SPECTRA POWERBOX 210‐
SERIES
USER MANUAL
Version 1.0 – April 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Powerbox 210 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Spectra Powerbox 210 Series

Summary of Contents for Spectra Powerbox 210 Series

  • Page 1 SPECTRA POWERBOX 210‐ SERIES USER MANUAL Version 1.0 – April 2019...

  • Page 2: Table Of Contents

    3.7 Installing the Chassis ………….…………..………..….……………..36 3.8 Installing the Chassis Bottom Cover …..…………..….……………... 37 3.9 Installing a SIM Card ………………………………..…………………. 38 3.10 Installing Wall Mount Brackets ..……….…………….……………..3.11 Installing DIN-Rail Mount Clips……………………………………….. 40 Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 3 6.10 Installing a PB-210-DIO Module .…………..…………………………..94 6.11 Installing a PB-210-IGN Module .…………..…………………………..96 6.12 Installing a PB-210-PoE Module .……..…………………………..….. 97 6.13 Installing a Side Mount Bracket ……………………………………… 99 6.14 Installing a VESA Mount Bracket…………………………………….. 101 Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 4: Revision

    2019/04/09 Copyright Notice © 2019 by Spectra GmbH & Co. KG. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Spectra GmbH &...

  • Page 5: Product Warranty Statement

    (such as a fuse, battery, etc.), are not warranted. Before sending your product in, you will need to fill in a Spectra RMA Request Form and obtain a RMA number from us. Please go to www.spectra.de/RMA...

  • Page 6: Technical Support And Assistance

    This indication alerts operators to an operation that, if not strictly observed, may result in safety hazards to personnel or damage to equipment. This indication provides additional information to complete a task easily. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 7: Safety Precaution

     The equipment has been dropped and damaged.  The equipment has obvious signs of breakage. 14. CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 8: Package Content

    Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty Spectra PowerBox 210 Utility DVD Driver Thermal Pad (for CPU Thermal Block) Power Terminal Block Connector Screw Pack Remote Power On/Off Terminal Block Connector...

  • Page 9: Optional Modules And Accessories

    Mini-PCIe Module with 2x LAN Ports,1x Universal Bracket with 2x RJ45 Cutout for Spectra PowerBox 210 M002 Side Mount Kit for Spectra PowerBox 210 Series, with KMRH-K175 for DIN- PB-210-SIDE-KIT Rail option Adapter AC/DC 12V 5A 60W, wide temp(-30 ° C ~ +70 ° C) Netzteil, 60W/12, 3pin Adapter AC/DC 24V 5A 120W, wide temp(-30 °...

  • Page 10: Chapter 1 Product Introductions

    Chapter 1 Product Introductions...

  • Page 11: Overview

    (PoE) even the third output of video for a variety of applications. Featuring with rigorous industrial protections, wide temperature range, and wide range DC power input, the Spectra PowerBox 210 offers a powerful, expandable computing platform to ensure long-lasting performance and reduce maintenance costs.

  • Page 12: Product Pictures

    • 2 x Full Size Mini-PCIe Socket, 2 x SIM Card Socket • Compact Size (185 x 131 x 56.5 mm) • Wide Operating Temperature -40°C to 70°C • E-mark (E13,), LVD EN60950-1 Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 13: Hardware Specification

    • 2x SIM Card Socket • 2x Antenna Hole Other Functions • Watchdog Timer: Software Programmable Supports 256 Levels System Reset • SuperCap Integrated for CMOS Battery Maintenance-free Operation • Supports Instant Reboot Technology (0.2 sec) Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 14: System I/O

    Used to set up IGN function Used to connect USB 3.0/2.0/1.1 device Clear CMOS LAN Port 1 & 2 Used to clear CMOS to reset BIOS Used to connect the system to a local area network Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 15 COM / DIO / DVI / VGA / HDMI modules. Do not change the CMI module by yourself, it may cause damage to your Spectra Do not change the CMI module by yourself, it may cause damage to your Spectra PowerBox 210.

  • Page 16: Mechanical Dimension

    1.7 Mechanical Dimensions Unit: mm Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 17: Chapter 2 Switches And Connectors

    Chapter 2 Switches and Connectors...

