Page 1 Preface, Contents Overview SIMATIC NET Industrial Communication Design and Functional Elements MOBIC T8 for Windows CE 3.0 Accessories Ports Manual Getting Started Data Exchange Supplied Programs and Tools Backup and Restore Changing the Settings of the MO- Installing Additional Applications...
Page 2: C79000-G8976-C190
Trademarks MOBICR, SIMATICR and SIMATIC NETR are registered trademarks of SIEMENS AG. Third parties using for their own purposes any other names in this document which refer to trademarks might infringe upon the rights of the trademark owners.
Page 3 Before you use the supplied sample programs or programs you have written yourself, make certain that no injury to persons nor damage to equipment can result in your plant or process. Copyright E Siemens AG 2003 All rights reserved Disclaimer of Liability...
Page 4 Turn off the MOBIC T8 if you are in the vicinity of gas stations, fuel depots, chemical plants or blasting operations. The MOBIC T8 can interfere with technical installations. Note the following: Warning Improper use of the MOBIC T8 invalidates the warranty. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 5: Preface
Preface MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 6 S MOBIC CD The MOBIC CD contains the software for the MOBIC and the documentation in PDF format. S Getting Started Brief instructions to get you off to a quick start with your MOBIC T8. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 7 2. Introducing Microsoft Windows CE for the Handheld PC Author: Robert O’Hara ISBN: 1-57231-515-6 3. Microsoft Windows CE Programmer’s Guide Author: Microsoft Corporation ISBN: 1-57231-634-8 4. Microsoft Windows CE Developer’s Kit Author: Microsoft Corporation ISBN: 0-7356-0619-6 MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 8 S Index Further Support If you have further questions on SIMATIC products, please contact your Siemens representative in your local Siemens office. You will find the addresses in our catalogs, on the Internet, and in CompuServe (go autforum). Workshop MOBIC Toolkit To familiarize you with the MOBIC, we also offer a training course.
Page 9: Table Of Contents
..........MOBIC T8 for Windows CE 3.0...
Page 10 ........11-5 MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 11 ..............Index-1 MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 12: Overview
MOBIC more or less right away. You will find a complete list of the components supplied with the product and the accessories available from SIEMENS. On our Web pages, you will find further up-to-the-minute information on the MOBIC. How to get this information is explained in Section 1.5.
Page 13: Welcome
The unit is operated simply with a touch screen using a pen or finger and also has additional function keys. The standard operating system is Windows CE and the Microsoft Internet Explorer V4.0 with the Java Virtual Machine as the basic software. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 14 - Microsoft Windows CE Internet Explorer V4.0 - Java Virtual Machine with plugin for Internet Explorer - MOBIC system software - Software keyboard - Handwriting recognition S Hardware - CPU NEC VR4121 - MQ 200 graphics controller MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 15: Mobic T8 For Windows Ce
For bi-directional data exchange between a host, for example notebook and the MOBIC - RS-232 port For example for connection with the host computer, for reading out machine data - USB port For connecting a mouse, keyboard, or printer. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 16 With its battery, the MOBIC can be operated for eight hours. The battery can be replaced without any loss of program data. The accessories and expansion modules available for your MOBIC are described in Section 1.4 of this manual. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 17: Quick Start
The components of your MOBIC are listed in Section 1.3. If you discover any damage caused by transport or if the consignment does not match the delivery note please contact the vendor immediately. Caution Do not put any damaged components into operation. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 18 (Section 4.5) (Section 4.7) Headset (Section 4.3) Power PCMCIA (on (Section 4.4) supply socket RS-232 the back in the (Section 4.8) (Section 4.1) battery com- partment) (Section 4.6) Figure 1-2 Ports of the MOBIC MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 19 (see Section 2.5 or 7.2). Status Indicators The MOBIC has LEDs on the front panel of the device below the screen (see Figure 1-1). The meaning of the LEDs is explained in Section 2.6. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 20: Components Of The Product
The stopper prevents a CP 1515 inserted in the internal PCMCIA slot (battery compartment) from coming loose in rough operating conditions. Apart from the basic components belonging to the MOBIC, you can also order accessories. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 21: Accessories
S Power supply unit with cable S Protective foil S Carrying strap S Pens S Carrying case S Replaceable battery S Headset adapter S Charging tray and charging station S Protective cover for MOBIC ports MOBIC T8 for Windows CE 3.0 1-10 C79000-G8976-C190-02...
Page 22: Up-To-The-Minute Information On The Internet
