Nearest
Ingersoll–Rand Office or Distributor.
Ingersoll–Rand Company 1999
Printed in U.S.A.
INSTRUCTIONS FOR
MODEL 7807R AND 7807R–EU 3/8"
REVERSIBLE ANGLE DRILL
03541448
USING THE TOOL
Always wear eye protection when operating or
performing maintenance on this tool.
Always wear hearing protection when operating
this tool.
Keep hands, loose clothing and long hair away
from rotating end of tool.
Note the position of the reversing lever before
operating the tool so as to be aware of the direction
of rotation when operating the throttle.
Anticipate and be alert for sudden changes in
motion during start up and operation of any power
tool.
Keep body stance balanced and firm. Do not
overreach when operating this tool. High reaction
torques can occur at or below the recommended
air pressure.
Tool shaft may continue to rotate briefly after
throttle is released.
Air powered tools can vibrate in use. Vibration,
repetitive motions or uncomfortable positions may
be harmful to your hands and arms. Stop using
any tool if discomfort, tingling feeling or pain
occurs. Seek medical advice before resuming use.
Use accessories recommended by Ingersoll–Rand.
This tool is not designed for working in explosive
atmospheres.
This tool is not insulated against electric shock.
Form P7228
GB
Edition 5
February, 1999

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7807R and is the answer not in the manual?

Questions and answers

Related Manuals for Ingersoll-Rand 7807R

Summary of Contents for Ingersoll-Rand 7807R

  • Page 1 INSTRUCTIONS FOR MODEL 7807R AND 7807R–EU 3/8” REVERSIBLE ANGLE DRILL The Model 7807R and 7807R–EU Angle Drill is designed to drill holes in metal in close quarters. Ingersoll–Rand is not responsible for customer modification of tools for applications on which Ingersoll–Rand was not consulted.

  • Page 2: Warning Label Identification

    SPECIFICATIONS HSound Level Model Type of Chuck Capacity Free Vibrations Handle Speed dB (A) Level Pressure Power 7807R, lever 3/8” 1,800 92.2 105.2 7807R–EU Tested in accordance with PNEUROP PN9NTC1.2 Tested in accordance to ISO8662–1 at 80% rated free speed...

  • Page 3: Declaration Of Conformity

    (supplier’s name) Swan Lane, Hindley Green, Wigan WN2 4EZ (address) declare under our sole responsibility that the product, Model 7807R–EU Reversible Angle Drill to which this declaration relates, is in compliance with the provisions of 98/37/EC Directives. EN292 ISO8662 PN8NTC1...
  • Page 4 RÉVERSIBLE MODÈLE 7807R ET 7807R–EU NOTE La perceuse d’angle Modèle 7807R et 7807R–EU est destinée au perçage de trous dans des métaux, dans des espaces restreints. Ingersoll–Rand ne peut être tenu responsable de la modification des outils par le client pour les adapter à...

  • Page 5: Mise En Service De L'outil

    HNiveau de son Modèle Type de Poignée Capacité du Vitesse à vide Niveau de mandrin dB (A) vibration Pression Puissance 7807R, Levier 3/8” 1.800 92,2 105,2 7807R–EU Test selon PNEUROP PN8NTC1.2 Testé conformément à ISO8662–1 a 80% vitesse libre nominale...

  • Page 6: Certificat De Conformité

    Swan Lane, Hindley Green, Wigan WN2 4EZ (adresse déclarons sous notre seule responsabilité que le produit: Perceuse d’Angle à 90 Réversible Modèle 7807R–EU objet de ce certificat, est conforme aux prescriptions des Directives: 98/37/CE EN292 ISO8662 PN8NTC1 en observant les normes de principe suivantes:...
  • Page 7 UMSTEUERBARE WINKELBOHRMASCHINE 3/8” DER BAUREIHE 7807R UND 7807R–EU HINWEIS Die Winkelbohrmaschine 7807R und 7807R–EU wird zum Bohren von Metall auf engem Raum eingesetzt. Ingersoll–Rand lehnt jede Haftung für Veränderungen an Werkzeugen ab, die ohne vorherige Rücksprache mit Ingersoll–Rand vorgenommen werden.

