  • Page 1 Spectra PowerBox 310 Series USER MANUAL Version 1.00 – December 2021...

  • Page 2: Table Of Contents

    3.8 Installing SIM Card ...................... 42  3.9 Installing Wall Mount ....................43  3.10  VESA Mount ......................45  3.11  Connecting to Power Supply ................46  Chapter 4 BIOS Setup ....................47   4.1 BIOS Introduction ......................48  Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 3 5.2 DIO Hardware Specification ..................77  5.2.1 DIO Connector Definition ..................78  Chapter 6 Optional Modules & Accessories ............80   6.1 Optional Module Pin Definition & Settings ............81  6.1.1  PB-310-LAN-M12 ....................81  Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 4 6.6 Installing External FAN ................... 111  6.6.1  FAN-EX ........................ 111  6.7 Installing DIN-Rail Mount Kit ................. 113  6.7.1  DINRAIL ....................... 113  6.8 Installing Side Mount Kit ..................114  6.8.1  SIDE ........................114  Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 5: Preface

    2021/11/15 Copyright Notice © 2021 by Spectra GmbH & Co. KG. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Spectra GmbH &...

  • Page 6: Product Warranty Statement

    Product Warranty Statement Warranty Spectra products are warranted by Spectra GmbH & Co. KG to be free from defect in materials and workmanship starting from the date of purchase by the original purchaser. The actual warranty period of Spectra products vary with product categories. During the warranty period, we shall, at our option, either repair or replace any product that proves to be defective under normal operation.
  • Page 7 Before sending your product in, you will need to fill in a Spectra RMA Request Form and obtain a RMA number from us. Please go to www.spectra.de/RMA to fill in this form. Our staff is available at any time to provide you with the most friendly and immediate service.

  • Page 8: Technical Support And Assistance

    Technical Support and Assistance 1. Visit the Spectra website at www.spectra.de where you can find the latest information about the product. 2. Contact our technical support team or sales representative for technical support if you need additional assistance. Please have following information ready before you call: ...

  • Page 9: Safety Precautions

    14. CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. 15. Equipment intended only for use in a RESTRICTED ACCESS AREA. Spectra GmbH & Co. KG User Manual sales@spectra.de...

  • Page 10: Ordering Information

    Utility DVD Driver x1 Screw Pack x1 Wall Mount Kit x1 Power Terminal Block Connector x1 Remote Function Terminal Block Connector x 2 Fan Terminal Block Connector x 1 Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 11: Chapter 1 Product Introductions

    Chapter 1 Product Introductions Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 12: Overview

    1.1 Overview The Spectra PowerBox 310 packs high performance, lots of I/O ports, and expansion flexibility in a compact form factor. The Spectra PowerBox 310 is powered by an 8th Gen Intel® Core™ U-Series processor (Whiskey Lake) with ultra-low 15W TDP yet delivering uncompromised performance. The...
  • Page 13 Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 14: Product Pictures

    Optional CMI modules (2x 10 GbE LAN, M12 A-coded, or M12 X-coded) Optional CFM modules (power ignition sensing, or 4x PoE)   Wide operating temperature -40°C to 70°C  E-mark and EN50155 (EN 50121-3-2 only) certified Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 15: Hardware Specification

    • 2x 480 Mbps USB 2.0, Type A PS/2 • 1x PS/2, 6 Pin Mini-DIN Female Connector Storage SSD/HDD • 1x 2.5” Front Accessible SATA HDD/SSD Bay (SATA 3.0) Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 16 Dimension (W x D x H) • 203 x 142 x 66.8 mm Weight Information • 1.74 KG • Extruded Aluminum with Heavy Duty Metal Mechanical Construction Mounting • Wall/ Side/ DIN-RAIL/ VESA Mount Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 17 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from our website. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 18: System I/O

    A switch used to clear CMOS to reset BIOS USB 3.2 Gen2 Reset Used to connect USB 3.2 Gen2/3.2 Gen1/2.0 A button used to reset the system device Universal I/O Bracket Used for customized I/O output Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 19 LED Used to connect to local area network Remote Power On/Off PS/2 A terminal block used to connect to remote Used to connect the PS/2 device power on/off switch Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 20: Mechanical Dimension

    1.7 Mechanical Dimension Unit: mm Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 21: Chapter 2 Switches & Connectors

    Chapter 2 Switches & Connectors Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 22: Location Of Switches And Connectors

    2.1 Location of Switches and Connectors 2.1.1 Top View 2.1.2 Bottom View Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 23: Switches And Connectors List