Up-to-the-Minute Information on the Internet In our Web site, you will find wide-ranging information about the product, customer support, and tips and tricks to help you make the best use of your MOBIC. www.siemens.com/mobic MOBIC T8 for Windows CE 3.0 1-11 C79000-G8976-C190-02...
Page 23 Overview MOBIC T8 for Windows CE 3.0 1-12 C79000-G8976-C190-02...
Page 24: Design And Functional Elements
Design and Functional Elements This chapter describes the basic design of your MOBIC. All the operator controls, functional and display elements required to work with your MOBIC are illustrated and described. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 25: Front View
There are a total of four LEDs that indicate the status of the unit. S Loudspeaker The integrated loudspeaker allows you to play audio files. S Carrying strap attachment points These are used to secure the shoulder or hand strap. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 26: Top With Protective Cover Open
PCs and the MOBIC. An infrared port is used for communication with devices complying with the IR standard. S Headset Allows the connection of a headset with a microphone to the MOBIC. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 27 S PCMCIA (under the protective cover) External PCMCIA slot, for example for connecting a barcode reader. S Ethernet (RJ-45) For direct attachment to existing Ethernet networks. S Power Supply Connector Used to connect the shipped power supply unit. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 28: Rear
Figure 2-3 Rear View with Battery Cover Open Elements in the Battery Compartment S Battery S Warm reset button S Cold reset button S PCMCIA port in battery compartment MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 29: Battery
Only replace the battery with the same battery or with a battery of the same type as recommended by the manufacturer. Do not incinerate or mutilate may burst or release toxic chemicals. Do not short circuit may cause burns. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 30 The backup battery provides the minimum necessary power supply when the main battery is removed. To avoid loss of data, you should only leave the device without its normal power supply for a short period (a few hours). MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 31 In the “Battery” tab, you will see the status of the main battery and backup battery. You can also display this menu by double-tapping the battery icon in the status bar of the system. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 32: Fixed Mounting Of The Mobic
There are four M4 screw holes on the rear of the MOBIC (see Figure 2-3). Caution Only use M4 screws and keep to the maximum screw-in depth of 7 mm. When mounting the unit, do not exceed the maximum torque (2 Nm) for the screw holes. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 33 The dimensions for the drilling template are shown in Figure 2-5. Front view Detail X: Screw holes for wall -mounting on rear of device (4 x) Figure 2-5 Dimensions for a Drilling Template MOBIC T8 for Windows CE 3.0 2-10 C79000-G8976-C190-02...
Page 34: Reset Buttons
In contrast to the warm reset, this cold reset button also clears the RAM and resto- res the “Default Registry”. The data in the flash are retained. Note You can also start a warm reset with the MOBIC Configurator. MOBIC T8 for Windows CE 3.0 2-11 C79000-G8976-C190-02...
Page 35: Function Keys
Individual Assignment You can also assign functions that you require often to the five function keys. You make this assignment in the MOBIC Configurator. MOBIC configuration is described in detail in Chapter 7. MOBIC T8 for Windows CE 3.0 2-12 C79000-G8976-C190-02...
Page 36: Status Indicators (Leds)
(for example, mail arrived) Power supply unit there is no message user-defined not connected: pending Power supply from battery Power supply connected: Battery fully charged. MOBIC T8 for Windows CE 3.0 2-13 C79000-G8976-C190-02...
Page 37: Loudspeaker
You can also turn off the loudspeaker by deactivating all the check boxes for “Enable sounds for:”. Assigning Acoustic Signals In the “Sounds” tab, you can also assign acoustic signals to certain events. Note If the headset is plugged in, the loudspeaker is automatically disabled. MOBIC T8 for Windows CE 3.0 2-14 C79000-G8976-C190-02...
Page 38: Touchscreen
You make your input and control the MOBIC by tapping the touchscreen. Caution Touchscreen input must only be made with the tip of the pen (stylus) intended for the touchscreen and not with the ballpoint. MOBIC T8 for Windows CE 3.0 2-15 C79000-G8976-C190-02...
Page 39 You can switch over the keyboard with the special character shift key at the bottom left. It is also possible to connect a normal keyboard to the USB port (see Section 4.4). MOBIC T8 for Windows CE 3.0 2-16 C79000-G8976-C190-02...
Page 40 Whether or not Jot is activated is indicated by the icons in the status bar (see Figure 2-10 and 2-11). Jot icon (not activated) Figure 2-10 Jot “Arrow” Icon Jot icon (activated) Figure 2-11 Jot “Pen” Icon MOBIC T8 for Windows CE 3.0 2-17 C79000-G8976-C190-02...
Page 41: On/Off Button
When you press this button, the MOBIC is set to the “Sleep” mode. By pressing the on/off button again, the device is immediately ready for operation (“instant on” function in Windows CE). On/Off button Figure 2-12 Location of the On/Off Button MOBIC T8 for Windows CE 3.0 2-18 C79000-G8976-C190-02...