  • Page 8: Technische Daten

    Anschließen des Luftschlauches in (5) geben. REGELMÄSSIG ABLASSEN (Zeichn. TPD905–1) TECHNISCHE DATEN HSchallpegel Modell Griffart Spannfutterkapazität Freie Schwingungs- Drehzahl dB (A) intensität Druck Leistung 7807R, Hebel 3/8” 1.800 92,2 105,2 7807R–EU Gemäß PNEUROP PN8NTC1.2 geprüft Gemäß ISO8662–1 bei 80% der freien Nenndrehzahl getestet...
  • Page 9 (Name des Herstellers) Swan Lane, Hindley Green, Wigan WN2 4EZ (Adresse) erklären hiermit, gemäß unserer alleinigen Verantwortung, daß die Geräte: Umsteuerbare Winkelbohrmaschine 3/8” der Baureihe 7807R–EU auf die sich diese Erklärung bezieht, den Richtlinien: 98/37/EG unter Anlehnung an die folgenden Grundnormen...
  • Page 10 TRAPANI REVERSIBILI AD ANGOLO MODELLO 7807R E 7807R–EU DA 3/8” AVVISO Il trapano ad angolo modello 7807R e 7807R–EU è stato progettato per fare dei fori su metallo in spazi ristretti. La Ingersoll–Rand non è responsabile delle modifiche apportate agli attrezzi dai clienti per adattarli ad applicazioni per le quali la Ingersoll–Rand non sia stata interpellata.
  • Page 11 HLivello suono Modello Tipo Capacità del Velocità Livello di d’impugnatura mandrino libera dB (A) vibrazione Pressione Potenza 7807R, Leva 3/8” 1.800 92,2 105,2 7807R–EU Test in conformità con PNEUROP PN8NTC1.2 Collaudato secondo i criteri ISO8662–1 a velocità libera nominale dell’80%...

  • Page 12: Dichiarazione Di Conformità

    Swan Lane, Hindley Green, Wigan WN2 4EZ (indirizzo) dichiariamo sotto la nostra unica responsabilità che il prodotto: Trapani reversibili ad angolo modello 7807R–EU a cui si riferisce la presente dichiarazione è conforme alle normative delle direttive: 98/37/CE EN292 ISO8662 PN8NTC1...
  • Page 13 TALADRO ANGULAR REVERSIBLE DE 3/8 PULG. MODELO 7807R Y 7807R–EU NOTA El taladro angular modelo 7807R y 7807R–EU está diseñado para taladrar agujeros a distancia mínima. Ingersoll–Rand no aceptará responsabilidad alguna por la modificación de las herramientas efectuada por el cliente para las aplicaciones que no hayan sido consultadas con Ingersoll–Rand.

  • Page 14: Etiquetas De Aviso

    Capacidad del Velocidad en Nivel de empuñadura portapuntas vacío dB (A) vibraciones Presión Potencia 7807R, Palanca 3/8 pulg. 1,800 92,2 105,2 7807R–EU Comprobado conforme a la norma PNEUROP PN8NTC1.2 Probado en conformidad con ISO8662–1 80% de la velocidad libre nominal...

