Page 1: Table Of Contents
ExSELLerate™ Series Dealer Training Guide SWB 26/8 At a Glance Specifications Page 2 Introduction Page 3 Overview Page 4 Installing the Lint Screen Page 5 Dual Purpose Page 6 Features and Benefits Page 7 Key Features Page 8 Operational Tips Page 10 Narrative Bid Specifications Page 16... -
Page 2: Specifications
Specifications Machine Dimensions SWB 26/8 Model Number 96210 32 in X 28 in X 24 in L X W X H 80 cm X 70 cm X 60 cm Weight (w/o batteries) 93 lbs. (42 kg) Weight (with batteries) 124 lbs. (56 kg) Capacity 8 gal. -
Page 3: Introduction
Target Market Carpet technicians, janitors, in-house facility managers, and building service contractors will appreciate the features of Tornado’s SWB 26/8 designed for use on large carpeted areas and hard surfaces. This unit is perfect for the following environments: ... -
Page 4: Overview
Overview 1. Main Power Button (activates main and side brush) 8. On-Board Charger 2. Side Brush Power Button 9. Side Brush Lock 3. Charging Indicator 10. Side Brush 4. Battery Power Level Indicator 11. Main Housing 5. Debris Tank Lock Lever 12. -
Page 5: Installing The Lint Screen
If your customer is not operating the SWB 26/8 on carpeting, they do not need to install the lint screen. Tornado recommends, however, that your customer retain the lint screen in the event they need to operate the SWB 26/8 on carpet at a later date. -
Page 6: Dual Purpose
The SWB 26/8 is at home in schools, hospitals, airports, commercial office buildings, theaters, retail, stores, casinos, sports facilities, and arenas. Sweeper Productivity (Sq. Ft. Per Hour) Tornado SWB 26/8 26,000 30” Wide Area Vacuum 10,000 ®... -
Page 7: Features And Benefits
Features & Benefits Maximize sweeping speed up to 26,000 sq. ft. per hour—more than Productivity two-and-a-half times faster than wide-area vacuums and ten times faster than a manual broom! Low Decibel Level Whisper-quiet at 67 dB for noise sensitive environments ... -
Page 8: Key Features
Key Features 1. Productivity Sweeper Productivity (Sq. Ft. Per Hour) The SWB 26/8 has more than double the productivity of a traditional wide area vacuum, saving time and money. 26,000 The unit also will work on both carpet and hard floor surfaces. One machine will cover multiple floor types. - Page 9 Key Features 5. Edge Cleaning With Side Broom The side broom extends from the right side of the machine, increasing the cleaning width by 10 inches. This allows for cleaning right along the edges of walls and other surfaces. This is especially useful when sweeping carpets, eliminating the need for edge cleaning.
-
Page 10: Operational Tips
Operation Tips The side brush power button turns the Main power button activates both the main brush and the side brush. side brush only off and on. ® ExSELLerate Sales Training Series │ SWB 26/8... - Page 11 Operation Tips A safety bolt is located directly in front of the caster. The bolt securely fastens the lid / cover ensuring safety. Qualified maintenance technicians can easily access the mechanicals by removing the bolt. Once the main housing has been lifted you can: Change the pressure Change the pressure of the side brush...
- Page 12 Operation Tips Pull back on the brush lock to set the . If you want the side brush in place brush floating simply pull forward. Pull up on the brush activation lever to engage the brushes and release the lever to disengage them.
- Page 13 Operation Tips Move the Filter Shake lever left and right to knock away loose debris from the filter. Perform this procedure periodically while sweeping in order to keep the filter system efficient. Pull up on debris bin lock and pull back to empty the bin in an approved location.
- Page 14 Operation Tips The filter is located directly above the debris tank. To access the filter: Second, loosen the two wing nuts First, remove the debris tank You now have access to: Lint Screen The Pleated Filter Filter Mount ® ExSELLerate Sales Training Series │...
- Page 15 Operation Tips In order to charge your SWB 26/8, simply plug the on-board charger into a wall outlet. ® ExSELLerate Sales Training Series │ SWB 26/8...
-
Page 16: Narrative Bid Specifications
Narrative Bid Specifications Tornado SWB 26/8, Model: 96210 Specified Unit The specified unit shall be battery operated, employing four (4) sealed, 6 volt, mainte- nance free batteries (24-volt system). The unit shall have an 8 gallon debris bin, with a total cleaning path of 26 inches. -
Page 17: Recommended Stocking Parts List
Recommended Stocking Parts List Part Number Description 90100 Filter 39026 Lint Screen 39122 Main Broom 39167 Side Broom ® ExSELLerate Sales Training Series │ SWB 26/8... -
Page 18: Green Cleaning
Vacuum cleaners including uprights, backpacks and canisters can release dust 3. IAQ Enhancement: and debris into the air if they are not designed with advanced infiltration systems. That’s why Tornado has developed a comprehensive product family of high-filtration vacuums with true HEPA filtration to minimize dust and exhaust from escaping the vacuum. - Page 19 Notes ® ExSELLerate Sales Training Series │ SWB 26/8...
- Page 20 Copyright © 2012. Tornado Industries. ALL RIGHTS RESERVED. Use of text, copy, or distribution of this document is protected by law. 1.800.VACUUMS www.tornadovac.com...