Page 42: Accessories
Accessories This chapter describes the accessories for the MOBIC. It also explains how to fit the accessories to the MOBIC. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 43: Carrying Straps
Fitting the Strap You can fit the shoulder/neck strap as shown in Figure 3-1. Figure 3-1 Fitting the Shoulder/Neck Strap or Hand Strap Caution Make sure that the straps are securely attached to the device. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 44 If you fit the strap to the left and right of the MOBIC, you can put the strap round your neck and have your hands free to make input. Figure 3-3 MOBIC with Neck Strap MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 45 Make sure that the strap is securely attached to the device. Possible Application The hand strap is used to hold the MOBIC during mobile operation (see Figure 3-5). Figure 3-5 MOBIC in Mobile Operation with the Hand Strap MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 46: Pen
Touchscreen input must only be made with the tip of the pen (stylus) intended for the touchscreen and not with the ballpoint. There is a loop on the hand strap where you can keep the pen. Figure 3-6 Hand Strap with Pen MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 47: Power Supply Unit
Accessories Power Supply Unit The supplied power supply unit is described in detail in Section 4.8. RS 232 Cable (serial port) The supplied RS-232 cable is described in detail in Section 6.2.2. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 48 SIMATIC HMI HMI Device MOBIC T8 in areas susceptible to electromagnetic interference Product information This documentation is valid for delivery units with order number: • 6GK1611-0TA01-1DX0 • 6GK1611-0TA01-1DV0 • 6GK1611-0TA01-0DX0 08/2006 A5E00882110-01...
Page 49 Safety Guidelines This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert symbol, notices referring only to property damage have no safety alert symbol.
Page 50 Trademarks All names identified by ® are registered trademarks of the Siemens AG. The remaining trademarks in this publication may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Page 51 Siemens. Correct, reliable operation of the product requires proper transport, storage, positioning and assembly as well as careful operation and maintenance.
Page 52 MOBIC T8 in areas susceptible to electromagnetic interference Validity This product information is valid for the MOBIC T8 with one of the following order numbers: 6GK1611-0TA01-1DX0 • 6GK1611-0TA01-1DV0 • 6GK1611-0TA01-0DX0 • A MOBIC T8 with one of these order numbers is delivered with a CP 1515 Wireless-LAN PCMCIA card already built-in.
Page 53 MOBIC T8 in areas susceptible to electromagnetic interference Use in areas susceptible to electromagnetic interference Caution Wireless LAN PCMCIA card CP 1515 If you use the MOBIC T8 in an area susceptible to electromagnetic interference, for example an airplane or in a hospital, then you have to disable the wireless LAN PCMCIA card CP 1515 or, depending on how it is installed, remove or unplug it.
Page 54 1. Switch on the MOBIC T8. 2. Select "Start ► Settings ► Control Panel ► Regional and Language Options". 3. Open WLAGS641. The dialog "Siemens Wireless Network Driver" opens. 4. Select the "IP Address" tab. 5. Select the "Disabled" checkbox. 6. Press OK.
Page 55 Enhancement of the rechargeable battery time If the CP 1515 is not required, removing or disabling it increases the rechargeable battery time. Additional notes on this are available on the Internet at: http://support.automation.siemens.com, ID-Nr.: 23335406 MOBIC T8 Product information, 08/2006, A5E00882110-01...
Page 56: Ports
(Section 4.5) (Section 4.7) Headset (Section 4.3) Power PCMCIA (on (Section 4.4) supply socket RS-232 the back in the (Section 4.8) (Section 4.1) battery com- partment) (Section 4.6) Figure 4-1 Ports of the MOBIC MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 57: Serial Port)
You can connect a cable with a 9-pin sub-D female connector to this port. Possible Applications Via the RS-232 port, you can, for example, establish a connection to your host computer using the Microsoft ActiveSync program or to another peripheral device with an RS-232 port. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 58: Infrared Port (Ir)
For more detailed information on establishing a connection with your host computer via the infrared port, refer to Section 6.2. You can also use the infrared port to connect peripheral devices such as printers to your MOBIC. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 59 Ports Note It is not possible to operate the infrared port and serial port at the same time. Warning Do not examine the active infrared interface using optical magnification devices. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 60: Headset Port
With a headset (earphones and microphone) connected to the headset port, you can, for example, record conversations. A headset adapter can be ordered as a MOBIC accessory. Using this adapter, you can connect commercially available headsets with 2 x 3.5 mm jack plugs. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 61: Usb Port
