  • Page 1 SPECTRA POWERBOX 400-SERIES USER MANUAL Version 1.0 – October 2017...
  • Page 2 3.5.6 Install an External Fan ..……………………………………….……. 60 3.5.7 Installing the Front Cover Plate…..…………………………………. 62 Wall Mount Brackets………………………….……………..………………. 63 DIN-Rail Mount Brackets…………….…….……………………………….. 64 VESA Mount ……………………………………………..….………………... 65 Side Mount Brackets………..…………………..……..……………………. 67 Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 3 PB-400-IGN Power Ignition Module Connector Location.………...…..…. 103 Definitions of Switches ………………………..………….….….…….………. 103 PB-400-COM Module Connector Definition and Settings…………………. 104 PB-400-LAN-M12 Module Pin Definitions ……….………………………….. 105 PB-400-PoE-M12 Module Pin Definitions ……….………………………….. 105 Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400...

  • Page 4: Preface Revision

    2017/10/19 Copyright Notice © 2017 by Spectra GmbH & Co. KG. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Spectra GmbH &...

  • Page 5: Product Warranty Statement

    (such as a fuse, battery, etc.), are not warranted. Before sending your product in, you will need to fill in a Spectra RMA Request Form and obtain a RMA number from us. Please go to www.spectra.de/RMA...

  • Page 6: Technical Support And Assistance

    This indication alerts operators to an operation that, if not strictly observed, may result in safety hazards to personnel or damage to equipment. This indication provides additional information to complete a task easily. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...

  • Page 7: Safety Precautions

     The equipment has obvious signs of breakage. 14. CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...

  • Page 8: Package Contents

    Package Contents Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty Spectra PowerBox 400 Rugged Workstation CPU Heatsink Thermal Pad Utility DVD Driver Screw Pack Wall Mounting Kit Power Terminal Block Connector...
  • Page 9 Adapter AC/DC 24V 9.2A 220W with 3pin Terminal Block Plug 5.0mm Pitch, with Tubes 3-pin PB-400-SIDE Kit Side Mount Kit PB-400-DIN Rail Kit Din rail Mount Kit Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 10 Chapter 1 PRODUCT INTRODUCTIONS...
  • Page 11 1.1 Overview The Spectra PowerBox 400 is a rugged workstation series based on LGA 1151 socket and Intel® C236 chipset supporting 7 generation Intel® Xeon® and Intel® Core™ Processors, the series supports 4K resolution through Intel® Gen 9 graphics engine with two DDR4 SO-DIMM sockets up to 32GB memory which delivers outstanding computing performance for high-end applications.

  • Page 12: Key Features

    • 2x Control Function Interfaces for Power Ignition Sensing and PoE Functions • 4x Full-size Mini-PCIe Slots for Wireless & I/O Expansions • EN50155 / EN50121-3-2 Certification for Railway Application • E-Mark Certification for In-vehicle Application (Pending) Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...

  • Page 13: Hardware Specification

    Database: Telcordia SR-332 Issue 3, Method 1, Case 3 - 2x COM Module, 16x Optical Isolated DIO Module (via 1x Low Speed Interface) • 4x Full-size Mini-PCIe Sockets • 1x SIM Socket Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400...
  • Page 14 Indicates the temperature of the system SIM Card Slot Used to inserts a SIM card Universal I/O Bracket Used to customized I/O output with optional modules Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 15 Used to connect a DVI monitor or connect optional split cable for dual display mode COM Port COM #1 ~ COM #4 support RS232/422/485 serial device Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...

  • Page 16: Mechanical Dimension

    1.7 Mechanical Dimension Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 17 Chapter 2 SYSTEM PIN DEFINITIONS AND SETTINGS...

  • Page 18: Top View

    All pins are open Pins 1 and 2 are short Pins 2 and 3 are short 2.2 Location of the Connectors, Jumpers and Switches 2.2.1 Top View Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400...

  • Page 19: Bottom View

    2.2.2 Bottom View Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 20 Power 1~4 +5V / +12V Power Output 24V_12V_1 IGN Board Function Select AT_ATX1 AT / ATX Power Mode Switch CLR_CMOS1 Clear BIOS Switch Reset1 Reset Button Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 21 ON (Default) COM3 Location Function DIP7 DIP8 0V(RI) ON (Default) ON (Default) COM4 SW3: Super CAP Switch Switch Function mode Super CAP Enable (Default) Disable Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 22 1-2 (Left) AT Power Mode 2-3 (Right) ATX Power Mode (Default) CLR_CMOS1: Clear BIOS Switch Definition 1-2 (Left) Normal Status (Default) 2-3 (Right) Clear BIOS Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...