    DC input power 15A/58V RESET1 Reset button CLR_CMOS1 Clear COMS switch setting AT_ATX1 AT_ATX1 switch setting f, g SIM1, SIM2 SIM Card socket A and B SATA2 22 Pins SATA connector Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 24: Definition Of Switches And Connectors

    Yellow PWR_SW1: Power button Switch Definition Push Power System MODE_SEL1: Super CAP Function Setting Location Function DIP1 DIP2 Super CAP ON (Default) Enabled ON (Default) MODE_SEL1 Super CAP Disabled Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 25 Definition Steady Green 1 Gbps Network Link Steady Orange 100 Mbps Network Link 10 Mbps Network Link Act LED Status Definition Blinking Yellow Data Activity Steady Yellow No Activity Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 26 CLKREQ# PERP0/SATARN0 RESERVED 10 NA +1.5V 11 REFCLK- 12 NA SMB_CLK +1.5V 13 REFCLK+ PETN0/SATATN0 14 NA SMB_DATA 15 GND PETP0/SATATP0 16 NA +3.3V 17 NA 18 GND USB_D- Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 27 CLKREQ# PERP1/SATARN1 SIM_PWR 10 SIM_DATA +1.5V 11 REFCLK- 12 SIM_CLK SMB_CLK +1.5V 13 REFCLK+ PETN1/SATATN1 14 SIM_RESET SMB_DATA 15 GND PETP1/SATATP1 16 SIM_VPP +3.3V 17 NA 18 GND USB_D- Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 28 Remote Power LED connector can connect an external LED indicator up to 10mA. Connector Type: Terminal Block 2X2 4-pin, 3.5mm pitch Definition PWR_SW RMT_PWR_LED_A Do not apply power to this connector! Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 29 Connector Type: Terminal Block 1x3 3-pin, 5.0mm pitch Definition +9~48VIN Ignition (IGN) 1 2 3 Please disconnect the power source before mounting the DC power cables or connecting the DC power connector to system. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 30: Chapter 3 System Setup

    Chapter 3 System Setup Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 31: Removing Top Cover

    1. Turn over the unit to have the bottom side face up, loosen the 6 screws on the bottom cover and place them aside for later use. 2. Remove the bottom cover from the chassis. Spectra GmbH & Co. KG User Manual sales@spectra.de...
  • Page 32 3. Lift up the unit vertically by holding the front and rear panel. 4. Turn over the body of the unit and place it gently. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 33: Installing So-Dimm

    2. Insert the SO-DIMM at a 45-degree angle until its edge connector is connected to the SO-DIMM socket firmly. 45° 3. Press down the module until the retaining clips snap back in place. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 34: Installing Mini-Pcie Card

    Tilt a Mini PCIe card at a 45-degree angle and insert it to the socket until the golden finger connector of the card seated firmly. 45° Press the card down and secure it with 2 screws. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 35: Installing Antenna

    Installing an antenna jack with a diameter greater than 9 mm on the right side of the system will collide with the terminal connector below. In this case, please try to install the antenna on the left side of the system. Spectra GmbH & Co. KG User Manual sales@spectra.de...
  • Page 36 4. Assemble the antenna and antenna jack together. 5. Attach the RF connector of the cable’s another end onto the card. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 37: Installing The Thermal Pad

    3. Paste the thermal pad onto the heatsink carefully. Thermal pad Before assembling the system’s chassis cover, please make sure the transparent protective film on the Thermal Pad has been removed! Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 38: Assembling Top Cover

    1. Make sure the notch on the chassis and the front bezel of the unit body are on the same side. 2. Lift the body of the unit, make sure that the front and rear panels are in the chassis groves, and then assemble the body into the chassis. Spectra GmbH & Co. KG User Manual sales@spectra.de...
  • Page 39 Place the bottom cover back to system. 3. Fasten the 6 screws to fix the cover. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 40: Installing Sata Hard Drives At Front Panel

    4. Make HDD bottom side face up, place the HDD bracket on it. Ensure the direction of bracket is correct and use 4 provided screws to assemble HDD and HDD bracket together. Spectra GmbH & Co. KG User Manual sales@spectra.de...
  • Page 41 HDD connector is fully inserted into the SATA slot. 6. Place the rotating arm back and fasten the screw. 7. Fix the cover plate of maintenance zone by fastening the two screws. Spectra GmbH & Co. KG User Manual sales@spectra.de...