The USB host port of the MOBIC allows connection of USB-target compatible devices (Universal Serial Bus). These include PC peripherals such as printers, mouse, keyboard, WEB CAM, barcode readers etc. (see also Section 1.4). MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 62 Windows CE, make sure that the manufacturer of the device supplies a Windows CE USB driver with the device. USB drivers for a mouse and keyboard are integrated in Windows CE 3.0. Special drivers do not need to be installed for these devices. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 63: Pcmcia Port Under The Protective Cover
This port allows the use of suitable PCMCIA cards (Type II). Possible Applications The PCMCIA port under the protective cover is suitable, for example, for connecting a barcode scanner with a read pistol. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 64 Caution If you encounter problems with the PCMCIA card after dropping or jolting the MOBIC T8 heavily, check that the PCMCIA card is inserted correctly and restart the MOBIC T8. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 65: Pcmcia Port In The Battery Compartment
This port allows the use of suitable PCMCIA cards (Type II). Possible Applications The PCMCIA port in the battery compartment is particularly suitable for the use of PCMCIA wireless cards (wireless LAN). MOBIC T8 for Windows CE 3.0 4-10 C79000-G8976-C190-02...
Page 66 For more detailed information on installing drivers, refer to Chapter 10. Dimensions The maximum possible dimensions of a PCMCIA card in the battery compartment are as follows (length x width x height): 127 mm x 54 mm x 5 mm MOBIC T8 for Windows CE 3.0 4-11 C79000-G8976-C190-02...
Page 67: Ethernet (Rj-45) Port
Possible Applications Using the Ethernet (RJ-45) port, you can connect the MOBIC to a local network (for example, your intranet). Caution Only for use in the LAN. Do not connect to telecommunications facilities. MOBIC T8 for Windows CE 3.0 4-12 C79000-G8976-C190-02...
Page 68 (RJ-45) port, you must first set the network parameters for operation. To do this, perform the steps described in Section 6.3 “Configuration of the Ethernet Port”. Note It is not possible to operate Ethernet (RJ-45) if a wireless LAN card is inserted. MOBIC T8 for Windows CE 3.0 4-13 C79000-G8976-C190-02...
Page 69: Power Supply Unit
1. Remove the protective cover from the top of the unit. 2. Connect the power supply unit to the MOBIC. 3. Connect the main power cable to the power supply unit. 4. Plug the power cable into a socket. MOBIC T8 for Windows CE 3.0 4-14 C79000-G8976-C190-02...
Page 70 (risk of heat accumulation). Note There are two contacts on the rear of the MOBIC to allow the battery to be charged in the MOBIC charging tray or charging station. MOBIC T8 for Windows CE 3.0 4-15 C79000-G8976-C190-02...
Page 71: Getting Started
Getting Started This chapter describes the basic steps required to put your MOBIC into operation. You should read this information carefully before starting to work with the unit. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 72: Getting Started
“Date/Time” icon in the Control Panel of Microsoft Windows CE (Start->Settings ->Control Panel) and set the current date, time and time zone. Further Settings You can still make a wide range of further individual settings in MOBIC configuration. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 73: Data Exchange
Data Exchange This chapter describes how you communicate with the MOBIC. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 74: Communication In Networks
To transfer data to the server, the following hardware can be used: S Wireless LAN (PCMCIA) S Wireless network GSM modem (PCMCIA) S Serial (RS-232) S Ethernet PCMCIA S IR port S Ethernet (RJ-45) MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 75: Connecting Using Activesync
This means that the data is always up to date regardless of which computer is used for display. Specifying a partnership is also a requirement for establishing an ActiveSync connection via Ethernet (see below). MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 76: Installation
(see Figure 6-1) that displays the status of the connection to your MOBIC. Icon Green = connected Gray = not connected Shows the status of the connection on the host computer to the MOBIC Figure 6-1 Status of the Connection to the MOBIC MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 77: Establishing A Serial Connection
Once the connection to your MOBIC is established, an icon appears in the status bar of your MOBIC in the form of a connection icon (see Figure 6-3). Connection icon (Status: Connection active) Figure 6-3 Connection Icon for a Serial Connection MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 78: Establishing An Infrared Connection
S Click/tap on Start, Settings and Control Panel one after the other S Double-click or double-tap the communications icon and click/tap the PC connection tab. S Click/tap Change... S Select infrared port in the list and confirm with “OK”. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 79: Estanblishing An Connection With An Host Computer Vian Ethernet