  • Page 23: Definition Of Connectors

    25 PERP0 / SATARN0 43 RESERVED CLINK_CLK SIM_DATA +1.5V REFCLK- CLINK_DATA SIM_CLK SMB_CLK +1.5V REFCLK+ 31 PETN0 / SATATN0 49 CLINK_RST SIM_Reset SMB_DATA PETP0 / SATATP0 SIM_VPP +3.3V USB_D- Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 24 23 PERN0 / SATARP0 41 3.3V 1.5V +3.3VAUX CLKREQ# 25 PERP0 / SATARN0 43 +1.5V REFCLK- SMB_CLK +1.5V REFCLK+ PETN0 / ATATN0 SMB_DATA PETP0 / SATATP0 +3.3V USB_D- Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 25 Steady Orange 100Mbps Network Link 10Mbps Network Link DC_IN1: DC Power Input Connector (+9~48V) Connector Type: Terminal Block 1x3 3-pin, 5.0mm pitch Definition +9~48VIN Ignition Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 26 Connector Type: 9-pin D-Sub COM1 / COM2 / COM3 / COM4 RS422 / 485 RS485 RS232 Full Duplex Half Duplex Definition Definition Definition DATA- DATA+ Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 27 Chapter 3 SYSTEM SETUP...
  • Page 28 1. Turn over the unit to have the bottom side face up, loosen the 6 screws of bottom cover and place them aside for later use. 2. Remove the bottom cover from the chassis. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...
  • Page 29 3. Loosen the 4 screws. Pull out 4 latches as marked on photo. 4. Hold front and rear panel and lift up the body of unit vertically. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400...
  • Page 30 5. Turn over the body of the unit and place it gently. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...

  • Page 31: Installing The Cpu

    1. Locate the CPU socket , remove the protection cover on it. 2. Press the CPU socket lever and pull it aside away from the socket to unlock it. Pull back the lever to open the socket. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...
  • Page 32 3. Align the notches on CPU with the alignment post on socket. 4. The notches of socket provide the space for fingers while lowering the CPU, hold the CPU by the edges toward the notches and insert the CPU gently. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...
  • Page 33 5. Place the thermal pad on the CPU heat spreader. Press down the socket lever to lock the CPU. Thermal pad 6. Align mounting holes of heat sink with the nut studs and fasten the heat sink with provided 4 screws. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400...
  • Page 34 7. Place thermal pad on the top of CPU heatsink in order to provide a seamless contact with the body of chassis to create a efficient heat dissipation. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400...
  • Page 35 SO-DIMM socket firmly. 45° 45° Lower socket Upper socket 3. Press down the module until the retaining clips snap back in place. Lower socket Upper socket Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 36 For 3G/4G Mini-PCIe card, please install on slot. 45° 45° CN3,4,5,6 slot CN3 slot 3. Press down the card and fasten two screws to fix it. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...

