4.4. Bandwidth and Response

For the PDA detectors, the gain of the detector is dependent on the feedback
element (R ). The bandwidth of the detector can be calculated using the
f
following:
Where GBP is the amplifier gain bandwidth product and C
photodiode junction capacitance and the amplifier capacitance.

4.5. Terminating Resistance

The maximum output of the PDA36A2 is 10 V for high impedance loads (i.e.
RLoad > 5 kΩ) and 5 V for 50 Ω loads. Adjust the gain so that the measured
signal level out of the PDA36A2 is below 10 V (5 V with a 50 Ω load) to avoid
saturation.
For low terminating resistors, <5 kΩ or 1% error, an additional factor needs to be
considered. The output of the PDA includes a 50 Ω series resistor (R
output load creates a voltage divider with the 50 Ω series resistor as follows:


4.6. Gain Adjustment

The PDA36A2 includes a low noise, low offset, high gain transimpedance
amplifier that allows gain adjustment over a 70 dB range. The gain is adjusted by
rotating the gain control knob, located on the top side of the unit. There are 8
gain positions incremented in 10 dB steps. It is important to note that the
bandwidth will decrease as the gain increases. See the specifications table on
page 7 to choose the best gain verse bandwidth for a given input signal.
