Intex GRAPHITE GRAY PANEL POOL SET Owner's Manual page 11

POOL SETUP (continued)
• Next slide the vertical legs into the belt loop located in the middle of
the pool liner. Carefully slide the leg into the belt loop and insert the
top of the leg into the bottom of the joint.
Snap the leg into the joint's holes by aligning the holes and the
spring-loaded pin. Attach the leg's end cap (6) to the bottom of the
leg (see drawings 6.1 & 6.2).
• Upon connecting the last leg, grab hold of the frame pool's top beams
in 2 – 3 locations. Shake the pool to be sure that all the joints, legs
and beams fit into each other. Ensure that all pins are in position by
pushing them downwards through the holes (see drawing 7.1).
• Pull gently, in an outward direction, the bottom of the leg making sure
the leg is vertical and perpendicular to the level ground.
3. Filling of the pool
• See Krystal Clear™ filter pump manual, install the strainer nuts, flat
strainer rubber washers and threaded strainer connectors on the liner
pre-cut holes. Use strainer valve caps (19) and plug them into the
threaded strainer connectors from the inside of the pool so water will not run out while filling.
• Before filling the pool with water, ensure that the drain plug inside the pool is closed and that the drain
cap on the outside is screwed on tightly. Fill the pool with no more than 1 inch (2.5 cm) of water. Check
to see whether the water is level.
IMPORTANT: If the water in the pool flows to one side, the pool is not completely level. Setting up
the pool on unlevel ground will cause the pool to tilt resulting in the sidewall material bulging and
a potential collapse of the pool. If the pool is not completely level, you must drain the pool, level
the area or move the pool to a different area that is level, and re-fill the pool, following the above
directions.
• Smooth out the bottom liner wrinkles (from inside the pool) by pushing out where the pool floor and pool
sides meet. Or, (from outside pool) reach under the side of the pool, grasp the pool floor and pull in
an outward direction. If the ground cloth is causing the wrinkles, have 2 people pull from opposite sides to
remove all wrinkles. Use the properly assembled pool ladder when entering or exiting the pool during this
process.
4. Fill the pool with water up to just below the sleeve line.
(see drawing 7.2).
SAVE THESE INSTRUCTIONS
(120IO) SEQUOIA SPIRIT™ WOOD-GRAIN FRAME POOL ENGLISH 7.5" X 10.3" PANTONE 295U 05/26/2016
English
3
5
6.2
6.1
6
7.1
WATER LEVEL
Page 11
120A
4
7.2