  • Page 37: Installing Antennas

    1. Remove the antenna rubber covers on rear panel. 2. Penetrate the antenna jack through the hole at both sides as illustrated. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...
  • Page 38 3. Put on washer and fasten the nut with antenna jack. 4. Assemble the antenna and antenna jack together 5. Attach the RF connector at another end of cable onto the module. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...
  • Page 39 3.3 Installing Control Function & Multi I/O Modules 3.3.1 Installing a PB-400-IGN Power Ignition Module 1. Locate the IGN connector on the bottom side of system. 2. Fasten 1 copper pillar before insert IGN module. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...
  • Page 40 3. Insert IGN module vertically to the female connector on the system’s mainboard, and fasten 2 screws to fix it. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 41 3.3.2 Installing a PB-400-COM Module 1. Locate the connector of Multi I/O module on the bottom side of system. 2. Loosen the 2 screws on rear bezel to remove the cover plate Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...
  • Page 42 Fix it with 2 screws. 4. Loosen the 4 D-Sub jack screws as marked on photo. 5. Attach the COM bracket. Fasten 2 screws and 4 D-Sub jack screws to fix it. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...
  • Page 43 3.3.3 Installing a PB-400-DIO Module 1. Locate the connector of PB-400-DIO module on the bottom side of system. 2. .Loosen the 2 screws on rear bezel to remove the cover plate Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...
  • Page 44 3. Insert the PB-400-DIO module carefully into the Multi I/O connector on main board. Fix it with 2 screws. 4. Attach the DIO bracket, and fasten 2 screws to fix it. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...
  • Page 45 Note: The photo example in this section is illustrated by PB-400-LAN-M12 module as shown in below picture. 1. Loosen the 2 screws on front bezel to remove the cover plate. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400...
  • Page 46 M12 I/O bracket. then fasten 4 ring hexes onto jacks as illustrated in right hand picture below. Rubber rings 3. Locate the Multi I/O Module connector on the top side of system. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...
  • Page 47 4. Exchange screw to copper pillar before insert the Multi I/O module . 5. Insert the Multi I/O module vertically into the female connector on system’s mainboard until it’s connected firmly and fasten screws to fix it. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...
  • Page 48 6. Fasten 2 screws on cover plate. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 49 1. Insert the PB-400-LAN-M12 module vertically into the female connector on system’s mainboard until it’s connected firmly, and fasten 4 copper pillars to fix it. 2. Insert the PB-400-PoE daughter board vertically into the female connector on PB-400-LAN- M12 module vertically. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...
  • Page 50 3. Please paste the 2 thermal pads onto the PB-400-PoE daughter board carefully. 4. Please paste the heatsink onto the PB-400-PoE daughter board carefully. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 51 5. Fasten 4 screws to fix it. 6. Please paste the thermal pad onto the heatsink carefully. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...

  • Page 52: Installing Top Cover

    3.4 Assembling the System 3.4.1 Installing Thermal Pad The Spectra PowerBox 400 series don’t need to additional installation of the PCH Note: thermal pad Thermal pad 3.4.2 Installing Top Cover the 4 1. Hold front and rear panel and put the body of unit back to chassis and fasten screws as marked on photo.
  • Page 53 3.4.3 Installing Bottom Cover 1. Place the bottom cover back to system. 2. Fasten the bottom cover with 6 screws . Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 54 Note: It’s advised to fasten the 2 screws manually. If fastened with an electrical screw driver, please set the torque of the driver to 2.5KgF. 3.5.2 Installing a SATA Hard Drive at Front Side 1. Locate the removable HDD bay and loosen the screw. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...
  • Page 55 3. Make the bottom side of the HDD face up, place the HDD bracket on it. Ensure the direction of bracket is correct and use 4 provided screws to assemble HDD and HDD bracket together. Spectra GmbH & Co. KG User Manual Version 1.0...
  • Page 56 4. Align the HDD bracket assembly with the entrance of removable HDD bay. Holding the rotating arm and insert the HDD bracket until the connector of HDD contact the SATA connector firmly. 5. Place the rotating arm back and fasten the screw. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...

  • Page 57: Installing A Sim Card

    1. Locate the SIM card slot at front side. 2. Insert a SIM card into SIM slot with the gold contacts facing up. Please pay attention to the insert orientation as illustrated. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...
  • Page 58 3.5.4 Installing the CMOS Battery 1. Locate the removable CMOS Battery and loosen the screw. 2. Pull out the CMOS battery bracket with assistance of a tweezer. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400...
  • Page 59 3. Insert a CMOS battery in the battery slot. 4. Insert the battery bracket firmly and fasten the screw. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...

  • Page 60: Fasten The Cover

    1. Fasten the cover by using the two screws. 3.5.6 Install an External Fan 1. Prepare an external fan. Loosen the 2 screws halfway on mounting frame before attempting to install it. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...
  • Page 61 2. Slide the FAN into the middle groove of chassis as illustrated. Tighten the 2 screws to fix it onto chassis. 3. Move the fan to the center of chassis. Tighten the 2 screws marked on photo to secure it. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...
  • Page 62 4. Connect the FAN cable to external fan power connector at rear panel. 3.5.7 Installing the Front Cover Plate 1. Put the front cover plate back. Fasten it with 2 screws. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...

  • Page 63: Wall Mount Brackets

    1. The mounting holes are at the bottom side of system. Use provided 8 screws to fasten the bracket on each side. 2. There are 2 bracket mounting holes at left and right side for customer fix the system on the wall. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...
  • Page 64 1. Please refer to section 3.6 Wall Mount Brackets to install mounting bracket at both sides of system. 2. Fasten 2 DIN rail mounting clips to mounting brackets on both sides with provided 4 screws as illustrated. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...

