Trigger System - TiePie Handyscope HS4 DIFF-5MHz Instrument Manual

8.3

Trigger system

System
Source
Trigger modes
Level adjustment
Hysteresis adjustment
Resolution
Pre trigger
Post trigger
Digital external trigger
Input
Sensitivity
Coupling
8.4 Interface
Interface
8.5 Power
Input
Consumption
8.6 Physical
Instrument height
Instrument length
Instrument width
Weight
USB cord length
34
Chapter 8
digital, 2 levels
CH1, CH2, CH3, CH4, digital external, AND, OR,
rising slope, falling slope,
inside window, outside window
0–100% of full scale
0–100% of full scale
0.025 % (12 bits)
0–128 ksamples (0–100%, one sample resolution)
0–128 ksamples (0–100%, one sample resolution)
extension connector
0 .. 5 V (TTL)
DC
USB 2.0 High Speed (480 Mbit/s)
(USB 1.1 Full Speed (12 Mbit/sec) compatible)
from USB or external input
500 mA max
25 mm / 1.0"
170 mm / 6.7"
140 mm / 5.2"
480 gram / 17 ounce
1.8 m / 70"