  • Page 42: Installing Sim Card

    2. Locate the SIM card slot at front side and insert a SIM card into a SIM slot with the gold contacts facing up. Please pay attention to the insert orientation as illustrated. 3. Fix the cover plate of maintenance zone by fastening the two screws. Spectra GmbH & Co. KG User Manual sales@spectra.de...

  • Page 43: Installing Wall Mount

    3.9 Installing Wall Mount Spectra PowerBox 310 series offers wall mount that customers can install system on the wall in a convenient and economical way. 1. The mounting holes are at the bottom side of system. Use provided 4 screws to fasten the bracket on each side.
  • Page 44 Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 45: Vesa Mount

    3.10 VESA Mount Spectra PowerBox 310 series supports VESA mounting that customer can mount system with panel complying with VESA 75mm and 100 mm standard for various usage. The following picture illustrates the installation of Spectra PowerBox 310 series on a VESA stand.

  • Page 46: Connecting To Power Supply

    3. Fasten the two screws to fix the phoenix contacts. In formal use, please use new Phoenix contacts and make sure the screws are tightened to avoid poor connection.  Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 47: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 48: Bios Introduction

    Then you can use the control keys to enter values and move from field to field within a sub-menu. If you want to return to the main menu, just press the <Esc >. Spectra GmbH & Co. KG User Manual sales@spectra.de...

  • Page 49: Main Setup

    4.2.1 System Date Set the date. Please use <Tab> to switch between date elements. 4.2.2 System Time Set the time. Please use <Tab> to switch between time elements. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 50: Advanced Setup

    ■ Active Process Cores [All] Allows users to choose the number of active processor cores. Configuration options: [All] [1] [2] [3] ■ Hyper-threading Enables or disables for Hyper-Threading Technology. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 51: Pch-Fw Configuration

    Allows users to enable or disable Intel® Active Management Technology BIOS execution. (This function can be opened for customization.) ■ Firmware Update Configuration  ME FW Image Re-Flash [Disabled] Allows users to enable or disable ME firmware image re-flash function. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 52: Trusted Computing

    This item allows users to configure ACPI settings. ■ Enable ACPI Auto Configuration [Enabled] Enables or disables BIOS Advanced Configuration Power Interface® (ACPI) auto configuration. ■ ACPI Sleep State [S3 (Suspend to RAM)] Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 53 The screen allows users to select options for the Super IO configuration, and change the value of the selected option. ■ Serial Port 1~2 Configuration  Serial Port [Enabled] This item allows users to enable or disable serial port.  Change Settings [Auto] Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 54: Hardware Monitor

    ■ External Smart Fan Function [Enabled] Enables or disables external smart fan function. ■ External Smart Fan Configuration Allows users to setting external smart fan parameters. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 55: S5 Rtc Wake Settings

    [Dynamic Time]: Set the increase time from current time to wake system. 4.3.8 Serial Port Console Redirection ■ Console Redirection [Disabled] These items allow users to enable or disable COM1, COM2 console redirection function. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 56: Usb Configuration

    This item allows users to enable or disable XHCI (USB3.2) hand-off function. ■ USB Mass Storage Driver Support [Enabled] Enables or disables support for USB mass storage devices. 4.3.10 CSM Configuration Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 57 ■ CSM Support [Disabled] Enables or disables compatibility support module. 4.3.11 Network Stack Configuration ■ Network Stack [Disabled] Enables or disables UEFI Network Stack. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 58: Chipset Setup

    4.4 Chipset Setup This section allows you to configure chipset related settings according to user’s preference. 4.4.1 System Agent (SA) Configuration Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 59: Pch-Io Configuration

    This item displays detailed memory information in the system. ■ VT-d [Enabled] This item allows users to enable or disable Intel® Virtualization Technology for Directed I/O (VT-d) function. 4.4.2 PCH-IO Configuration Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 60  PCI Express Root Port [Enabled] Allows you to enable or disable the PCI Express Port.  PCIe Speed [Auto] Allows you to select PCI Express interface speed. Configuration options: [Auto] [Gen1] [Gen2] [Gen3]. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 61  Serial ATA Port 0 Port 0 [Enabled] Enables or disables SATA Port 0 (Location: SATA2).  Serial ATA Port 1 Port 1 [Enabled] Enables or disables SATA Port 1 (Location: MINIPCIE1). Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 62 Allows users to select [Mini-PCIe] or [mSATA] for MiniPCIe1 connector. ■ MiniPcie1 USB3 Function Switch [Disabled] Enables or disables MiniPcie1 USB3 Function. ■ MiniPcie2 USB3 Function Switch [Disabled] Enables or disables MiniPcie2 USB3 Function. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 63 (G3 state). [Always on]: Enters to power on state. [Always off]: Enters to power off state. [Keep last state]: Enters to the last power state before a power failure. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 64: Security Setup