  • Page 65: Vesa Mount

    3.8 VESA Mount Spectra PowerBox 400 series supports VESA mounting that customer can mount system with panel complying with VESA 75mm and 100 mm standard for various usage. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400...
  • Page 66 VESA stand. Align the 4 screw holes of VESA stand with the screw holes on bottom side of system. Fasten 4 screws to fix it. 2. Provided below is mounted with VESA stand. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...

  • Page 67: Side Mount Brackets

    1. The mounting holes are at the bottom of system. Fasten the 8 screws to fix the side mount bracket with system together. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...
  • Page 68 2. Fasten the screws through the bracket mounting hole to mount system on the wall. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 69 Chapter 4 BIOS SETUP...

  • Page 70: Bios Introduction

    If you want to return to the main menu, just press the <Esc >. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...

  • Page 71: Main Setup

    4.2.1 System Date Set the date. Please use <Tab> to switch between date elements. 4.2.2 System Time Set the time. Please use <Tab> to switch between time elements. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400...

  • Page 72: Cpu Configuration

    4.3 Advanced Setup This section allows you to configure and improve your system and allows you to set up some system features according to your preference. 4.3.1 CPU Configuration Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400...

  • Page 73: Sata And Rst Configuration

    ■ SATA Controller(s) [Enabled] Enables or disables SATA device. ■ SATA Mode Selection [AHCI] Allows you to select which mode SATA controller will operates. Configuration options: [AHCI], [RAID] Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400...
  • Page 74  Port 4 [Enabled] Enables or disables SATA Port 4. ■ Serial ATA Port 5  Port 5 [Enabled] Enables or disables SATA Port 5. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 75 HDD Unlock Enables or disables HDD Unlock.  LED Locate Enables or disables LED Locate. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...

  • Page 76: Pch-Fw Configuration

    ■ ME Unconfig on RTC Clear Enables or disables ■ Firmware Update Configuration Configure Management Engine Parameters  Me FW Image Re-Flash Enables or disables ME firmware Image Re-Flash function. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...

  • Page 77: Acpi Settings

    [S3 (suspend to RAM)]: Enables suspend to RAM state. ■ Lock Legacy Resources [Disabled] Enables or disables Lock Legacy Resources. ■ S3 Video Repost [Enabled] Enable or disable S3 Video Repost. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400...

  • Page 78: F81866 Super Io Configuration

    4.3.5 F81866 Super IO Configuration Set Parameters of Serial Ports. User can Enable/Disable the serial port and Select an optimal settings for the Super IO Device ■ Serial Port 1~6 Configuration. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...

  • Page 79: Hardware Monitor

    Allows you to set watchdog timer’s value in the range of 0 to 255. 4.3.6 Hardware Monitor This screen displays the current status of all monitored hardware devices/components such as voltages, temperatures and all fans’ speeds. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...

  • Page 80: S5 Rtc Wake Settings

    [Disabled]: Disables wake system from S5. [Fixed Time]: Sets a fixed time (HH:MM:SS) to wake system from S5. [Dynamic Time]: Sets a increase minute(s) from current time to wake system from Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...

  • Page 81: Serial Port Console Redirection

    COM1 = Serial Port 2 COM2 = Serial Port 3 COM3 = Serial Port 4 COM4 = Serial Port 5 COM5 = Serial Port 6 Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...

  • Page 82: Network Stack Configuration

    4.3.9 Network Stack Configuration ■ Network Stack [Disabled] Enables or disables UEFI Network Stack. 4.3.10 CSM Configuration This option controls legacy/UEFI ROMs priority. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 83 [Legacy]: Enables legacy option ROM only. ■ Other PCI devices [Do not launch] Allows users to determine option ROM execution policy for devise other than network, storage, or video. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400...

  • Page 84: Usb Configuration

    Enables or disables XHCI (USB3.0) hand-off function. Use this feature as a workaround for operating systems without XHCI hand-off support. ■ USB Mass Storage Driver Support [Enabled] Enables or disables USB mass storage driver support. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...

