I/O Connectors - TiePie Handyscope HS4 DIFF-5MHz Instrument Manual

8.7

I/O connectors

Ch1–Ch2
Generator out
Power
Extension connector
8.8 System requirements
PC I/O connection
Operating System
8.9 Operating environment
Ambient temperature
Relative humidity
8.10 Storage environment
Ambient temperature
Relative humidity
8.11 Certifications and Compliances
CE mark compliancee
RoHS
8.12 Package
Instrument
Test lead
Accessories
Software
Drivers
Manual
BNC
BNC
3.5 mm power socket
Sub-D 25 pins female
USB 2.0 High Speed (480 Mbit/s)
(USB 1.1 Full Speed (12 Mbit/sec) compatible)
Windows 98/ME/2000/XP/Vista-32
0 - 55 C
10 to 90% non condensing
-20 - 70 C
5 to 95% non condensing
Yes
Yes
Handyscope HS4 DIFF
4 x low noise differential with 4 mm banana jacks
4 x 1:10 differential attenuators
PS2 power cable
Windows 98/2000/ME/XP/Vista-32
Windows 98/2000/ME/XP/Vista-32
Instrument manual and software user's manual
Specifications