To establish a connection via Ethernet, follow the steps below: 1. As described above, set up a partnership via a serial connection. 2. Then disconnect the serial connection by removing the serial cable. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 80 “Connect to” select the computer to which you want to establish a connection. Note: The “Connect to” list displays all computers with which you have set up a partnership. 6. Tap on “Connect...” to establish the connection. Note: The first connection may take several seconds. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 81 Table 6-1 below provides an overview of all the ports with which an ActiveSync connection can be established. Table 6-1 Overview of ActiveSync Connections Connection Operating system on the host PC method Windows 95 Windows 98 Windows 2000 Windows NT Serial Ethernet Infrared MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 82: Configuration Of The Ethernet Port
“Name Servers” tab and enter the address of your PC. 5. Confirm your entries with OK. 6. Reset your MOBIC by tapping on the “Reset” button in the “Miscellaneous” tab of the MOBIC Configurator (warm reset). The new configuration is activated. MOBIC T8 for Windows CE 3.0 6-10 C79000-G8976-C190-02...
Page 83: Access To Html Pages With The Microsoft Internet Explorer V4.0
Internet Explorer familiar from your PC. Note Before you can view pages on an intranet or on the Internet, you must first configure the network access as explained in Section 6.3. MOBIC T8 for Windows CE 3.0 6-11 C79000-G8976-C190-02...
Page 84: Java
You can also create your own applets and run them locally on the MOBIC. The JVM installed on the MOBIC: S corresponds to the pJava V3.1 specification (Personal Java) S is based on the API (Application Interface) of the JDK V 1.1.8 (Java Development Kit) MOBIC T8 for Windows CE 3.0 6-12 C79000-G8976-C190-02...
Page 85: Access To An Ftp Server With The Microsoft Internet Explorer V4.0
It is only possible to copy complete files. There must also be space for the entire file on the Windows CE device. The data must exist in a format that can be read by a Windows CE application. MOBIC T8 for Windows CE 3.0 6-13 C79000-G8976-C190-02...
Page 86: Access To Network Drives With The Windows Explorer
To open files, you must specify the complete network path. When you open a file, the entire file is transferred. The data must exist in a format that can be read by a Windows CE application. MOBIC T8 for Windows CE 3.0 6-14 C79000-G8976-C190-02...
Page 87: E-Mails With Microsoft Pocket Outlook
In this mode, the MOBIC functions simply as an input device (thin client) that requires a permanent network connection to a Windows terminal server (for example in a wireless LAN). You will find further information in our Web site: www.siemens.com/mobic MOBIC T8 for Windows CE 3.0 6-15...
Page 88: Supplied Programs And Tools
The MOBIC is supplied with both a number of Microsoft Windows CE standard programs and additional programs some of which were developed especially for the MOBIC. This chapter lists the supplied standard programs and includes a brief description of each of these programs. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 89: Standard Programs
Microsoft Inbox includes functions for sending and receiving E-mails. Using ActiveSync (see Section 5.1), you can synchronize data in Microsoft Outlook on your host computer with the data in Inbox on your MOBIC. Starting Tap on Inbox in the Start->Programs menu. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 90: Microsoft Internet Explorer V4.0
Tap on the icon for the Internet Explorer in the Start -> Programs menu. Java A Java Virtual Machine was adapted using a plugin. This makes it possible for you to download and execute Java Applets embedded in HTML pages via the Internet. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 91: Handwriting Recognition With Jot
By tapping on the currently displayed icon in the system bar, you can activate or deactivate Jot. You can open a window for setting the Jot properties by double-tapping on the Jot icon. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 92: Ping
In this mode, the MOBIC functions simply as an input device (thin client) that requires a permanent network connection to a Windows terminal server (for example in a wireless LAN). You will find further information in our Web site: www.siemens.com/mobic MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 93: Mobic Configurator
These tabs are assigned to the components listed above. Online Help The MOBIC Configurator has an online help system with descriptions of all the specific MOBIC settings that you can refer to at any time. To start: Tap the “?” button MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 94 S Storage Card External PCMCIA flash card S Internal Disk Flash For each area, you can see the information “Total” (“total available memory”), “In Use” (“currently used memory”) and “Free” (“free memory”) displayed in Kbytes. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 95: Trace Archive Tab
After tapping on the “Trace Archive” tab, you display the user interface for configuring the trace archive (see Figure 7-6). Note Standard Windows CE programs do not use this trace archive. Figure 7-6 User Interface for Configuring the Trace Archive MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 96 Trace to File (Trace Output) 8 data bits, no parity, 1 stop bit, no handshake 115200 (baud rate) Trace Archive Path Here, you can change the path for the trace archive. Default setting: \Windows\Logfiles MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 97: Error Archive Tab
