O N L I N E H E L P
LMS400
LASER MEASUREMENT SENSORS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LMS400 and is the answer not in the manual?

Questions and answers

Related Manuals for SICK LMS400

Summary of Contents for SICK LMS400

  • Page 1 O N L I N E H E L P LMS400 LASER MEASUREMENT SENSORS...
  • Page 2 Windows 98, NT 4.0, 2000, XP, 7, 8, 10 and Internet Explorer are registered trademarks of Microsoft Corporation in the USA and other countries. 8011984/YSZ3/2016-02-04 © SICK AG · Germany · All rights reserved · Subject to change without notice...

  • Page 3: Table Of Contents

    Display of the Level Control application ..............33 Service ........................36 Version information ....................36 Operating data ......................36 System status ......................36 Glossary ......................... 37 Index ........................39 8011984/YSZ3/2016-02-04 © SICK AG · Germany · All rights reserved · Subject to change without notice...
  • Page 4 Fig. 6: Errors in the entry of the scan area ..............15 Fig. 7: Scan view ........................33 Fig. 8: Display of the Level Control results ..............34 8011984/YSZ3/2016-02-04 © SICK AG · Germany · All rights reserved · Subject to change without notice...

  • Page 5: About This Document

    Depth of information This document contains information on the configuration, diagnostics and troubleshooting on the LMS400 laser measurement sensor with the aid of the SOPAS ET configuration software. Planning and using measurement sensors such as the LMS400 also require specific technical skills which are not detailed in this documentation.

  • Page 6: For Your Safety

    The tests must be carried out by specialist personnel or specially qualified and authorised personnel and must be recorded and documented to ensure that the tests can be reconstructed and retraced at any time. 8011984/YSZ3/2016-02-04 © SICK AG · Germany · All rights reserved · Subject to change without notice...

  • Page 7: Configuration

     From the LMS400-XX00 menu, choose the command P ARAMETER AVE PERMANENT In this way the parameters are saved in the EEPROM in the LMS400 and will also be available after the device is switched off and on again. Preparing the configuration To configure the LMS400 laser measurement sensor, you need: ...

  • Page 8: Application

    Configuration Chapter 3 Online help LMS400 laser measurement sensor  Connect the PC/notebook with the aux interface of the LMS400. The connection of the PC is described in chapter “Electrical installation” in the LMS400 operating instructions.  Install the SOPAS ET configuration software.

  • Page 9: Position

    (see 3.2 on page On this device page you can enter the coordinates and angle of the LMS400 over the conveyor system and in this way define the zero point for the system. You can also define the relevant working area as the measurement area.

  • Page 10: Fig. 1: Lms Coordinates Above A Conveyor System

    COORDINATE COORDINATE COORDINATE 3.3.2 Angle Using the fields on the device page you can define the angle at which the LMS400 is mounted in relation to the conveyor system. Alpha  Enter 90° for the A angle. LPHA Beta ...

  • Page 11: Fig. 2: Gamma Angle

     The bottom border can also have a negative value, e.g. to include the conveyor system in the evaluation. 8011984/YSZ3/2016-02-04 © SICK AG · Germany · All rights reserved · Subject to change without notice...

  • Page 12: Basic Parameters

    EASUREMENT AREA fields. Basic parameters To be able to perform measurements with the LMS400, the basic parameters must be configured. For this purpose configure the size of the scanning area, the angular resolution and the scanning frequency in the scan settings.

  • Page 13: Fig. 4: Measured Value Quality As A Function Of Scan Frequency And Angular Resolution

     Choose the configuration that provides the highest measured value quality. Once you have completed the wizard the new parameters will be displayed in the C URRENT area. DEVICE PARAMETER 8011984/YSZ3/2016-02-04 © SICK AG · Germany · All rights reserved · Subject to change without notice...

  • Page 14: Fig. 5: Scanning Area Of The Lms400

    22), master and slave must be configured to the same scanning frequency and angular resolution. 3.4.2 Scan settings Scanning area The scanning area of the LMS400 covers an angle of maximum 70°, the minimum starting angle is 55° (see Fig. 5). Using the S and A...

  • Page 15: Advanced Parameters

    D field. EVICE NAME  Press the Return key. If the PC is connected to the LMS400 and the device is switched online, the device name is displayed in the project tree. Advanced parameters Note The advanced parameters are only available in the “Authorised client” user level.

  • Page 16: Filter

    (e.g. if the previous/next measured point was too dark or outside the measuring range of 3 metres). With the edge filter enabled, the LMS400 also sets a distance value to 0 at each edge. On this subject please read the section “Edge filter”...
  • Page 17 A ATHEMATICAL CTIVATE MEAN FILTER  In the N field enter a value of at least 2 and maximum 100. UMBER OF AVERAGED SCANS 8011984/YSZ3/2016-02-04 © SICK AG · Germany · All rights reserved · Subject to change without notice...