    4.5.3 Security Boot  Secure Boot [Disabled] Enable or disable Secure Boot function.  Secure Boot Mode [Standard] Allows you to select Secure Boor Mode. Configuration options: [Standard] [Custom]. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 65: Boot Setup

    Allows users to select the power-on state for keyboard NumLock. 4.6.3 Quiet Boot [Disabled] Allows users to enable or disable Quiet Boot function. 4.6.4 Fast Boot [Disabled] Allows users to enable or disable Fast Boot function. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 66: Save & Exit

    This item allows users to save the changes done so far as user defaults. 4.7.9 Restore User Defaults This item allows users to restore the user defaults to all the options. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 67: Chapter 5 Product Application

    Chapter 5 Product Application Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 68: Digital I/O (Dio) Application

    GPIO31 (Pin37) GPIO32 (Pin38) GPIO33 (Pin39) GPIO34 (Pin40) GPIO35 (Pin41) GPIO36 (Pin42) GPIO37 (Pin43) GPIO50 (Pin9) GPIO51 (Pin10) GPIO52 (Pin11) GPIO53 (Pin12) GPIO54 (Pin13) GPIO55 (Pin14) GPIO56 (Pin15) GPIO57 (Pin16) Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 69 Following is an example to enable configuration and to disable configuration by using debug. -o 4e 87 -o 4e 87 (enable configuration) -o 4e aa (disable configuration) 5.1.1.3 Relative Registers To program the F81866A configuration registers, see the following configuration procedures. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 70 Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 71 Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 72 // Assume read (bit 0~7) to Value is FFh , thus GP30 ~37 are all high. // Assume read (bit 0~7) to Value is 00h , thus GP30 ~37 are all low. // Read Value range: 00h~FFh <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 73 // Select configuration register A1h WriteByte(DataPort, Value) // Set bit 0~7=(0/1) to output GP 50~57 as Low or High // Write Value Range: 0x00 ~0xFF <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 74 // Select configuration register 60h (High Byte address) WriteByte(DataPort, 0x0A) WriteByte(AddrPort, 0x61) // Select configuration register 61h (Low Byte address) WriteByte(DataPort, 0x00) <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) default GPIO Port base address is 0xA00 Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 75 +9) address +5) (0xA09) (0xA05) = DI7 = DO7 (Base (Base address +9) address +5) (0xA09) (0xA05) = DI8 = DO8 (Base (Base address +9) address +5) (0xA09) (0xA05) Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 76 5.1.1.7 DIO I/O Port Address (Default Address 0xA00) Pin Definition Data Bits DIO Type Digital Input I/O Port Address 0xA09 Pin Definition Data Bits DIO Type Digital Output I/O Port Address 0xA05 Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 77: Dio Hardware Specification

    DO Signal have to pull up resistor to XCOM+ for external device, the ‐ resistance will affect the pull up current Signal High Level: Pull up resistor to XCOM+ ‐ Signal Low Level: = XCOM- ‐ Sink Current: 1A (Max) ‐ Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 78: Dio Connector Definition

    Digital Output Digital Input/ Output Connector Connector Type: Terminal Block 2X10 20-pin, 3.5mm pitch Location Definition Location Definition DC INPUT DC INPUT (XCOM+) (XCOM+) Digital Input Digital Output (XCOM-) (XCOM-) Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 79 Reference Input Circuit Reference Output Circuit Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 80: Chapter 6 Optional Modules & Accessories

    Chapter 6 Optional Modules & Accessories Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 81: Optional Module Pin Definition & Settings

    Connector Type: M12 A-coded 8pin connector Definition Definition 2_LAN1_0+ 2_LAN1_0- 2_LAN1_2+ 2_LAN1_1+ 2_LAN1_2- 2_LAN1_1- 2_LAN1_3+ 2_LAN1_3- 6.1.2 PB-310-LAN-XM12 LAN-XM12 Module Pin Definitions Connector Type: M12 X-coded 8pin connector Pin Definition Definition Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 82: Pb-310-10Glan

    Link LED Status Definition Steady Green 10 Gbps Network Link Steady Orange 1Gbps Network Link 100Mbps Network Link Act LED Status Definition Blinking Green Data Activity Steady Green No Activity Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 83: Pb-310-Com

