SignalHawk™ PC and Rack Mount Models
Mark & Limit Menu
Figure 30
Example, Mark & Limit Menu
Select Marker
Changes the active marker. There are six markers to choose from
(measurements that use some of the markers for data display have less
selectable markers). Pressing the soft key will cycle through each of the six
markers.
Marker On / Off
Turns a Marker on and off.
Marker to Max Peak
Moves the active marker to the highest point on the trace.
Markers to Peak/Valley
Figure 31
Markers to Peak/Valley
41
