INSTALLER INSTRUCTIONS
CONTENTS
1
DESCRIPTION OF THE BOILER .......................................................................................................... pag.
2
INSTALLATION ................................................................................................................................... pag.
3
CHARACTERISTICS ............................................................................................................................ pag. 102
4
USE AND MAINTENANCE .................................................................................................................. pag. 109
Our Company declares that MURELLE HM ErP boilers comply with the essential requirements of the fol-
lowing directives:
- Boiler Efficiency Directive 92/42/EEC
- Gas Appliances Directive 2009/142/EC up to 20/04/18 and Gas Regulation 2016/426/EC from 21/04/18
- Electromagnetic Compatibility Directive 2014/30/UE
- Low Voltage Directive 2014/35/UE
- Ecodesign Directive 2009/125/EC
- Regulation (EU) N. 813/2013 - 811/2013
- Energy Labelling 2010/30/EC
When carrying out commissioning of the boiler, you are highly recommended to perform the following checks:
– Make sure that there are no liquids or inflammable materials in the immediate vicinity of the boiler.
– Make sure that the electrical connections have been made correctly and that the earth wire is connected to
a good earthing system.
– Open the gas tap and check the soundness of the connections, including that of the burner.
– Make sure that the boiler is set for operation for the type of gas supplied.
– Check that the flue pipe for the outlet of the products of the combustion is unobstructed and has been pro-
perly installed.
– Make sure that any shutoff valves are open.
– Make sure that the system is charged with water and is thoroughly vented.
– Check that the circulating pump is not locked.
– Purge the system, bleeding off the air present in the gas pipe by operating the pressure relief valve on the
gas valve inlet.
– The installer must provide the user with instruction in operation of the boiler and safety devices and hand over
the instruction booklet to the user.
CONFORMITY
IMPORTANT
80
84

Advertisement

loading
Need help?

Need help?

Do you have a question about the MURELLE HM 25 ErP and is the answer not in the manual?

Questions and answers

Related Manuals for Sime MURELLE HM 25 ErP

Summary of Contents for Sime MURELLE HM 25 ErP

  • Page 1 INSTALLER INSTRUCTIONS CONTENTS DESCRIPTION OF THE BOILER ......................pag. INSTALLATION ........................... pag. CHARACTERISTICS ..........................pag. 102 USE AND MAINTENANCE ........................pag. 109 CONFORMITY Our Company declares that MURELLE HM ErP boilers comply with the essential requirements of the fol- lowing directives: - Boiler Efficiency Directive 92/42/EEC - Gas Appliances Directive 2009/142/EC up to 20/04/18 and Gas Regulation 2016/426/EC from 21/04/18 - Electromagnetic Compatibility Directive 2014/30/UE...

  • Page 2: Description Of The Boiler

    DESCRIPTION OF THE BOILER INTRODUCTION control and manage all the functions. tees maximum D.H.W. comfort. The wide field of modulation of the heat power (from 10% to 100%), decreases the For optimum installation and operation, MURELLE HM ErP are premixed gas con- densation thermal modules that employ switch-on and off cycles and, in case of always follow the instructions provided in...
  • Page 3 TECHNICAL FEATURES MURELLE HM 25 ErP 30 ErP 35 ErP 25 T ErP 35 T ErP Heat output Nominal (80-60°C) (Pn max) 23.9 28.9 34.1 23.9 34.1 Nominal (50-30°C) (Pn max) 26.2 31.4 37.2 26.2 37.2 Reduced G20 (80-60°C) (Pn min) Reduced G20 (50-30°C) (Pn min) Reduced G31 (80-60°C) (Pn min) Reduced G31 (50-30°C) (Pn min)
  • Page 4 FUNCTIONAL DIAGRAM (fig. 2) MURELLE HM 25 - 30 - 35 ErP Limit thermostat Primary exchanger Gas valve D.H.W. exchanger Aqua Guard Filter System C.H. flow sensor (SM) Safety thermostat 100°C Diverter valve Pump high efficiency C.H return sensor (SR) D.H.W.
  • Page 5 MAIN COMPONENTS (fig. 3) 1 Control panel 2 Aqua Guard Filter System 3 Condensate drain tap 4 Air pressure tap 6 Safety thermostat 7 C.H. flow sensor (SM) 8 Ignition electrode 9 Primary exchanger 10 Sensor fumes (SF) 11 Suction/discharge fitting 12 Expansion vessel 13 Detection electrode 14 Fan...

