Installation instructions platform
KERN KXP_V20
Version 1.1
04/2015
GB
KERN & Sohn GmbH
Ziegelei 1
D-72336 Balingen
E-Mail: info@kern-sohn.com
Tel: +49-[0]7433- 9933-0
Fax: +49-[0]7433-9933-149
Internet: www.kern-sohn.com
Importør:
Impex Produkter AS
Gamle Drammensvei 107
1363 Høvik
www.impex.no
info@impex.no
Tel.: 22 32 77 20
KXP V20_6-300-IA-e-1511
Advertisement
Table of Contents
Related Manuals for KERN KXP_V20 Series
Summary of Contents for KERN KXP_V20 Series
- Page 1 KERN & Sohn GmbH Ziegelei 1 Tel: +49-[0]7433- 9933-0 D-72336 Balingen Fax: +49-[0]7433-9933-149 E-Mail: info@kern-sohn.com Internet: www.kern-sohn.com Installation instructions platform KERN KXP_V20 Version 1.1 Importør: Impex Produkter AS 04/2015 Gamle Drammensvei 107 1363 Høvik www.impex.no info@impex.no Tel.: 22 32 77 20...
-
Page 2: Table Of Contents
KERN KXP V20 Version 1.1 04/2015 Operating Instruction Platforms Tabel of contents General ......................3 Safety precautions ..................3 Setting up the weighing platform ..............4 Selecting the site of installation ....................4 Package volume ........................4 Protect screw ..........................4 Packaging / return transport .................... -
Page 3: General
KXP150V20M / KXP 150V20LM KXP300V20M 2 Safety precautions Product safety plays an important role at KERN & Sohn. Non-observance of the following instructions can lead to damage to the weighing platform and/or injuries. Before using the weighing platform read these instructions. Store these instruc- tions for future use. -
Page 4: Setting Up The Weighing Platform
3 Setting up the weighing platform 3.1 Selecting the site of installation • The surface must be able to bear the weighing platform under maxi- mum load at the points of support. At the same time it should be so stable that no vibrations arise dur- ing weighing. -
Page 5: Packaging / Return Transport
Models platform sizes 240 x 300 mm and 300 x 400 mm 3.4 Packaging / return transport Keep all parts of the original packaging for a pos- sibly required return. Only use original packaging for returning. Reattach supplied transport securing devices. ... -
Page 6: Levelling
3.6 Levelling Only a weighing platform which is aligned exactly horizontally supplies exact weigh- ing results. The weighing platform has to be levelled during the initial installation and whenever its location is changed. Level platform with foot screws until the air bubble of the water balance is in the prescribed circle. -
Page 7: Connecting To The Weighing Terminal
3.7 Connecting to the weighing terminal Deadweight cell output KERN KXP V20 weighing platform connection EXC+ See marking of the deadweight cell EXC- SIG- SIG+ 4 Operating limits The weighing platform is designed so robustly that an occasional exceeding of the maximum weighing load does not lead to damage. -
Page 8: Cleaning
5 Cleaning Clean the weighing platform with a soft cloth soaked with a mild cleaning agent. Take off the load panel and remove any dirt and foreign substances which may have collected underneath it. Do not use any hard objects to do so. Do not open the weighing platform. -
Page 9: Technical Data Of The Weighing Cell
6.2 Technical data of the weighing cell Sensitivity 2.0 ±0.2 mV/V 406 ±6 Ω Input resistance 350 ±3 Ω Output resistance Supply voltage 5~12 VDC OIML approval KXP V20_6-300-IA-e-1511... -
Page 10: Preload, Deadload And Overload Settings
6.3 Preload, Deadload and Overload settings Center Overload Corner Overload Loadcell max. Preload* (kg) Kern model * = additional initial load Protection circa (kg) Protection circa (kg) Capacity (kg) 1.86 KXP 6V20 LM 2.86 KXP 15V20 M 2.86 KXP 15V20 LM 10.52...