    MODE3 on CMI-COM05 Module：COM3 Power Select Location Function DIP1 DIP2 0V(RI) ON (Default) ON (Default) MODE3 COM3 MODE4 on CMI-COM05 Module：COM4 Power Select Location Function DIP3 DIP4 0V(RI) ON (Default) ON (Default) MODE4 COM4 Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 84: Cfm-Ign

    Default setting of Pin1 to Pin4 is OFF/ OFF/ OFF/ OFF. 24V_12V_1：IGN Module Voltage Mode Setting Switch 12V/ 24V Car Battery Switch Switch Definition Left 12V Car Battery Input Right 24V Car Battery Input (Default) Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 85: Installing High Speed Cmi Module

    2. Locate the BTB_FH1 connector of the CMI module on the top side of system. 3. Insert the CMI module vertically until it’s connected firmly and fasten 2 screws to fix it. Spectra GmbH & Co. KG User Manual sales@spectra.de...

  • Page 86: Pb-310-Lan-M12-Set

    4. Attach the I/O bracket on to the system, and fasten the two screws to fix it. 6.2.2 PB-310-LAN-M12-Set 1. Loosen the 2 screws and remove the front bezel. 2. Locate the BTB_FH1 connector of the CMI module on the top side of system. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 87 4. Insert the CMI module vertically until it’s connected firmly and fasten 2 screws to fix it. 5. Attach the I/O bracket on to the system, and fasten the two screws to fix it. Spectra GmbH & Co. KG User Manual sales@spectra.de...

  • Page 88: Pb-310-Lan-Xm12-Set

    6. Fasten the four hex rings to fix the cover plate. 6.2.3 PB-310-LAN-XM12-Set Hex washers M12 I/O bracket Hex rings Rubber rings Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 89 Penetrate hex rings through the M12 I/O bracket holes, and fix them with hex washers. 2. Loosen the 2 screws and remove the front bezel. 3. Locate the BTB_FH1 connector of the CMI module on the top side of system. Spectra GmbH & Co. KG User Manual sales@spectra.de...
  • Page 90 2 screws to fix it. 5. Attach the assembled M12 I/O bracket on to the system, and fasten the hex nuts to fix it. 6. Put on the rubber rings to the four M12 LAN ports. Spectra GmbH & Co. KG User Manual sales@spectra.de...

  • Page 91: Pb-310-10Glan-Set

    Mode Selection] setting from default mode [4x1] to mode [1x4]. 1. Loosen the 2 screws and remove the front bezel. 2. Locate the BTB_FH1 connector of the CMI module on the top side of system. Spectra GmbH & Co. KG User Manual sales@spectra.de...
  • Page 92 4. Put on the heatsink and turn over the module. Fasten the 3 screws (M3X5L) to fix the heatsink. Insert the CMI module vertically into the female connector on system’s mainboard until it’s connected firmly and fasten the 2 screws (M3X12L) to fix it. Spectra GmbH & Co. KG User Manual sales@spectra.de...
  • Page 93 Before assembling the system’s chassis cover, please make sure the transparent protective film on the Thermal Pad has been removed! 7. Attach the I/O bracket on to the system, and fasten the two screws to fix it. Spectra GmbH & Co. KG User Manual sales@spectra.de...

  • Page 94: Installing Low Speed Cmi Module

    2. Locate the BTB_FH2 connector of the CMI module on the top side of system. 3. Insert the CMI module vertically until it’s connected firmly and fasten the screw to fix it. Spectra GmbH & Co. KG User Manual sales@spectra.de...

  • Page 95: Pb-310-Com-Set

    After installing CMI-COM module, users need to enter BIOS to check the items for CMI-COM module, which are “Serial Port 3 Configuration” and “Serial Port 4 Configuration”. Please find Chapter 4.3.5 for the detail setup regulations. Spectra GmbH & Co. KG User Manual sales@spectra.de...
  • Page 96 2. Locate the BTB_FH2 connector of the CMI module on the top side of system. 3. Insert the CMI module vertically until it’s connected firmly and fasten the screw to fix it. Spectra GmbH & Co. KG User Manual sales@spectra.de...
  • Page 97 4. Attach the I/O bracket on to the system, and fasten the two screws to fix it. 5. Fasten the 4 D-Sub jack screws to fix the module. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 98: Installing Cfm Module

