Front panel
6.1
Channel input connectors
The CH1 – CH4 BNC connectors are the main inputs of the acqui-
sition system. The isolated BNC connectors are not connected to
the ground of the Handyscope HS4 DIFF.
6.2
Power indicator
A power indicator is situated at the top cover of the instrument.
It is lit when the Handyscope HS4 DIFF is powered.
Figure 6.1: Front panel
