Specifications - TiePie Handyscope HS4 DIFF-5MHz Instrument Manual

Specifications
8.1 Acquisition system
Number of input channels
Ch1, Ch2, Ch3, Ch4
Maximum sampling rate
Sampling source
Accuracy
Stability
Memory
8.2 BNC inputs Ch1 – Ch4
Measure mode
Resolution
Accuracy
Sensitivity
Coupling
Impedance
Maximum voltage
Maximum voltage with 1:10 attenuator
Maximum common mode voltage
Common Mode Rejection Ration
Channel Isolation
Channel Separation
Bandwidth (-3dB)
AC coupling cut off frequency (-3dB)
4 analog
isolated BNC
12 bit 5 MS/s, 10 MS/s, 25 MS/s or 50 MS/s
14 bit 3.125 MS/s
16 bit 195 kS/s
internal quartz, external
0.01%
100 ppm over
128 kSamples per channel
(256 kSamples with disabled generator)
Differential
12, 14, 16 bit user selectable
0.3% 1 LSB
200 mV .. 80 V full scale
AC/DC
2 MΩ / 30 pF
200 V (DC + AC peak
500 V (DC + AC peak
200 mV – 800 mV ranges : 2 V
2 V – 8 V ranges : 20 V
20 V – 80 V ranges : 200 V
-48 dB
500 V
-80 dB
DC to 50 MHz
1.5 Hz
8
40 C to +85 C
10 kHz)
10 kHz)
33
Specifications