  • Page 6: Control Panel

    INSTALLATION The boiler must be installed in a fixed loca- 15502, with a maximum ambient tempe- code 8092243. tion and only by specialized and qualified rature of 60°C and a minimum ambient ATTENTION: In sequence/cascade instal- firms in compliance with all instructions temperature of -5°C.
  • Page 7 Fig. 4/b...
  • Page 8 MODBUS mode (fig. 4/c) - Set the DIP SWITCH of the RS-485 board CASCADE+MODBUS mode (fig. 4/d) and the PAR 16 as indicated in the figure. The RS-485 board can be used for MODBUS This mode allows for MODBUS communi- communication of every MURELLE HM 25 - Choose the communication configuration cation of at least two boilers in cascade and...
  • Page 9 TABELLA DELLE VARIABILI MODBUS / MODBUS BOILER VARIABLES LIST Descrizione / Function Variable description Digital variables (COILS) Request CH zone 1 Boiler CH Enable/Request D R/W Richiesta riscaldamento zona 1 Boiler DHW Enable D R/W Abilitazione preparazione ACS Enable DHW preparation Boiler Water Filling Function D R/W Non usato...
  • Page 10 ATTENTION: Communication will occur only with the MASTER boiler, (boiler with CONNETTORE CABLATO PAR 15 = 0), interpreting the cascade as a (cod. 6319173) single heat capacity generator: WIRED CONNECTOR x No. (cod 6319173) CASCADE BOILER BOILERS To install the second board, proceed as follows: - Remove the cover and electrically con- nect the second RS-485 board equipped...
  • Page 11 - the boiler is correctly connected to the during interventions. If the heating system 2.3.2 Filter on the gas pipe gas and electricity supply circuits; is on a higher floor than the boiler, install - the boiler is constantly fed; the on/off taps supplied in kit optional on The gas valve is supplied ex factory with an - the boiler ignition is not blocked;...
  • Page 12 INSTALLATION OF SEPARATE - The kits with dedicated ø 60 pipes, code (ATTENTION: the total length of each pipe DUCTS ø 80 - ø 60 8089913, include a suction collar that should not exceed 25 m, even if the total replaces the boiler collar (C).
  • Page 13 exhaust flange (pos. 2 fig. 7) when the 2.6.1 Separate ducts kit (fig. 9) 2.6.2 Connection to total load loss of the separate ducts is existing flues below H2O (do not use the diaphragm The diagrams of figure 9 show a few with total load losses above 9 mmH20 up examples of the permitted exhausts con- The ø...
  • Page 14 IMPORTANT: In type C53 the outlet and inlet flues must not come out on opposite walls. max 0,5 m LIST OF ø 80 ACCESSORIES Coaxial duct kit code 8089912 Additional 90° MF curve code 8077450 (6 pz.) Extension L. 1000 code 8077351 (6 pz.) Extension L.
  • Page 15 When the boiler runs at low temperature, it is possible to use standard flues provi- ded that: - The flue is not be used by other boilers. - The interior of the flue is protected to prevent a direct contact with conden- sation from the boiler.
  • Page 16 Some examples are given below of boiler SYSTEM WITH A DIRECT ZONE AND ROOM THERMOSTAT, OR WITH systems combined with different electro- REMOTE CONTROL SIME HOME (Code 8092280/81) AND EXTERNAL nic systems. Where necessary, the para- SENSOR (supplied with) meters to be set in the boiler are given.
  • Page 17 MULTI-ZONE SYSTEM WITH PUMP, ROOM THERMOSTAT AND EXTERNAL SENSOR (supplied with) BASIC SYSTEM MULTI-ZONE SYSTEM WITH PUMP, ROOM THERMOSTAT AND EXTERNAL SENSOR (supplied with) BASIC SYSTEM MULTI-ZONE SYSTEM WITH VALVE, ROOM THERMOSTAT, REMOTE CONTROL SIME HOME (Code 8092280/81) AND EXTERNAL SENSOR (supplied with) PARAMETERS SETTINGS To use the remote control...
  • Page 18 BASIC SYSTEM MULTI-ZONE SYSTEM WITH VALVE, ROOM THERMOSTAT, REMOTE CONTROL SIME HOME (Code 8092280/81) AND EXTERNAL SENSOR (supplied with) PARAMETER SETTING To use the remote control SIME HOME (CR) as room refe- rence for a zone, set: PAR 7 = 1...
  • Page 19 SYSTEM WITH DOUBLE TEMPERATURE OUTPUT MULTI-ZONE SYSTEM WITH PUMP, CHRONOTHERMOSTAT AND EXTERNAL SENSOR (supplied with) NIGHT ZONA ZONA GIORNO NOTTE ZONE ZONE (50°C) (70°C) (50°C) (70°C) SYSTEM WITH REMOTE BOILING UNIT PARAMETER SETTING MURELLE HM 25 T - 35 T ErP with D.H.W sensor to be set: PAR 2 = 3 MURELLE HM 25 T - 35 T ErP...
  • Page 20 SYSTEM WITH MIXER VALVE SYSTEM WITH ONE DIRECT ZONE, ONE MIXED ZONE, ONE KIT ZONA MIX (Code 8092234), REMOTE CONTROL SIME HOME (Code 8092280/81) AND EXTERNAL SENSOR (supplied with) PARAMETERS SETTINGS To use the remote control SIME HOME (CR) as remote...
  • Page 21 SENSOR (supplied with) SYSTEM SOLAR SYSTEM WITH TWO MIXED ZONES INDEPENDENT, ONE DIRECT ZONE, WO KITS ZONA MIX (Code 8092234), ONE KIT SOLAR INSOL (Code 8092235), REMOTE CONTROL SIME HOME (Code 8092280/81) AND EXTERNAL SENSOR (supplied with) Murelle HM T ErP...
  • Page 22 Pump high efficiency Selection TA2 or 0-10 VDC CN1/13 code 6319146 SB/SA D.H.W. sensor/drain tap antifreeze code 6319144 Limit thermostat Remote control SIME HOME (optional) code 6319145 Ignition electrode External sensor (supplied with) code 6316203 Detection electrode Programming clock (optional)
  • Page 23 CN1/13 code 6319146 Zone 2 environment thermostat code 6323886 Limit thermostat Solar heat sensor code 6319145 Ignition electrode Remote control SIME HOME (optional) code 6316203 Detection electrode External sensor (supplied with) code 6316202 EV1-2 Gas valve coil Programming clock (optional)

