Labels Tab

Creates a title, subtitle, and a trace name for the displayed trace.
The title will be in larger letters and centered above the graph. The subtitle will
be smaller.
Edit a trace name by typing in the list of traces on this tab. The trace and date
will be located above the graph and on the left.
Note: If a specific trace name is not created, the PC tool will
create one automatically.
Other options are to display or hide the title, subtitle, trace name, and trace
date on the graph.
Figure 65
Example, Labels Tab

GPS

If a GPS sensor is attached to the SignalHawk, it will display a location and GPS
time reading at the bottom of the trace.
Note: This section does not apply to PC and Rack Mount
SignalHawks.
Figure 66
GPS Reading
GPS
Location
PC Tool
GPS
Time
76