  • Page 15: Declaración De Conformidad

    (nombre del proveedor) Swan Lane, Hindley Green, Wigan WN2 4EZ (domicilio) Declaramos que, bajo nuestra responsabilidad exclusiva, el producto: Taladro Angular Reversible Modelo 7807R–EU a los que se refiere la presente declaración, cumplen con todo lo establecido en las directivas: 98/37/CE EN292 ISO8662 PN8NTC1 conforme a los siguientes estándares:...
  • Page 16 TYPE 7807R EN 7807R–EU 3/8” OMKEERBAARE BOORMACHINE MET HAAKSE KOP LET WEL Het Type 7807R en 7807R–EU Omkeerbare Boormachine met Haakse kop is bedoeld voor het boren van gaten in metalen in besloten ruimten. Ingersoll–Rand is niet aansprakelijk voor door de klant aangebrachte veranderingen aan de gereedschappen voor toepassingen waarover met Ingersoll–Rand geen...
  • Page 17 DRUKLUCHT– GEREEDSCHAP REGELMATIG AFTAPPEN (Tekening TPD905–1) SPECIFICATIES HGeluidsniveau Type Soort Hendel Capaciteit Onbelast Trillings– Houder toerental dB (A) niveau Deuk Vermogen 7807R, hefboom 3/8” 1.800 92,2 105,2 7807R–EU Getest overeenkomstig PNEUROP PN8NTC1.2 Getest volgens ISO8662–1 bij 80% nominale vrije snelheid...
  • Page 18 (naam leverancier) Swan Lane, Hindley Green, Wigan WN2 4EZ (adres) verklaren, onder onze uitsluitende aansprakelijkheid, dat het produkt: Type 7807R–EU 3/8” Omkeerbare Boormachine met Haakse Kop waarop deze verklaring betrekking heeft overeenkomt met de bepalingen van directieven: 98/37/EG EN292 ISO8662 PN8NTC1...
  • Page 19 31 Front End Plate ... . . LA411–11 for 7807R ....WARNING –7–99 32 Front Rotor Bearing ..LA411–34 for 7807R–EU .
  • Page 20 Service Centers Centres d’entretien Ingersoll–Rand Niederlassungen Centri di Assistenza Centros de Servicio Service Centra Ingersoll–Rand Nederland Produktieweg 10 2382 PB Zoeterwoude Nederland Tel: (31) 71 452200 Fax: (31) 71 218671 Ingersoll–Rand Company 510 Hester Drive Ingersoll–Rand Company SA White House, TN 37188 PO Box 3720 Alrode 1451 Tel: (615) 672 0321...
  • Page 21 REVERSIBEL 3/8”–VINKELBOREMASKINE, MODEL 7807R OG 7807R–EU BEMÆRK Vinkelboremaskine model 7807R og 7807R–EU er designet til hulboring i metal under trange pladsforhold. Ingersoll–Rand påtager sig intet ansvar for eventuelle ændringer af værktøjer udført af brugeren i forbindelse med anvendelsesområder, som Ingersoll–Rand ikke på forhånd er blevet konsulteret om.
  • Page 22 (Tegning TPD905–1) luftledningssmøring. SPECIFIKATIONER GLydniveau Model Håndtagstype Borepatronskapacitet Fri hastighed Vibrations- dB (A) niveau Tryk Effekt 7807R, Tangentarm 3/8” 1.800 92,2 105,2 7807R–EU G Afprøvet i overensstemmelse med PNEUROP PN8NTC1.2 Afprøvet i overensstemmelse med IS08662–1 ved 80% af dimensioneret, fri hastighed...
  • Page 23 (leverandørens navn) Swan Lane, Hindley Green, Wigan WN2 4EZ (adresse) erklærer som eneansvarlig, at nedenstående produkt, Reversibel 3/8”–vinkelboremaskine, model 7807R–EU som denne erklæring vedrører, overholder bestemmelserne i følgende direktiver, 98/37/EF ved at være i overensstemmelse med følgende hovedstandard(er): EN292 ISO8662 PN8NTC1...
  • Page 24 REVERSIBEL VINKELBORRMASKIN, MODELL 7807R OCH 7807R–EU OBS! Modell 7807R och 7807R–EU, reversibel vinkelborrmaskin, är avsedd för borrning av hål i metall i trånga utrymmen. Ingersoll–Rand är inte ansvarigt för verktyg som har modifierats av kunden för att anpassas till andra användningar, om inte kunden har konsulterat Ingersoll–Rand.
  • Page 25 (Bild TPD905–1) SPECIFIKATIONER HLjudstyrkenivå Modell Typ av Chuck–kapacitet Fri Hastighet Vibrations– handtag dB (A) nivå varv/min. Tryck Kraft 7807R, hävarm 1 800 92,2 105,2 7807R–EU Testad i enlighet med PNEUROP PN8NTC1.2 Testad i enlighet med ISO8662–1 vid 80% beräknad fri hastighet...