  • Page 24: Characteristics

    PC CONNECTION OFF = Electricity supply to boiler is on but nor To be used only with the SIME programming kit and only ready for functioning. However, the protec- by authorised personnel. Do not connect other electronic tion functions are active.

  • Page 25: C.h. Flow Sensor (Sm

    ACCESS TO INSTALLER’S INFORMATION For access to information for the installer, press the key (3 fig. 14). Every time the key is pressed, the display moves to the next item of information. If the key is not pressed, the system automatically quits the function. If there is no expansion board (ZONA MIX or INSOL) the relative info shall not be displayed.
  • Page 26 18. Visualisation C.H. return sensor value (SR) 29. Visualisation valve closing opening control with board ZONA MIX 18. Visualizzazione valore sonda ritorno riscaldamento (SR) 29. Visualizzazione comando chiusura valvola con schedino 2 (respectively ON and OFF) ZONA MIX 2 (rispettivamente ON e OFF) 30.
  • Page 27 The standard visualisation returns auto- of voltage 1 = Enabled matically after 60 seconds, or by pres- Allocation of SIME HOME channels 0 = Not assigned 1 = Circuit 1 sing one of the control keys (2 fig. 12) 2 = Three-zone circuit excluded the key RESET.
  • Page 28 BOILER PAR 2 PARAMETERS INSTALLER Instant with deviator valve and flowmeter EXPANSION CARD Instant with deviator valve, flowmeter and solar combination PAR DESCRIPTION RANGE UNIT OF INC/DEC DEFAULT MEASUREMENT UNIT SETTING D.H.W. tank with Number of expansion boards 0 ... 3 deviator valve and boiler sensor Mix valve stroke time 0 ...

  • Page 29: Ignition Electrode

    12.090 – Interface with the following electronic It can be caused by a closed gas tap or 8.313 systems: remote control SIME HOME by a broken valve coil (the interruption 5.828 code 8092280/81, thermal regulator does not allow for opening).
  • Page 30 The electronic board is faulty. HEAD AVAILABLE lating pump WILO-YONOS PARA PWM is TO SYSTEM (fig. 14) set as default (installation parameter PAR In the case of a sudden lack of voltage, the 13 = Au). burner will immediately switch off. When Residual head for the heating system is voltage returns, the boiler will automati- shown as a function of rate of flow in the...

  • Page 31: Gas Valve

    8,4 ±0,2 10,0 ±0,3 This operation must be performed by MODELS PAR 1 authorised personnel using original Sime 6) Press the buttons several times to components. check the pressures change them if required. To convert from natural gas to LPG or vice...
  • Page 32 Codice/Code 8112440 Modello/Model MURELLE HM 25 ErP Matricola/Serial n. 9999999999 PAR 1 = 1 (G20) / 9 (G31) PAR 2 = 1 ATTENTION Before removing or refitting the front panel of the boiler, open the small upper plastic door. Fig. 19...
  • Page 33 the boiler will function at maximum power with the D.H.W. circuit kept at between 60°C and 50°C. During the test, the hot water faucets must remain open. If the key are pressed during the 15 minutes of the chimney sweep fun- ction, the boiler will be brought respecti- vely to maximum and minimum power.
  • Page 34 4.5.4 WILO-YONOS PARA PWM pump diagnose and remedy (fig. 22/b) LED diagnose and remedy Led color Meaning Diagnostic Cause Remedy Continuous green Normal running Pump run as Normal operation expected or is faced to a phenomenon that shortly affects its running Red/green blinking Abnormal situation Pump will restart...