  • Page 18: Digital Inputs/Trigger

    You can define the sources for the triggering and if necessary the logic and debounce for the digital inputs. You can also define whether the laser in the LMS400 is switched on by a trigger or remains switched on continuously.
  • Page 19 3.7.3 Digital inputs The digital inputs 1 and 3 (IN1 and IN3) are used for triggering the LMS400, for example using external switches or sensors. To bridge bounce times on external switches, you can configure an input delay for the inputs. For both inputs you can also select whether they are to be active high or active low.
  • Page 20 LMS400 laser measurement sensor 3.7.4 Gate The LMS400 provides several trigger sources for gate control. These can start or stop the measurement immediately or initiate a delayed start and/or stop of the measurement. On this subject please read section “Control of the measurement process using a gate”...
  • Page 21 Note The LMS400 can count a maximum of 30000 encoder pulses from the time the trigger is activated until the lasers are switched off. With the encoder resolution of 0.2 mm/incr. of the recommended encoder this results in 30000 × 0.2 mm = 6000 mm.

  • Page 22: Encoder And Synchronization

    Phase On the use of two LMS400 in a master/slave system it may occur that one LMS400 received the beams from the other LMS400 and is affected by the beams. 8011984/YSZ3/2016-02-04...

  • Page 23: Interfaces

    HASE 3.8.2 Increment configuration The LMS400 can use the pulses from an encoder to determine the position or velocity. As an alternative, it is also possible to enter a constant velocity that can be used for making the position calculations.
  • Page 24  : 255.255.255.0 UBNET MASK Recommendation To check the availability of the LMS400, at the command prompt on the PC enter ping IP address, e.g. ping 192.168.0.1. How to configure the Ethernet interface: 8011984/YSZ3/2016-02-04 © SICK AG · Germany · All rights reserved · Subject to change without notice...
  • Page 25 Online help Chapter 3 LMS400 Note Changes to the Ethernet interface parameters will only be effective after the LMS400 is re- started. The CoLa protocol cannot be changed using the Ethernet interface.  Open in the P , LMS400-XX00, P...

  • Page 26: Level Control

    UMBER necessary values in the Z-L , Z-H and Y-Q fields. EVEL UALITY  Select the mode for the evaluation in the C field. 8011984/YSZ3/2016-02-04 © SICK AG · Germany · All rights reserved · Subject to change without notice...

  • Page 27: Column Length

    The gate can be defined either using an external trigger (see 3.7.4 on page 20) or using an internal gate (see 3.7.7 on page 22). 8011984/YSZ3/2016-02-04 © SICK AG · Germany · All rights reserved · Subject to change without notice...
  • Page 28  If you have selected U , enter in the O field the value for the SER DEFINED UTPUT ALUE column if a column is invalid. 8011984/YSZ3/2016-02-04 © SICK AG · Germany · All rights reserved · Subject to change without notice...

  • Page 29: Evaluation Result

    All columns switch the output if the switching point in all columns is exceeded.  All under switching point All columns switch the output if the switching point in all columns is not reached. 8011984/YSZ3/2016-02-04 © SICK AG · Germany · All rights reserved · Subject to change without notice...
  • Page 30 ELAY 4.3.2 Analog output You can allocate the analog output of the LMS400 to a single column or to all columns. You have three options for linking the output with the column results:  Inactive The output state remains unchanged.

  • Page 31: Output Message

    “Message reference” in the chapter “Level Control” of the LMS400 operating instructions. You can define which message is to be output by the LMS400 if the messages are polled by a host. You can choose between two messages:  OLUMN VALUES Outputs the values measured in the columns in detail.

  • Page 32: Monitor

    Chapter 5 Online help LMS400 laser measurement sensor Monitor In the SOPAS ET monitor the measurement results from the LMS400 are displayed in various forms. Use these displays to observe the measurement during operation or during testing. Scan view Use the graphic scan view in SOPAS ET to verify the measured values generated and to verify the measurement area online.

  • Page 33: Display Of The Level Control Application

    EVEL ONTROL  In the A area, click the S button. PPLICATION TART The column values can now be displayed in the V area. 8011984/YSZ3/2016-02-04 © SICK AG · Germany · All rights reserved · Subject to change without notice...

  • Page 34: Fig. 8: Display Of The Level Control Results

    Display of the Level Control results You can change the size of the diagram using the buttons above the diagram. Display You can switch between “pure” scan data from the LMS400 and the column results from the Level Control application. ...
  • Page 35 TART  Click in the V area the button with the green triangle. Depending on your selection, either “pure” scan data from the LMS400 or the column results from the application Level Control are displayed on the diagram. 8011984/YSZ3/2016-02-04 © SICK AG · Germany · All rights reserved · Subject to change without notice...

  • Page 36: Service

    YSTEM STATUS In the S area you will find “Information”, “Warning”, “Error” and “Serious YSTEM STATUS error” displayed in the form of a table. 8011984/YSZ3/2016-02-04 © SICK AG · Germany · All rights reserved · Subject to change without notice...

  • Page 37: Glossary

    A small RIS value signifies a low reflectivity (as a rule a dark object). Only distance values with RIS values  5 (= 10%) are inside the specified range of the LMS400. With RIS values < 5 the reliability of the measured result is low.
  • Page 38 Online help that supports the usage of the SOPAS ET configuration software. The functions of the parameters for the LMS400 are explained in the help and the related value ranges are given. Can be used with an HTML browser, e.g. Internet Explorer and can be opened from SOPAS ET setup.
