- Page 1 MANUAL ENGLISH Cameleon Flood 6NW Ordercode: 42677 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Cameleon Flood 6NW Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................4 Rigging .................................... 4 Connection with the mains............................5 Return Procedure ................................6 Claims ....................................6 Description of the device ..............................7 Optional accessories..............................7 Frontside.................................. -
Page 3: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: ● Showtec Cameleon Flood 6NW ● 1x Schuko to 3-pins (IP-65 ) Power cable 1,5m ●... - Page 4 Cameleon Flood 6NW Before the initial start-up, please make sure that there is no damage caused by transportation. Should there be any, consult your dealer and do not use the device. To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to follow the safety instructions and warning notes contained in this manual.
-
Page 5: Operating Determinations
Cameleon Flood 6NW ● If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service. ● For adult use only. The device must be installed beyond the reach of children. Never leave the unit running unattended. -
Page 6: Connection With The Mains
When rigging, derigging or servicing the Cameleon Flood, always make sure, that the area below the installation site is secured and that there are not any unauthorized people around. The Cameleon Flood 6NW can be placed on a flat stage floor or mounted to any kind of truss with a clamp. -
Page 7: Return Procedure
Cameleon Flood 6NW Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. -
Page 8: Description Of The Device
Cameleon Flood 6NW Description of the device Features The Cameleon Flood 6NW is a wall washer with great output and effects. It is an extension on our Cameleon series. It's an indoor and outdoor solution for illumination of numerous objects. ●... -
Page 9: Frontside
Cameleon Flood 6NW Frontside Fig. 01 01) 6x 8W Power LED (Neutral white) 02) IR sensor 03) Mounting bracket Backside Fig. 02 04) Special mini 3-pin DMX cable IN IP-65 05) Safety eye 06) Special mini 3-pin DMX cable OUT IP-65... -
Page 10: Installation
Cameleon Flood 6NW Installation Remove all packing materials from the Cameleon Flood 6NW. Check if all foam and plastic padding is removed. Connect all cables. Do not supply power before the whole system is set up and connected properly. Always disconnect from electric mains power supply before cleaning or servicing. -
Page 11: Multiple Cameleon Floods (Master/Slave Control)
Cameleon Flood 6NW Multiple Cameleon Floods (Master/Slave control) 01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation. 02) Always use a safety cable (ordercode 70140 / 70141). 03) Use a 3-p XLR cable to connect the Cameleon Floods and other devices. -
Page 12: Multiple Cameleon Floods (Dmx Control)
Cameleon Flood 6NW Multiple Cameleon Floods (DMX Control) 01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation. 02) Always use a safety cable (ordercode 70140 / 70141). 03) Use a 3-pin XLR cable to connect the Cameleon Floods and other devices. -
Page 13: Fixture Linking
DMX Extension cable for Cameleon series (3m) 427076 DMX Extension cable for Cameleon series (6m) 42708 DMX Input cable for Cameleon series (3m) The Cameleon Flood 6NW can be operated with a controller in control mode or without the controller in stand-alone mode. 42677... -
Page 14: Control Panel
Cameleon Flood 6NW Control Panel A) OLED Display MODE button C) SET button D) UP button DOWN button Fig. 05 Control Mode The fixtures are individually addressed on a data-link and connected to the controller. The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it, the controller will display the saved DMX address, next time.) -
Page 15: Menu Overview
Cameleon Flood 6NW Menu Overview The Cameleon Flood 6NW will show the current software version and actual temperature at start-up ! 42677... -
Page 16: Main Menu Options
Cameleon Flood 6NW Main Menu Options 01) Press the SET or MODE button to open the main menu. The display will show: 02) Press the UP/DOWN buttons to toggle between the menus. 03) Press the SET button to open the desired menu. -
Page 17: Master/Slave
Cameleon Flood 6NW 3. Master/slave In this menu you can set the device as a slave. 01) While in the main menu, press the UP/DOWN buttons until the display shows Slave. 02) Press the SET button to open the menu, the display will show: 03) Press the UP/DOWN buttons to choose between Yes or No. -
Page 18: Curves Select
Cameleon Flood 6NW 5.1. Curves Select In this menu you can adjust the dimming of the device by choosing a dimming curve. 01) Press the UP/DOWN buttons to choose Curves Select. 02) Press the SET button to open the menu. -
Page 19: Dmx Fail
Cameleon Flood 6NW 5.3. Dmx Fail In this menu you can adjust the behaviour of the device in case of a DMX signal error . 01) Press the UP/DOWN buttons until the display shows Dmx Fail. 02) Press the SET button to open the menu, the display will show: 03) Press the UP/DOWN buttons to choose the desired option. -
Page 20: Factory
Cameleon Flood 6NW 5.6. Factory In this menu you can reset to the factory default settings. 01) While in Settings menu, press the UP/DOWN buttons to choose Factory. 02) Press the SET button to open the menu, the display will show: 03) Press the UP/DOWN buttons to select Yes or No. -
Page 21: Optional Remote Control
Cameleon Flood 6NW Optional remote control Button Function Description On / Off Switch the device ON or OFF Program Activates the Built-in program Speed Activates the Program speed mode Strobe Activates the Strobe frequency mode Dimming Activates the Manual mode... -
Page 22: Dmx Channels
04) The electric power supply cables must not show any damages or material fatigue. The Cameleon Flood 6NW requires almost no maintenance. However, you should keep the unit clean. Otherwise, the fixture’s light-output will be significantly reduced. Disconnect the mains power supply, and then wipe the cover with a damp cloth. -
Page 23: Troubleshooting
01) Power supply. Check that the unit is plugged into an appropriate power supply. 02) The LEDs. Return the Cameleon Flood to your Showtec dealer. 03) The internal fuse. Return the Cameleon Flood to your Showtec dealer. 04) If all of the above appears to be O.K., plug the unit in again. - Page 24 Cameleon Flood 6NW Problem Probable cause(s) Solution No power to the fixture • Check if power is switched on and One or more cables are plugged in fixtures do not function at all Internal fuse blown • Return the Cameleon Flood to...
-
Page 25: Product Specifications
Cameleon Flood 6NW Product Specifications Model: Showtec Cameleon Flood 6NW Input Voltage: 100-240 VAC, 50/60Hz Power consumption: 20W @FO Data linking: 30 pcss Drive current: 380mA Refresh rate: >4,2 kHz Protection rate: IP-65 Dimensions: 220 x 90 x 150 mm (LxWxH incl. bracket) -
Page 26: Dimensions
Cameleon Flood 6NW Dimensions 42677... -
Page 27: Notes
Cameleon Flood 6NW Notes 42677... - Page 28 ©2018 Showtec...