  • Page 18: Jumper Settings

    2.1 Jumpers Settings The Spectra PowerBox 210 is featured with jumper-free design 2.2 Location of the Switches and Connectors 2.2.1 Top View Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 19: Bottom View

    2.2.2 Bottom View Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 20: Switch And Connector Definition

    SIM Card Sockets (apply with MINIPCIE1) CMI BTB 50-pin header connector BTB_FH1 (Support DVI-D/VGA/HDMI/DIO/COM Ports) CMI BTB 44-pin header connector BTB_FH2 (Support DIO/COM Ports) IGN_PH1 IGN Board to Board Connector POE_PH2 20-pin POE Board to Board Connector Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 21: Definition Of Switches

    CLR_CMOS : Clear CMOS Switch Switch Definition 1-2 (Left) Clear CMOS 2-3 (Right) Normal Status (Default) POWER_LED1: Power Status LED Power Status LED Color POWER ON Green HDD_LED1: HDD Status LED HDD Status LED Color Yellow Read/Write Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 22 Function Setting via DIP Switch Location Function DIP1 DIP2 Enabled ON (Default) SUPER Disabled Location Function DIP3 DIP4 0V(RI) ON (Default) ON (Default) COM1 Location Function DIP5 DIP6 0V(RI) ON (Default) ON (Default) COM2 Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 23: Definition Of Connectors

    +1.5V SMB_CLK PETn0 1.5V SMB_DATA UIM_RESET_B PETp0 UIM_PWR_A UIM_DATA_A USB_D- REFCLK- UIM_CLK_A USB_D+ +3.3Vaux REFCLK+ / UIM_PWR_B UIM_RESET_A +3.3Vaux UIM_VPP_A UIM_IC_DM / (UIM_CLK_B) UIM_IC_DP / (UIM_DATA_B) W_DISABLE1# PERST# +1.5V PERn0 +3.3Vaux PERp0 +3.3Vaux Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 24 MINIPCIE2 : Mini PCI-Express Socket (Support mPCIE & mSATA) Definition Definition WAKE# 3.3V +1.5V SMB_CLK PETn0 / SATA_TXN 1.5V SMB_DATA PETp0 / SATA_TXP USB_D- REFCLK- USB_D+ +3.3Vaux REFCLK+ +3.3Vaux W_DISABLE1# PERST# +1.5V PERn0 / SATA_RXP +3.3Vaux PERp0 / SATA_RXN +3.3Vaux Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 25 LAN1 / LAN2: LAN LED Status Definition Act LED Status Definition Blinking Yellow Data Activity No Activity Link LED Status Definition Steady Green 1Gbps Network Link Steady Orange 100Mbps Network Link 10Mbps Network Link Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 26 RS422 / 485 Full RS485 Half RS232 Definition Duplex Definition Duplex Definition 1                  5 DATA - 6              9  DATA + 1                  5 6              9  POWER1, POWER2 : Power Connector Connector Type: 1x4 4-pin Wafer, 2.0mm pitch Definition Pin 1 +12V Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 27: Chapter 3 System Setup

    Chapter 3 System Setup...

  • Page 28: Removing The Chassis Bottom Cover

    1. Turn over the unit to have the bottom side face up, loosen the 4 screws of bottom cover and place them aside. 2. Remove the cover from the chassis. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 29: Removing The Chassis

    3.2 Removing the Chassis 1. Hold front and rear panel and lift up the body of unit vertically. 2. Turn over the body of the unit and place it gently. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 30: Installing Antennas

    3.3 Installing Antennas 1. Remove the antenna hole covers at rear panel. 2. Have antenna jack penetrate through the hole. 3. Put on washer and fasten the nut with antenna jack. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 31 4. Assemble the antenna and antenna jack together. 5. Attach the RF connector at another end of cable onto the module. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 32: Installing Full-Size Mini Pcie Cards On Bottom Side

    1. Turn over the body of unit. Unscrew the 3 screws on HDD bracket and remove the bracket. 2. Locate the Mini PCIe slots. Please note that the upside connector (MINIPCIE2) is shared mSATA/Mini-PCIe interface, and downside connector (MINIPCIE1) is Mini-PCIe interface which supports SIM Card to Link feature. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 33 45° 4. Press down the module and use two screws to fix a module. 5. If you have a Half-size Mini-PCIe card, make sure use extender to make it Full-size as shown below. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 34: Installing A Sata Hard Drive

    4 provided screws to assemble HDD and HDD bracket together. 3. Turn over the HDD bracket. Connect the HDD bracket to the SATA connector of the unit and fasten the 3 screws. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 35: Installing A Sodimm

