Intex Ultra XTR Owner's Manual
  1. Manuals
  2. Brands
  3. Intex Manuals
  4. Swimming Pool
  5. Ultra XTR
  6. Owner's manual

Intex Ultra XTR Owner's Manual

157-1/2” x 78-3/4” x 39-3/8” (400 cm x 200 cm x 100 cm), 118-1/8” x 68-3/4” (300 cm x 175 cm), 15' x 9' (457 cm x 274 cm), 16' x 8' (488 cm x 244 cm), 18' x 9' (549 cm x 274 cm), 24' x 12' (732 cm x 366 cm), 32' x 16' (975 cm x 488 cm)