  • Page 85: Chipset Setup

    4.4 Chipset Setup This section allows you to configure chipset related settings according to user’s preference. 4.4.1 System Agent (SA) Configuration Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 86 Configuration options: [Auto] [IGFX] [PEG] [PCIe]  Internal Graphics [Auto] Allows users to enable or disable Internal Graphics. Configuration options: [Auto] [Disabled] [Enabled] 4.4.2 PCH-IO Configuration Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 87  PCI Express (Mini PCIe1 (CN6)) [Enabled] Enables or disables PCI Express Root Port.  PCIeSpeed [Auto] Allows you to select PCI Express port speed. Configuration options: [Auto] [Gen1] [Gen2] [Gen3]. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400...
  • Page 88 Allows you to change Mini PCIe1 (CN5) as [Mini-PCIe] or [mSATA]. ■ CN6 mSATA Function Switch [Mini-PCIe] Allows you to change Mini PCIe1 (CN6) as [Mini-PCIe] or [mSATA]. ■ Amplifier Function [Enabled] Enables or disables Amplifier Function. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400...

  • Page 89: Security Setup

    Allows you to set Administrator Password to control access to the BIOS Setup utility. 4.5.2 User Password Allows you to set User Password to control access to the system at boot and to the BIOS Setup utility. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...

  • Page 90: Bootup Numlock State

    Allows you to change New Boot Option Policy. Configuration options: [Default] [Place First] [Place Last]. 4.6.6 Hard Drive BBS Priority Allows you to set the order of the legacy devices in this group. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...
  • Page 91 This item allows you to save the changes done so far as user defaults. 4.7.9 Restore User Defaults This item allows you to restore the user defaults to all the setup options. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de...
  • Page 92 Chapter 5 PRODUCT APPLICATION (FOR DIO ONLY)
  • Page 93 Following is an example to enable configuration and disable configuration by using debug. -o 4e 87 -o 4e 87 (enable configuration) -o 4e aa (disable configuration) Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400...
  • Page 94 5.1.1.3 Relative Registers To program the F81866A configuration registers, the following configuration procedures. Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 95 Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 96 <input Value> WriteByte(AddrPort, 0x82) // Select configuration register 82h ReadByte(DataPort, Value) // Read bit 0~7(0xFx)= GP70 ~77 as High. <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 97 // Select configuration register 61h (Low Byte address) WriteByte(DataPort, ( 0x00)) <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) default DIO Port base address is set to 0x0A00h Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400...
  • Page 98 (Base address +3) (0xA03) 7 6 5 4 3 2 1 0 = DI8 1 0 0 0 0 0 0 0 Value (Base address +3) (0xA03) Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 99 (Base address +2) (0xA02) 7 6 5 4 3 2 1 0 = DO8 1 0 0 0 0 0 0 0 Value (Base address +2) (0xA02) Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 100 - Signal High Level : Pull up resistor to XCOM+ - Signal Low Level : = XCOM- - Sink Current: 1A (Max) Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400...
  • Page 101 Connector Type: Terminal Block 1X10 10-pin, 3.5mm pitch XCOM+ XCOM- Definition Pin 1 DIO2: Digital Output Connector Connector Type: Terminal Block 1X10 10-pin, 3.5mm pitch XCOM+ XCOM- Definition Pin 1 Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 102 Chapter 6 OPTIONAL MODULE PIN DEFINITIONS AND SETTINGS...
  • Page 103 30 minutes 1 hour 2 hours Reserved (0 second) 24V_12V_1: 12V / 24V Car Battery Switch Definition 24V Car Battery Input 12V Car Battery Input Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 104 COM5/6 Voltage Function Setting : Pin Define SW2 Switch Location Function DIP1 DIP2 0V(RI) ON (Default) ON (Default) COM5 Location Function DIP3 DIP4 0V(RI) ON (Default) ON (Default) COM6 Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...

  • Page 105: Pb-400-Poe-M12 Module Pin Definitions

    Connector Type: M12 A coded 8pin connector POE type: Midspan (B-Type) Definition Definition 2_LAN1_0+ 2_LAN1_0- 2_LAN1_1+ 2_LAN1_2+(Power PIN) 2_LAN1_2-(Power PIN) 2_LAN1_1- 2_LAN1_3+(Power PIN) 2_LAN1_3-(Power PIN) Spectra GmbH & Co. KG User Manual Version 1.0 vertrieb@spectra.de Spectra PowerBox 400 October 2017...
  • Page 106 Spectra GmbH & Co. KG Sales Offices Phone +49 (0) 7121 1432 + ext. Mahdenstr. 3 North 06, 10-31, 38-39 -148 72768 Reutlingen Center 32-37, 40-54, 56-59 -123 Germany Southwest-West 55, 60-69, 72000-72519, 72700-72999, 75-79, 87-88 -155 +49 (0) 7121 14321-0...