    2. Tilt the SODIMM module at a 45 degree angle and insert it to SODIMM socket until the gold-pated connector of module contacted firmly with the socket. 45° 3. Press the module down until it’s fixed firmly by the two locking latches on the sides. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 36: Installing The Chassis

    3.7 Installing the Chassis 1. Hold the body of unit, and make sure the both sides of front and rear panels are in the chassis grooves and insert the body of unit into chassis. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 37: Installing The Chassis Bottom Cover

    3.8 Installing the Chassis Bottom Cover 1. Level the grooves on the cover at front and rear panels. Put on the cover. 2. Fasten the 4 screws to fix the cover. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 38: Installing A Sim Card

    3.9 Installing a SIM Card 1. Loosen 2 screws on the front panel to remove the cover plate. 2. SIM card slots are at the front panel of the system. 3. Insert the SIM card. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 39: Installing Wall Mount Brackets

    3.10 Installing Wall Mount Brackets offers Wall Mount that customers can install system on the The Spectra PowerBox 210 wall in convenient and economical way. 1. The mounting holes are at the bottom side of system. Use provided 4 screws to fasten the bracket with each side on system together.

  • Page 40: Installing Din-Rail Mount Clips

    3.11 Installing DIN-Rail Mount Clips The Spectra PowerBox 210 series offers DIN-Rail Mount that customer can install system on the DIN Rail. 1. Please refer to section 3.10 Wall Mount Brackets to install mounting bracket at both sides of system.

  • Page 41: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup...

  • Page 42: Bios Introduction

    ( ↑↓ ) to highlight the field and press <Enter> to call up the sub-menu. Then you can use the control keys to enter values and move from field to field within a sub-menu. If you want to return to the main menu, just press the <Esc >. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 43: Main Setup

    Use arrow keys to move among the items and press <Enter> to accept or enter a sub-menu. ■ System Date Set the date. Please use <Tab> to switch between date elements. ■ System Time Set the time. Please use <Tab> to switch between time elements. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 44: Advanced Setup

    4.3 Advanced Setup This section allows you to configure and improve your system and allows you to set up some system features according to your preference. 4.3.1 ACPI Settings Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 45: F81866 Super Io Configuration

    ■ Lock Legacy Resources [Enabled] Enables or disables Lock Legacy Resources. 4.3.2 F81866 Super IO Configuration Set Parameters of Serial Ports. User can Enable/Disable the serial port and Select an optimal settings for the Super IO Device Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 46 ■ Watch Dog Mode [Sec] Allows to set watchdog timer unit <Sec> or <Min>. ■ Watch Dog Timer [0] Allows you to set watchdog timer’s value in the range of 0 to 255. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 47: Hardware Monitor

    4.3.3 Hardware Monitor This screen displays the current status of all monitored hardware devices/components such as voltages, temperatures. 4.3.4 S5 RTC Wake Settings Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 48: Serial Port Console Redirection

    [Dynamic Time]: Sets a increase minute(s) from current time to wake system from 4.3.5 Serial Port Console Redirection ■ Console Redirection [Disabled] Allow users to enable or disable COM1, COM2, COM3, COM4, COM5, COM6 console redirection function. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 49: Cpu Configuration

    Enables or disables Intel Virtualization Technology. Virtualization enhanced by Intel Virtualization Technology will allow a platform to run multiple operating systems and applications in independent partitions. With virtualization, one computer system can function as multiple virtual systems. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 50: Network Stack Configuration

    4.3.7 Network Stack Configuration ■ Network Stack [Disabled] Enables or disables UEFI Network Stack. 4.3.8 CSM Configuration This option controls legacy/UEFI ROMs priority. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 51 [UEFI]: Enables UEFI option ROM only. [Legacy]: Enables legacy option ROM only. ■ Other PCI devices [Do not launch] Allows users to determine option ROM execution policy for devise other than network, storage, or video. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 52: Usb Configuration

    Enables or disables XHCI (USB3.0) hand-off function. Use this feature as a workaround for operating systems without XHCI hand-off support. ■ USB Mass Storage Driver Support [Enabled] Enables or disables USB mass storage driver support. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 53: Chipset Setup

    4.4 Chipset Setup This section allows you to configure chipset related settings according to user’s preference. 4.4.1 North Bridge This section provides information on the installed memory size. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 54: South Bridge