The Error Archive function is a tool to help development of new user programs under Windows CE. After tapping on the “Error Archive” tab, you display the user interface for configuring the error archive (see Figure 7-7). MOBIC T8 for Windows CE 3.0 7-10 C79000-G8976-C190-02...
Page 98 “Apply” button. You can restore the default values for the error archive by simply tapping on the “Set Default Settings” button. Error Archive Path Here, you can change the path for the error archive. Default setting: \Windows\Logfiles MOBIC T8 for Windows CE 3.0 7-11 C79000-G8976-C190-02...
Page 99 Errors with medium priority are included in this error level. S User Information This level has the lowest priority of all three error levels. Default setting: critical error Note If you change the error level, the relevant programs must be restarted. MOBIC T8 for Windows CE 3.0 7-12 C79000-G8976-C190-02...
Page 100: F1...F5 Tab
The current configuration of the five function keys is displayed in the “Function Key Assignment: ” list boxes. Default settings for the function keys F1...F5: F1: Start operating system help F2: Start Microsoft Terminal Client F3: Start MOBIC Configurator MOBIC T8 for Windows CE 3.0 7-13 C79000-G8976-C190-02...
Page 101 Figure 7-10); this starts the function (comparable with pressing the Alt key). Status “active” Right Mouse Button (Status “active”) Status “inactive” Figure 7-10 Right Mouse Button” Function 2. The next action with the pen executes a right mouse click. MOBIC T8 for Windows CE 3.0 7-14 C79000-G8976-C190-02...
Page 102 If the slider is at the extreme left, this is the shortest possible debounce time, moving it to the extreme right sets the longest possible debounce time. Default setting: Shortest debounce time (slider at the extreme left) MOBIC T8 for Windows CE 3.0 7-15 C79000-G8976-C190-02...
Page 103: Software Tab
You obtain the following information about each application. S Application name (Name) S Version number of the application (optional) S Date the application was created (optional) Figure 7-12 Overview of all Installed Applications MOBIC T8 for Windows CE 3.0 7-16 C79000-G8976-C190-02...
Page 104: Miscellaneous Tab
Supplied Programs and Tools 7.2.6 Miscellaneous Tab If you tap on the “Miscellaneous” tab, you display the user interface of the MOBIC Configurator in which you can make further settings (see Figure 7-13). MOBIC T8 for Windows CE 3.0 7-17 C79000-G8976-C190-02...
Page 105 Supplied Programs and Tools MOBIC T8 for Windows CE 3.0 7-18 C79000-G8976-C190-02...
Page 106 In the “Power Switch” group, you can lock or unlock the on/off switch. If you select the “Unlocked” option, this function is not disabled, if you select the “Locked” option, the function is disabled and the MOBIC is then permanently on (example: terminal operation). Default setting: unlocked MOBIC T8 for Windows CE 3.0 7-19 C79000-G8976-C190-02...
Page 107 You can also trigger a warm reset by pressing the function keys F2, F3 and F4 simultaneously. In this case, you do not need to be in the MOBIC Configurator. MOBIC T8 for Windows CE 3.0 7-20 C79000-G8976-C190-02...
Page 108 Power Supply on the RS-232 Port The MOBIC provides a power supply (5V/max. 200 mA) on the RS-232 port (pin 9). This power supply can be enabled/disabled. As default, this is “disabled”. MOBIC T8 for Windows CE 3.0 7-21 C79000-G8976-C190-02...
Page 109: Error And Trace Archive
The user interface of the error archive provides you with various input boxes with which you can filter all existing error messages according to specific criteria. When you open the error archive, the filter is set so that all messages are displayed. MOBIC T8 for Windows CE 3.0 7-22 C79000-G8976-C190-02...
Page 110 (entries made in the four input boxes). The latest (most recent) message is always displayed in the first line of the log view. MOBIC T8 for Windows CE 3.0 7-23 C79000-G8976-C190-02...
Page 111 (see Figure 7-15) by selecting the “Trace Messages” option button instead of the “Error Messages” option button. MOBIC T8 for Windows CE 3.0 7-24 C79000-G8976-C190-02...
Page 112 Date and time at which the trace message was generated in the format dd/mm/yy hh:mm:ss S Level Trace level of the trace message S Message Trace output text Figure 7-15 Trace Archive MOBIC T8 for Windows CE 3.0 7-25 C79000-G8976-C190-02...
Page 113: Backup And Restore
Backup and Restore This chapter explains how you can save your data. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 114 2. Click on the file you want to save and then select the ”Copy” command in the “Edit” menu. 3. Now double-click Internal Disk and select the ”Paste” command in the ”Edit” menu. The file is then saved on the Internal Disk (in other words in the flash). MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 115 Backups also contain information on the touchscreen calibration. This means that if you restore a backup created on a different MOBIC, the touchscreen must be recalibrated. To calibrate the touchscreen, press F1 + F5 simultaneously. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 116: Changing The Settings Of The Mobic
Changing the Settings of the MOBIC This chapter explains how you can change the settings of your MOBIC to meet your own specific requirements. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 117: Energy Saving