  • Page 26: Försäkran Om Överensstämmelse

    Ingersoll–Rand, Co. (leverantörens namn) Swan Lane, Hindley Green, Wigan WN2 4EZ (adress) intygar härmed, i enlighet med vårt fullständiga ansvar, att produkten, Reversibel vinkelborrmaskin, modell 7807R–EU som detta intyg avser, uppfyller kraven i 98/37/EG Direktiven. EN292 ISO8662 PN8NTC1 Genom att använda följande principstandard:...
  • Page 27 Februar, 1999 INSTRUKSJONER FOR REVERSERBAR VINKELDRILL 7807R OG 7807R–EU 3/8 TOMME MERK Vinkeldrill, modell 7807R og 7807R–EU er konstruert for boring av hull på trange arbeidssteder. Ingersoll–Rand er ikke ansvarlig for verktøymodifikasjoner som utføres av kunden uten at Ingersoll–Rand er rådspurt.
  • Page 28 MELLOMROM (Tegning TPD905–1) SPESIFIKASJONER HLydstyrkenivå Modell Håndtak Chuck–kapasitet Fri Hastighet Vibrasjonsnivå dB (A) tomme o/min Trykk Styrke 7807R, hendelpådrag 1.800 92,2 105,2 7807R–EU Testet i henhold til PNEUROP PN8NTC1.2 Testet i henhold til ISO8662–1 ved 80 % nominell fri hastighet...
  • Page 29 Ingersoll–Rand, Co. (leverandørens navn) Swan Lane, Hindley Green, Wigan WN2 4EZ (adresse) erklærer som eneansvarlig at produktet, Reverserbar vinkeldrill modell 7807R–EU som denne erklæringen gjelder for, oppfyller bestemmelsene i EU–direktivene 98/37/CE EN292 ISO8662 PN8NTC1 ved å bruke følgende prinsipielle standarder:...
  • Page 30 OHJEITA 7807R– JA 7807R–EU– SARJAN 3/8 TUUMAN KAKSISUUNTAISIIN KULMAPORAKONEISIIN HUOMAA 7807R– ja 7807R–EU– sarjan kulmaporakone on suunniteltu käytettäväksi reikien poraamiseen metalliin sellaisissa sovelluksissa, joissa työstöön käytettävissä oleva tila on hyvin ahdas. Ingersoll–Rand ei ole vastuussa työkalujen mahdollisista modifikaatioista muihin sovelluksiin, joista Ingersoll–Randille ei ole tiedoitettu.
  • Page 31 ERITTELY HMelutaso Malli Kädensijan Istukan Vapaa Värinä tyyppi kapasiteetti nopeus dB (A) tuumaa 1/min Paine Teho 7807R, vipu 1 800 92,2 105,2 7807R–EU Testattu PNEUROP PN8NTC1.2:n vaatimusten mukaisesti Koestettu ISO8662–1 mukaisesti 80%:sella vapaalla kierrosnopeudella...
  • Page 32 Ingersoll–Rand, Co. (toimittajan nimi) Swan Lane, Hindley Green, Wigan WN2 4EZ (osoite) vakuutamme ja kannamme yksin täyden vastuun siitä, että tuote 7807R–EU –sarjan kaksisuuntaiset kulmaporakoneet johon tämä vakuutus viittaa, täyttää direktiiveissä 98/37/EY EN292 ISO8662 PN8NTC1 esitetyt vaatimukset seuraavia perusnormeja käytettäessä:...
  • Page 33 31 Front End Plate ... . . LA411–11 for 7807R ....WARNING –7–99 32 Front Rotor Bearing ..LA411–34 for 7807R–EU .
  • Page 34 Servicentre Servicecenter Servicesenter Huoltokeskus Ingersoll–Rand Nederland Produktieweg 10 2382 PB Zoeterwoude Nederland Tel: (31) 71 452200 Fax: (31) 71 218671 Ingersoll–Rand Company 510 Hester Drive Ingersoll–Rand Company SA White House, TN 37188 PO Box 3720 Alrode 1451 Tel: (615) 672 0321 South Africa Fax: (615) 672 0601 Tel: (27) 11 864 3930...