    Allows you to change Mini PCIE2 to [Mini PCIE] or [mSATA]. ■ PSE Enable Selection [Enabled] Enables or disables PSE (Power Sourcing Equipment). ■ LAN1 [Enabled] Enables or disables LAN1 Controller. ■ LAN2 [Enabled] Enables or disables LAN2 Controller. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 55: South Cluster Configuration

    4.4.3 South Cluster Configuration ■ PCI Express Configuration Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 56 Configuration options: [Auto] [Gen1] [Gen2]. ■ SATA Devices SATA Port 0  Port 0 [Enabled] Enables or disables SATA Port 0. SATA Port 1  Port 1 [Enabled] Enables or disables SATA Port 1. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 57 [Last state]: Enters to the last power state before a power failure sables.  Wake On Lan [Enabled] Enables or disables Wake On LAN (WOL) function.  BIOS Lock [Disabled] Enables or disables BIOS the SC BIOS Lock enable feature. It is required to be enabled to  ensure SMM protection of flash. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 58: Security Setup

    Allows you to set Administrator Password to control access to the BIOS Setup utility. ■ User Password Allows you to set User Password to control access to the system at boot and to the BIOS Setup utility. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 59: Boot Setup

    Allows you to enable or disable Quiet Boot function. ■ Fast Boot Allows you to enable or disable Fast Boot function. If enabled, system boots with initialization of a minimal set of devices required to launch active boot option. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 60: Save & Exit

    ■ Save as User Defaults This item allows you to save the changes done so far as user defaults. ■ Restore User Defaults This item allows you to restore the user defaults to all the setup options. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 61: Chapter 5 Product Application (For Pb-210-Dio Only)

    Chapter 5 Product Application (For PB-210-DIO Only)

  • Page 62: Digital I/O (Dio) Application

    5.1.1 Digital I/O (DIO) Programming Guide 5.1.1.1 Pins for Digital I/O BTB_FH2 BTB_FH1 Item Standard Item Standard GPIO74 (Pin107) GPIO70 (Pin103) GPIO75 (Pin108) GPIO71 (Pin104) GPIO76 (Pin109) GPIO72 (Pin105) GPIO77 (Pin110) GPIO73 (Pin106) GPIO84 (Pin115) GPIO80 (Pin111) GPIO85 (Pin116) GPIO81 (Pin112) GPIO86 (Pin117) GPIO82 (Pin113) GPIO87 (Pin118) GPIO83 (Pin114) Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 63 Following is an example to enable configuration and disable configuration by using debug. -o 4e 87 -o 4e 87 (enable configuration) -o 4e aa (disable configuration) 5.1.1.3 Relative Registers To program the F81866A configuration registers, the following configuration procedures. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 64 Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 65 Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 66 Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 67 // Set (bit 0~3) = 1 to select GP 80~83 as Output mode <Output Value> WriteByte(AddrPort, 0x89) // Select configuration register 89h WriteByte(DataPort, Value) // Set bit 0~3=(0/1) to output GP 80~83 as Low or High <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 68 // Set (bit 4~7) = 1 to select GP 84~87 as Output mode <Output Value> WriteByte(AddrPort, 0x89) // Select configuration register 89h WriteByte(DataPort, Value) // Set bit 4~7=(0/1) to output GP 84~87 as Low or High <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 69 // Set (bit 0~7) = 0 to select GP 70~77 as Input mode <input Value> WriteByte(AddrPort, 0x82) // Select configuration register 82h ReadByte(DataPort, Value) // Read bit 0~7(0xFx)= GP70~77 as High <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 70 // Select configuration register 60h (High Byte address) WriteByte(DataPort, ( 0x0A)) WriteByte(AddrPort, 0x61) // Select configuration register 61h (Low Byte address) WriteByte(DataPort, ( 0x00)) <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) Default DIO Port base address is set to 0x0A00h Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 71 7 6 5 4 3 2 1 0 = DI7 0 1 0 0 0 0 0 0 Value (Base address + 3) (0xA03) 7 6 5 4 3 2 1 0 = DI8 1 0 0 0 0 0 0 0 Value (Base address + 3) (0xA03) Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 72 7 6 5 4 3 2 1 0 = DO7 0 1 0 0 0 0 0 0 Value (Base address + 2) (0xA02) 7 6 5 4 3 2 1 0 = DO8 1 0 0 0 0 0 0 0 Value (Base address + 2) (0xA02) Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 73 5.1.1.6 DIO I/O Port Address (Default Address 0xA00) Pin Definition Data Bits Digital Input I/O Port Address 0xA03 Pin Definition Data Bits Digital Output I/O Port Address 0xA02 Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 74: Digital I/O (Dio) Hardware Specification