    2. Insert the LAN module vertically to the female connector on system’s mainboard until it is connected firmly, and fasten the two copper pillars. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 99 5. Paste two thermal pads for CFM-PoE onto the heatsink carefully. Before putting on the thermal block (in the next step), please make sure the protective films on the Thermal Pads have been removed! Spectra GmbH & Co. KG User Manual sales@spectra.de...
  • Page 100 The yellow surface is part of the thermal pad. Do not tear it off as it would affect the thermal conductivity. Once the steps are finished, after system power on, PoE LED (on PB-310-LAN, PB-310-LAN-M12, or PB-310-LAN-XM12 module) will light blue as shown below. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 101: Cfm-Ign Module

    Insert the connector of IGN module to the female connector on system motherboard. (Make sure all the pins of IGN module’s connector are firmly connected.) Fasten the two screws to secure the power ignition board. Spectra GmbH & Co. KG User Manual sales@spectra.de...

  • Page 102: Installing Mec Module

    When the mPCIe card is installed onto the socket MINIPCIE1, then the USB board can be installed at bracket 1 or 2. When the mPCIe card is installed onto the socket MINIPCIE2, then the USB board can only be installed at bracket 1. Spectra GmbH & Co. KG User Manual sales@spectra.de...
  • Page 103 4. Tilt the Mini PCIe card at a 45-degree angle and insert it to the socket until the golden finger connector of the card seated firmly. 45° 5. Press the card down and secure it with 2 screws. 6. Connect the attached wire to the USB board. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 104 7. Connect the other end of the wire to the Mini PCIe card as indicated. 8. Attach the USB board onto the back side of the cover plate, and then fasten the two screws to secure the module. Spectra GmbH & Co. KG User Manual sales@spectra.de...

  • Page 105: Pb-310-Mec-Lan-Set

    When the mPCIe card is installed onto the socket MINIPCIE1, then the LAN board can be installed at bracket 1 or 2. When the mPCIe card is installed onto the socket MINIPCIE2, then the LAN board can only be installed at bracket 1. Spectra GmbH & Co. KG User Manual sales@spectra.de...
  • Page 106 3. Tilt the Mini PCIe card at a 45-degree angle and insert it to the socket until the golden finger connector of the card seated firmly. 45° 4. Press the card down and secure it with 2 screws. 5. Connect the attached wires to the LAN board. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 107 6. Connect the wires to the Mini PCIe card as indicated. 7. Attach the LAN board onto the back side of the cover plate, and then fasten the two screws to secure the module. Spectra GmbH & Co. KG User Manual sales@spectra.de...

  • Page 108: Pb-310-Mec-Com-Set

    2. Attach the MEC-COM bracket, and fasten the 2 screws to fix it as indicated. 3. Locate the Mini PCIe socket(s) on the bottom side of the system. MINIPCIE MINIPCIE Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 109 4. Tilt the Mini PCIe card at a 45-degree angle and insert it to the socket until the golden finger connector of the card seated firmly. 45° 5. Press the card down and secure it with 2 screws. 6. Remove the hex screws from the module. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 110 7. Connect the wire to the Mini PCIe card as indicated. 8. Penetrate the COM ports through the bracket from the back side. 9. Fasten the hex screws back. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 111: Installing External Fan

    1. Prepare an external fan. Loosen the 2 screws halfway on mounting frame before attempting to install it. 2. Slide the FAN into the middle groove of chassis as illustrated. Tighten the 2 screws to fix it onto chassis. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 112 3. Move the fan to the center of chassis. Tighten the 2 screws marked on photo to secure it. 4. Connect the FAN cable to external fan power connector at rear panel. Spectra GmbH & Co. KG User Manual sales@spectra.de...

  • Page 113: Installing Din-Rail Mount Kit

    6.7 Installing DIN-Rail Mount Kit 6.7.1 DINRAIL 1. The mounting holes are at the bottom of system. Fasten the 2 screws to fix the DIN-Rail mount bracket with system together. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...

  • Page 114: Installing Side Mount Kit

    6.8 Installing Side Mount Kit 6.8.1 SIDE 1. The mounting holes are at the bottom of system. Fasten the 4 screws to fix the side mount bracket with system together. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 115 2. Fasten the screws through the bracket mounting hole to mount system on the wall. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 310...
  • Page 116 Spectra GmbH & Co. KG Spectra GmbH & Co. KG Spectra (Schweiz) AG Mahdenstr. 3 Gewerbepark Ost 1 Flugplatzstr. 5 72768 Reutlingen 4621 Sipbachzell (Wels) 8404 Winterthur Germany Austria Switzerland Phone +49 (0) 7121 1432-10 Phone +43 (0) 7240 20190...