  • Page 35: Limit Thermostat

    – D.H.W. SENSOR ANOMALY ALARM 04 – SAFETY THERMOSTAT the presence of water inside the prima- MIT THERMOSTAT ANOMALY ALARM ry circuit; it then stops showing on the (fig. 23/3) If the D.H.W. sensor (SS) is open or 07 (fig. 23/6 display the ALL 09 anomaly.
  • Page 36 – ACTIVATION “ALL 13” boiler continues normal functioning. When it results that the ZONA MIX bo- EXHAUST FUMES PROBE (fig. 23/10) ard is connected to the boiler and the delivery probe is open or short circuited The activation of this probe causes the boiler to stop and error message ALL on the display the anomaly ALL 23 ap- 13 to display.
  • Page 37 When a probe is connected instead of a splayed. scade connection, error codes 70 and 71 will appear on the SIME HOME remote clean contact on entry S3 the board on The boiler restarts when the boiler display shows the anomaly ALL 28. Du-...
  • Page 38 USER INSTRUCTIONS WARNINGS – In case of failure or malfunction of the equipment, contact authorised technical staff. – For safety reasons, the User cannot access the internal parts of the appliance. All opera- tions involving the removal of protections or otherwise the access to dangerous parts of the appliance must be performed by qualified personnel.
  • Page 39 REGULATION OF THE WATER TEMPE- RATURE FOR HEATING (fig. 25) To set the temperature of the water for heating, press the key of the controls Circuito riscaldamento 2 (2). The first time the key is pressed, the Heating circuit 2 SET of heating circuit 1 is selected.
  • Page 40 SIME HOME remote control display. to check the seal of the heating sy- If the anomaly persists, request assi- Request assistance from qualified stem (to check whether there are any stance from qualified technical per- technical personnel.
  • Page 41 APPENDIX DETALLES DEL PRODUCTO / DETALHES DO PRODUTO / PRODUCT DETAILS Murelle HM 25 ErP 30 ErP 35 ErP Profilo sanitario di carico dichiarato Perfil de carga declarado en agua sanitaria Perfil sanitário de carga declarado D.H.W load profile declared Classe efficienza energetica stagionale riscaldamento Clase de eficiencia energética estacional en calefacción Classe de eficiência energética do aquecimento ambiente sazonal...
  • Page 42 Daily fuel consumption Recapiti / Datos de contacto Fonderie Sime S.p.A. Via Garbo 27, 37045 Legnago (VR) ITALIA Elementos de contacto / Contact details a. Regime ad alta temperatura: temperatura di ritorno di 60°C all’entrata e 80°C di temperatura di fruizione all’uscita dell’apparecchio b.
  • Page 43 Daily fuel consumption Recapiti / Datos de contacto Fonderie Sime S.p.A. Via Garbo 27, 37045 Legnago (VR) ITALIA Elementos de contacto / Contact details a. Regime ad alta temperatura: temperatura di ritorno di 60°C all’entrata e 80°C di temperatura di fruizione all’uscita dell’apparecchio b.
  • Page 44 Daily fuel consumption Recapiti / Datos de contacto Fonderie Sime S.p.A. Via Garbo 27, 37045 Legnago (VR) ITALIA Elementos de contacto / Contact details a. Regime ad alta temperatura: temperatura di ritorno di 60°C all’entrata e 80°C di temperatura di fruizione all’uscita dell’apparecchio b.
  • Page 45 Daily fuel consumption Recapiti / Datos de contacto Fonderie Sime S.p.A. Via Garbo 27, 37045 Legnago (VR) ITALIA Elementos de contacto / Contact details a. Regime ad alta temperatura: temperatura di ritorno di 60°C all’entrata e 80°C di temperatura di fruizione all’uscita dell’apparecchio b.
  • Page 46 Daily fuel consumption Recapiti / Datos de contacto Fonderie Sime S.p.A. Via Garbo 27, 37045 Legnago (VR) ITALIA Elementos de contacto / Contact details a. Regime ad alta temperatura: temperatura di ritorno di 60°C all’entrata e 80°C di temperatura di fruizione all’uscita dell’apparecchio b.
  • Page 47 NOTES...
  • Page 48 NOTES...
  • Page 50 Fonderie Sime S.p.A - Via Garbo, 27 - 37045 Legnago (Vr) Tel. +39 0442 631111 - Fax +39 0442 631292 - www.sime.it...

This manual is also suitable for:

Murelle hm 30 erpMurelle hm 35 erpMurelle hm 25 t erpMurelle hm 35 t erp