    - DO Signal have to pull up resistor to XCOM+ for external device, the resistance will affect the pull up current - Signal High Level : Pull up resistor to XCOM+ - Signal Low Level : = XCOM- - Sink Current: 1A (Max) Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 75: Dio Connector Definitions

    Connector Type: Terminal Block 1x10 10-pin, 3.5mm pitch Definition Definition XCOM+ Pin1 XCOM- 5.2.1.2 BTB_FH2 DIO1: Digital Input / Output Connector Connector Type: Terminal Block 1x10 10-pin, 3.5mm pitch Definition Definition XCOM+ Pin1 XCOM- Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 76 DIO1: Digital Input / Output Connector Connector Type: Terminal Block 1x10 10-pin, 3.5mm pitch Definition Definition Definition Definition XCOM+ XCOM+ DO1 (DO5) DI1 (DI5) DO2 (DO6) DI2 (DI6) DO3 (DO7) DI3 (DI7) DO4 (DO8) XCOM- DI4 (DI8) XCOM- Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 77 Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 78: Chapter 6 Optional Modules And Accessories

    Chapter 6 Optional Modules and Accessories Pin Definitions and Settings...

  • Page 79: Location Of The Connectors For Cmi Modules

    Model No. Description CMI Module with 1x DVI-D Connector,1x Universal Bracket with 1x PB-210-DVI DVI-D Cutout for Spectra PowerBox 210 CMI Module with 1x VGA Port, 1x Universal Bracket with 1x VGA PB-210-VGA Cutout for Spectra PowerBox 210 CMI Module with 1x HDMI Port, 1x Universal Bracket with 1x HDMI...
  • Page 80 Description CMI Module with 2x RS232/422/485 (Support 5V/12V), 1x Universal PB-210-COM Bracket with 2x DB9 Cutout for Spectra PowerBox 210 CMI Module with 8x Optical Isolated DIO (4 in/4 out), 1x Universal PB-210-DIO Bracket with DIO Cutout for Spectra PowerBox 210 Locate the CMI Modules/ connectors on system motherboard as indicated.

  • Page 81: Location Of The Connector For Pb-210-Ign Module

    6.2 Location of the Connector for PB-210-IGN Module Model No. Description CFM Module with Power Ignition Sensing Control Function, Select PB-210-IGN 12V/24V Locate the CFM-IGN Module’s connector on system motherboard as indicated. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 82: Location Of The Connector For Pb-210-Poe Module

    6.3 Location of the Connector for PB-210-PoE Module Model No. Description PB-210-PoE CFM Module with PoE Control Function, Individual Port 25.5W Daughterboard Locate the CFM-PoE Module’s connector on system motherboard as indicated. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 83: Pb-210-Com Module Connector Definition And Settings

    Model No. Description CMI Module with 2x RS232/422/485 (Support 5V/12V),1x Universal PB-210-COM Bracket with 2x DB9 Cutout for Spectra PowerBox 210 COM3 / COM4 / COM5 / COM6: RS232 / RS422 / RS485 Connector Connector Type: 9-pin D-Sub COM3 / COM4...
  • Page 84 Function Setting via DIP Switch Location Function DIP1 DIP2 0V(RI) ON (Default) ON (Default) SW1 on COM3_1 CMI-COM Module Location Function DIP3 DIP4 0V(RI) ON (Default) ON (Default) SW1 on CMI-COM COM4_1 Module Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 85: Pb-210-Ign Module Switches Definition And Settings

    Default setting of Pin1 to Pin4 is OFF/ON/ON/ON. 24V_12V_1 on PB-210-IGN Module: IGN Module Voltage Mode Setting Switch 12V / 24V Car Battery Switch Definition 24V Car Battery Input (Default) 12V Car Battery Input Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 86: Installing A Pb-210-Dvi Module

