Fundamental safety instructions Overview Dimension drawings SINUMERIK Operator control and display elements SINUMERIK ONE ONE MCP Part 2: MCP 1500 / MCP Technical data 1500.4c Equipment Manual Valid for: Control system SINUMERIK ONE SINUMERIK 840D sl/840DE sl 09/2024 A5E54099241B AA...
Page 2
Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
Page 3
Table of contents Fundamental safety instructions......................5 General safety instructions....................5 Equipment damage due to electric fields or electrostatic discharge ........8 Warranty and liability for application examples ..............9 Cybersecurity information ....................9 Residual risks of power drive systems ................. 11 Overview..............................
Page 4
Table of contents ONE MCP Part 2: MCP 1500 / MCP 1500.4c Equipment Manual, 09/2024, A5E54099241B AA...
Page 5
Fundamental safety instructions General safety instructions WARNING Electric shock and danger to life due to other energy sources Touching live components can result in death or severe injury. • Only work on electrical devices when you are qualified for this job. •...
Page 6
Fundamental safety instructions 1.1 General safety instructions WARNING Electric shock due to equipment damage Improper handling may cause damage to equipment. For damaged devices, hazardous voltages can be present at the enclosure or at exposed components; if touched, this can result in death or severe injury.
Page 7
Fundamental safety instructions 1.1 General safety instructions CAUTION Symptomatic respiratory and skin reaction to chemicals A newly purchased product might contain traces of substances that are identified as sensitizers. Sensitizers are substances which can cause sensitization in the lungs and skin after exposure to them.
Page 8
Fundamental safety instructions 1.2 Equipment damage due to electric fields or electrostatic discharge WARNING Unexpected movement of machines caused by inactive safety functions Inactive or non-adapted safety functions can trigger unexpected machine movements that may result in serious injury or death. •...
Page 9
Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customer’s exposure...
Page 10
Fundamental safety instructions 1.4 Cybersecurity information Industrial Security Configuration Manual (https://support.industry.siemens.com/cs/ww/en/ view/108862708) WARNING Unsafe operating states resulting from software manipulation Software manipulations, e.g. viruses, Trojans, or worms, can cause unsafe operating states in your system that may lead to death, serious injury, and property damage.
Page 11
Fundamental safety instructions 1.5 Residual risks of power drive systems Residual risks of power drive systems When assessing the machine or system-related risk in accordance with the respective local regulations (e.g. EC Machinery Directive), the machine manufacturer or system integrator must take into account the following residual risks emanating from the control and drive components of a drive system: 1.
Page 12
Fundamental safety instructions 1.5 Residual risks of power drive systems 6. Influence of network-connected and wireless communications systems, e.g. ripple-control transmitters or data communication via the network or mobile radio, WLAN or Bluetooth. 7. Motors for use in potentially explosive areas: When moving components such as bearings become worn, this can cause enclosure components to exhibit unexpectedly high temperatures during operation, creating a hazard in areas with a potentially explosive atmosphere.
Page 13
Overview This manual describes the specific properties of the SINUMERIK ONE MCP 1500 machine control panel. The documentation is always structured in 2 parts. Part 1 contains general information that applies to all machine control panels. Part 2 covers specifics of individual machine control panels.
Page 14
Overview ONE MCP Part 2: MCP 1500 / MCP 1500.4c Equipment Manual, 09/2024, A5E54099241B AA...
Page 15
Dimension drawings Plus wiring portion Figure 3-1 Front, rear and side view of MCP 1500 (all specifications in mm) The installation clearance for the MCPs is 70 mm including the wiring portion. Panel cutout The MCP 1500 is attached to the rear side of the operator panel using 8 tension jacks (contained in the scope of delivery).
Page 16
Dimension drawings ONE MCP Part 2: MCP 1500 / MCP 1500.4c Equipment Manual, 09/2024, A5E54099241B AA...
Page 17
Operator control and display elements Front side Overview ① Emergency stop ② Keypad 1 (operating mode block) ③ Keypad 2 (axis block) ④ Powerride 2 (spindle) + keypad 2.2 ⑤ Powerride 1 (feed) + keypad 2.1 ⑥ 4x mounting space for 22.5 mm element ⑦...
Page 18
Operator control and display elements 4.2 Rear side Rear side ① Power supply interface X10 ② Switch S2 ③ Ethernet interfaces X20 port 1/ port 2 ④ Emergency stop ⑤ Handwheel connections X60/ X61 ⑥ Protective conductor connection ⑦ Interface of the customer-specific inputs/outputs X516 ⑧...
Page 19
Operator control and display elements 4.3 Configuration Configuration Input image Slot 1 Base Slot 2 Keypad 1 (operating mode block), keypad 1.1 and keypad 1.2 Slot 3 Keypad 2 (axis block), keypad 2.1 and keypad 2.2 Slot 4 Powerride 1 (feed) Slot 5 Powerride 2 (spindle) Slot 6...
Page 20
Operator control and display elements 4.3 Configuration ONE MCP Part 2: MCP 1500 / MCP 1500.4c Equipment Manual, 09/2024, A5E54099241B AA...
Page 21
Technical data MCP 1500 / MCP 1500.4c Safety Safety class according to III; PELV EN 50178 Degree of protection according Front: IP65 Keyswitch: IP54 Rear: IP00 to EN 60529 Approvals CE / EAC / UL / UKCA Flame resistance UL 94 V-1 UL identifier MCPS2101-398225E-0402051AA0 Electrical data...
Page 22
Technical data MCP 1500 / MCP 1500.4c Temperature limit values (stor‐ -40 ... 70 °C (cyclic) age) Temperature limit values (opera‐ 0 ... 45 °C (front) tion) 0 ... 55 °C (rear) Temperature change Max. 30 K/h Relative humidity 5 ... 90% (without condensation) Permissible change in the rela‐...
Page 23
Technical data Note In a residential environment, this product can cause high-frequency radio interference, which may make interference suppression measures necessary. • Have the installation and commissioning with appropriate radio interference suppression measures performed by qualified personnel. Note Damage to components by coolants and lubricants The SINUMERIK operator components have been designed for industrial use, particularly on machine tools and production machines.
Page 24
Technical data ONE MCP Part 2: MCP 1500 / MCP 1500.4c Equipment Manual, 09/2024, A5E54099241B AA...
Page 25
Index MCP 1500 EMERGENCY STOP pushbutton, 23 Technical specifications, 21 Current consumption, 21 Power consumption, 21 ONE MCP Part 2: MCP 1500 / MCP 1500.4c Equipment Manual, 09/2024, A5E54099241B AA...
Page 26
Index ONE MCP Part 2: MCP 1500 / MCP 1500.4c Equipment Manual, 09/2024, A5E54099241B AA...