(Start->Settings ->Control Panel->Display). Then select the “Backlight” tab and set the time after which the device automatically darkens the display. The shorter this time (can be selected between 15 seconds and 5 minutes), the longer the battery will remain operational. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 118: Mobic Configuration
You can, for example assign input that you require often (for example starting a particular program) to one of the five available function keys. For detailed information on working with the MOBIC Configurator, refer to Chapter 7. MOBIC T8 for Windows CE 3.0 C79000-G8976-C190-02...
Page 119 Installing Additional Applications and Drivers This chapter explains how you can expand the functionality of your MOBIC. MOBIC T8 for Windows CE 3.0 10-1 C79000-G8976-C190-02...
Page 120 3. Select “Software” in the “Extras” menu in the ActiveSync window. 4. Select the check box for the program you want to remove. 5. Click “Remove” to remove the selected program from the MOBIC and the host computer. MOBIC T8 for Windows CE 3.0 10-2 C79000-G8976-C190-02...
Page 121: Repair, Care, And Maintenance
Repair, Care, and Maintenance This chapter contains useful tips and information on repair, care, and maintenance of your MOBIC. MOBIC T8 for Windows CE 3.0 11-1 C79000-G8976-C190-02...
Page 122: Repairs
For information on the system expansions suitable for installation, contact the technical customer service or sales department. Note The guarantee is nullified if defects are caused on the MOBIC by installing or replacing system expansions. MOBIC T8 for Windows CE 3.0 11-2 C79000-G8976-C190-02...
Page 123: Tft Screen
(eyes, mouth etc.) or with foodstuffs. Do not inhale any vapors escaping from the screen. If your skin or clothing becomes contaminated, clean thoroughly with plenty of soap and water. MOBIC T8 for Windows CE 3.0 11-3 C79000-G8976-C190-02...
Page 124: Cleaning
Note Cleaning the surface of the display with denatured alcohol can leave smears on the screen. In this case, polish the surface of the screen gently with a soft, dry cloth. MOBIC T8 for Windows CE 3.0 11-4 C79000-G8976-C190-02...
Page 125: Changing The Protective Foil
To achieve a good seal between the screen foil and the display, do not remove the foil again after it has been fitted to the display. MOBIC T8 for Windows CE 3.0 11-5 C79000-G8976-C190-02...
Page 126: Seals
11.5 Seals Before you replace the protective cover or the cover of the battery compartment, make sure that all the seals are clean and if necessary clean them with a damp cloth. MOBIC T8 for Windows CE 3.0 11-6 C79000-G8976-C190-02...
Page 127: Recalibrating The Screen
30 seconds if you want to save the new calibration settings. If you do not tap on the screen within 30 seconds, the ”old” calibration settings are retained. MOBIC T8 for Windows CE 3.0 11-7 C79000-G8976-C190-02...
Page 128: Pen
Repair, Care, and Maintenance 11.7 Working with a worn or dirty pen can scratch the screen. Make sure that you replace the pen in good time. MOBIC T8 for Windows CE 3.0 11-8 C79000-G8976-C190-02...
Page 129: Battery
Risk of fire, explosion, and burns: Do not squash, take apart, or burn. The battery must not be exposed to a temperature in excess of °F (100 °C). MOBIC T8 for Windows CE 3.0 11-9 C79000-G8976-C190-02...
Page 130: Certificates, Directives, And Declarations
Certificates, Directives, and Declarations MOBIC T8 for Windows CE 3.0 12-1 C79000-G8976-C190-02...
Page 131: Notes On The Ce Mark
The EU declarations of conformity and corresponding documentation are available for the responsible authorities according to the above-mentioned EU directive at the following address: Siemens AG Bereich Automation & Drives Industrielle Kommunikation (A&D PT2) Postfach 4848 D-90327 Nürnberg MOBIC T8 for Windows CE 3.0 12-2 C79000-G8976-C190-02...
Page 132 This was confirmed by DQS (Deutsche Gesellschaft zur Zertifizierung von Qualitätsmanagementsystemen mbH) . EQ−Net Certificate No.: 1323−01 The MOBIC is supplied with the software installed. Please adhere to the corresponding license agreements. MOBIC T8 for Windows CE 3.0 12-3 C79000-G8976-C190-02...
Page 133: Certificates For Usa, Canada, And Australia
Underwriters Laboratories (UL) complying with Standard UL 60950, Report E21 6641 and Canadian Standard C22.2 No. 60950 (I.T.E) or complying with UL508 and C22.2 No. 142 (IND.CONT.EQ) UL Recognition Mark FM approved, Class I Division II, Class 3611, 3810 MOBIC T8 for Windows CE 3.0 12-4 C79000-G8976-C190-02...
Page 134 This Class A digital apparatus complies with Canadian ICES-003. Avis Canadien Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. Australia AS/NZS 2064 This product fulfills the requirements of the Standard (Class A). MOBIC T8 for Windows CE 3.0 12-5 C79000-G8976-C190-02...
Page 135: Frequently Asked Questions (Faqs)
Frequently Asked Questions (FAQs) MOBIC T8 for Windows CE 3.0 13-1 C79000-G8976-C190-02...
Page 136 If the pen selects a different area of the screen from the point at which you tap, you should recalibrate the screen. Follow the instructions in Section 11.6 – Recalibrating the Screen. MOBIC T8 for Windows CE 3.0 13-2 C79000-G8976-C190-02...