    1. Unscrew 2 screws to remove bracket#3 from rear panel. 2. Assemble the PB-210-DVI bracket and PB-210-DVI module together with 2 D-Sub jack screws . 3. Align two holes on the PB-210-DVI bracket with the holes on the rear panel. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 87 5. Make sure the hole on PB-210-DVI module is aligned with the screw hole on the system’s mainboard, and fasten a screw to fix it. 6. Attach the PB-210-DVI bracket, and fasten 2 screws as marked. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 88: Installing A Pb-210-Vga Module

    1. Unscrew 2 screws to remove bracket#3 from rear panel. 2. Assemble the PB-210-VGA bracket and PB-210‐VGA module together with 2 D-Sub jack screws . 3. Align two holes on the PB-210‐VGA bracket with the holes on the rear panel. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 89 5. Make sure the hole on PB-210‐VGA module is aligned with the screw hole on the system’s mainboard, and fasten a screw to fix it. 6. Attach the PB-210-VGA bracket, and fasten 2 screws as marked. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 90: Installing A Pb-210-Hdmi Module

    2. Attach PB-210-HDMI bracket on the backside of system’s rear panel, and fasten it with two screws. 3. Align the hole on PB-210-HDMI module with the screw hole on the system’s mainboard module, and insert vertically to the female connector (BTB_FH1) on the system’s mainboard. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 91 4. Fasten a screw to fix the PB-210-HDMI module. 5. Align the hole on PB-210-HDMI module with the screw hole on the system’s mainboard module, and insert vertically to the female connector (BTB_FH1) on the system’s mainboard. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 92: Installing A Pb-210-Com Module

    1. Unscrew 2 screws to remove bracket#2 or bracket#3 from rear panel. 2. Assemble the PB-210-COM bracket and PB-210-COM module together with 4 D-Sub jack screws 3. Align two holes on the PB-210-COM bracket with the holes on the rear panel. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 93 5. Make sure the hole on PB-210-COM module is aligned with the screw hole on the system’s mainboard, and fasten a screw to fix it. 6. Fasten 2 screws for each PB-210-COM bracket as marked. COM6 COM3 COM4 COM5 Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 94: Installing A Pb-210-Dio Module

    2. Attach the PB-210-DIO bracket on the backside of system’s rear panel, and fasten it with two screws. 3. Push the connector pins on PB-210-DIO module until the pins can be inserted completely to the female connector (BTB_FH2 or BTB_FH1) on the system’s mainboard. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 95 4. Make sure the hole on PB-210-DIO module is aligned with the screw hole on the system’s mainboard, and fasten a screw to fix it. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 96: Installing A Pb-210-Ign Module

    1. Locate the IGN connector on system motherboard as indicated in page 75, and insert the male connector of PB-210-IGN module to the female connector on system’s mainboard. 2. Fasten a screw to fix the PB-210-IGN Module. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 97: Installing A Pb-210-Poe Module

    PB-210-PoE module to the male connector on system’s mainboard. 2. Turn over the heatsink and paste the thermal pad onto the marked by red squares. 3. Paste the heatsink onto the PB-210-PoE module carefully and fasten 2 screws to fix it. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 98 4. Paste the thermal pads onto the heatsink and coil carefully. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 99: Installing A Side Mount Bracket

    6.13 Installing a Side Mount Bracket Model No. Description Side Mount Kit for Spectra PowerBox 210, with KMRH-K175 for DIN- PB-210-SIDE-KIT Rail option offers Side Mount that customer can install the system onto The Spectra PowerBox 210 the right or left side of wall to create effectiveness of space.
  • Page 100 4 screws to fix the side mount bracket with system together. 4. It is achievable to mount system on the wall by fastening the screws through the bracket mounting hole. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...

  • Page 101: Installing A Vesa Mount Bracket

    6.14 Installing a VESA Mount Bracket offers VESA Mount that customer can mount system with The Spectra PowerBox 210 VESA standards of 75 mm and 100 mm for various usages. 1. Provided below is the base of the system unit with screw holes specified to be Blue circles represent the use for VESA 75 mm.
  • Page 102 3. Provided below is completion of mounting with VESA stand. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 210  Series April 2019...
  • Page 103 Spectra GmbH & Co. KG Spectra GmbH & Co. KG Spectra (Schweiz) AG Mahdenstr. 3 Gewerbepark Ost 1 Flugplatzstr. 5 72768 Reutlingen 4621 Sipbachzell (Wels) 8404 Winterthur Germany Austria Switzerland Phone Phone +49 (0) 7121 1432-10 +43 (0) 7240 20190...
