Data Log

V
s
meters offer a 2000 point data log. Each point
ersa
tar
includes measurements from one to four channels with
the date and time. When the data log function is turned
on in the Instrument Settings setup menu, the read type
determines how the displayed measurements are saved
to the data log.
1. In the measurement mode, press the setup key.
2. Press the or key to highlight Log View and press
the f3 (Select) key.
3. Press the or key to highlight Data Log.
4. Press the
or
key to highlight View and press the
f3 (Select) key.
5. Press the
or
key to highlight a point and press the
enter key to view detailed data for that point. Press the
or key to scroll through additional data log points.
6. Press the measure (esc) key to return to the
measurement mode.
thermoscientific.com/water
© 2014 Thermo Fisher Scientific Inc. All rights reserved. All trademarks are the property of Thermo Fisher
Scientific and its subsidiaries.
Water Analysis Instruments
North America
India
Toll Free: 1-800-225-1480
Tel: (91) 22-4157-8800
Tel: 1-978-232-6000
wai.asia@thermofisher.com
info.water@thermo.com
China
Netherlands
Tel: (86) 21-68654588
Tel: (31) 020-4936270
wai.asia@thermofisher.com
info.water.uk@thermo.com
Japan
Singapore
Tel: (81) 045-453-9175
Tel: (65) 6778-6876
wai.asia@thermofisher.com
wai.asia@thermofisher.com
IS-68X591204-B 0614
Calibration Log
The calibration log contains up to the ten most recent
calibrations per pH, RmV, ORP, ISE, incremental
technique, conductivity, DO and RDO parameter.
1. In the measurement mode, press the setup key.
2. Press the or key to highlight Log View and press
the f3 (Select) key.
3. Press the or key to highlight Cal Log.
4. Press the
or
key to highlight the desired
calibration parameter and press the f3 (Select) key.
5. Press the
or
key to view each calibration for the
selected parameter.
6. Press the measure (esc) key to return to the
measurement mode.
Australia
Tel: (613) 9757-4300
in Australia (1300) 735-295
InfoWaterAU@thermofisher.com
Thermo Scientific Orion
V
s
RDO/Dissolved Oxygen Temperature Module
ersa
tar
This literature provides basic instructions on operating the Thermo Scientific
V
s
RDO/DO measurement module is installed. For comprehensive information on meter and module system
ersa
tar
setup, operation and advanced features, please refer to the V
literature CD or www.thermoscientific.com/water.
Preparation
1. Prepare the universal power adapter, install the meter-attached
electrode stand and verify that the RDO/DO module is connected to
the meter. If it is not connected, insert the module into an available
channel on the back of the meter.
2. Select either the Thermo Scientific
Orion
RDO
probe or Orion polarographic DO probe, based on sample range and
requirements. Prepare the electrodes as instructed in the electrode
user manuals. For improved movement and control, place the
electrodes into the electrode stand.
3. Connect the dissolved oxygen probe cable to the 9 pin MiniDIN input on the module.
Orion
V
s
meter when the
ersa
tar
s
user manual available on the V
ersa
tar
ersa
RDO/DO Module
9 pin
MiniDIN
optical DO
s
tar