Page 137 Windows CE API is a subset of Windows 9x/NT API. There are also APIs specifically for Windows CE. You will find more information at: http://msdn.microsoft.com/cetools/ Can Java applications run on the MOBIC? MOBIC T8 for Windows CE 3.0 13-3 C79000-G8976-C190-02...
Page 138 Frequently Asked Questions (FAQs) Wireless LAN Which Wireless LAN can be used? You will find this information on the Internet page www.siemens.com/mobic How far does a Wireless LAN extend? A Wireless LAN can extend approximately 30 to 100 m around an access point depending on the architecture of the room and whether the card is operated in the internal (IP65) PCMCIA or in the external PCMCIA slot.
Page 139 1. Open the “Network Resources” program. 2. Select the network connection to be deleted. 3. Tap on “Disconnect”. 4. Then tap on “OK”. 5. The network connection has been removed from your network folder. MOBIC T8 for Windows CE 3.0 13-5 C79000-G8976-C190-02...
Page 140 Due to the high resolution, this is, however, relatively difficult. Remedy: In the registry of the terminal server, change the maximum deviation for a double click to a higher value (for example to 20). [HKEY_CURRENT_USER/Control Panel/Mouse] “DoubleClickHeight”=”20” “DoubleClickWidth”=”20” MOBIC T8 for Windows CE 3.0 13-6 C79000-G8976-C190-02...
Page 141: Technical Specifications
Technical Specifications MOBIC T8 for Windows CE 3.0 14-1 C79000-G8976-C190-02...
Page 142 MS Windows CE 3.0 Software MS Inbox MS Pocket Word MS Internet Explorer V4.0 Java Virtual Machine with plugin for Internet Explorer MS Thin Client Software keyboard Jot Handwriting Recognition MOBIC System Software MOBIC T8 for Windows CE 3.0 14-2 C79000-G8976-C190-02...
Page 143 2 LED yellow (function user-defined) Processor NEC VR4121 Graphics controller MQ 200 Memory RAM 64 MB Flash 32 MB (max. number of write cycles 100,000) Operating time Approx. 8 hours with one charge MOBIC T8 for Windows CE 3.0 14-3 C79000-G8976-C190-02...
Page 144 14-6 impact Materials Silicone-free MOBIC T8 power supply unit Construction see mech. data 14-6 Function keys 5 function keys in right side panel, functions of all keys can be freely configured MOBIC T8 for Windows CE 3.0 14-4 C79000-G8976-C190-02...
Page 145 Power supply unit -20 °C to 60 °C Storage/transport max. 85% at 30 °C (with protective cover open Relative humidity and no condensation) Caution Do not expose the MOBIC T8 to direct sunlight. MOBIC T8 for Windows CE 3.0 14-5 C79000-G8976-C190-02...
Page 146 1.7 kg Class of Protection Protective cover: closed IP65 open IP 20 Marks of conformity Marks of conformity CE, UL, CUL, FCC Class A, FM Class I Division II “FM”, e1 approval “e1” MOBIC T8 for Windows CE 3.0 14-6 C79000-G8976-C190-02...
Page 147 0.4 A (when both PCMCIA slots loaded with 600 mA together.) max. current 0.5 A (when both PCMCIA slots loaded with not more than 500 mA.) Data negative Data positive Signal ground MOBIC T8 for Windows CE 3.0 14-7 C79000-G8976-C190-02...
Page 148 Transmit data negative Receive data positive No connection No connection Receive data negative No connection No connection Functional electrical isolation: 500 V (DC) Power supply connection Signal Description +VCC Power supply positive Signal ground MOBIC T8 for Windows CE 3.0 14-8 C79000-G8976-C190-02...
Page 149: Glossary
Messages and other information you send or receive in your mailbox. Flash Non-volatile memory comparable with the hard disk of a PC. Headset Combination of headphones and microphone. Host computer A computer with which a partnership with the MOBIC can be established. MOBIC T8 for Windows CE 3.0 Glossary-1 C79000-G8976-C190-02...
Page 150 A link between your MOBIC and a computer or server at a remote location. Serial cable A cable for connecting your MOBIC to a host computer. Serial connection A cable connection between your MOBIC (RS-232 port) and a serial port (COM) on your host computer. MOBIC T8 for Windows CE 3.0 Glossary-2 C79000-G8976-C190-02...
Page 151 Software for handwriting recognition on your MOBIC. USB (Universal Serial Bus) A standard for connecting peripherals. USB supports relatively high data trans- mission rates and can be used to connect several devices to one computer. MOBIC T8 for Windows CE 3.0 Glossary-3 C79000-G8976-C190-02...
Page 152: Index
Microsoft Pocket Internet Explorer V4.0, 7-3 Microsoft Pocket Outlook, 7-2 Microsoft Pocket Word, 7-2 Miscellaneous tab, 7-17 F1...F5 tab, 7-13 MOBIC Configurator, 7-6, 9-3 FTP server, 6-13 Function keys, 1-8, 2-2, 2-12 assignment, 2-12 MOBIC T8 for Windows CE 3.0 Index-1 C79000-G8976-C190-02...
Page 153 Power supply, 2-4 USB, 1-4, 2-4, 4-6 Power supply unit, 1-9 connecting, 4-14 Protective cover, 2-2 Protective foil, 1-9, 11-5 Volume, 2-14 RAM, 7-7 Warm reset button, 2-11 Reset, 7-20 Reset button, 1-8 MOBIC T8 for Windows CE 3.0 Index-2 C79000-G8976-C190-02...

Siemens MOBIC T8 for Windows CE 3.0 Manual

Preface

1 Overview

2 Design and Functional Elements

3 Accessories

4 Ports

5 Getting Started

6 Data Exchange

7 Supplied Programs and Tools

8 Backup and Restore

9 Changing the Settings of the MOBIC

10 Installing Additional Applications and Drivers

11 Repair, Care, and Maintenance

12 Certificates, Directives, and Declarations

13 Frequently Asked Questions (Faqs)

14 Technical Specifications

Glossary

Index

Quick Links

Related Manuals for Siemens MOBIC T8 for Windows CE 3.0

Summary of Contents for Siemens MOBIC T8 for Windows CE 3.0

Table of Contents
