PART LIST/EXPLODED DRAWING

Key No. Qty. Description
1 1 Upright
2 1 Leg Lever
3 1 Base
4 1 Platform
5 1 Handle
6 1 Resistance Cord
7 1 Adjustment Bracket
8 1 Pad
9 1 Pad Tube
10 1 Adjustment Pin
11 1 Lock Pin
12 2 Upright Bushing
13 1 Push Nut
14 4 M3 x 15mm Screw
15 1 Leg Lever Cover
16 1 Upright Cover
17 1 Pad Tube Cap
18 1 Leg Lever Cap
19 1 M8 x 15mm Screw
20 6 M4 x 15mm Screw
15
27
9
18
8
17
12
26
14
14
6
2
29
23
19
20
22
21
10
7
Key No. Qty.
21 1
22 2
23 1
24 4
25 2
26 1
27 1
28 8
29 1
30 1
31 1
* –
Note: Specifications are subject to change without
notice. For information about ordering replacement
parts, see the back cover of this manual. *These parts
are not illustrated.
14
16
13
12
20
11
1
30
31
28
24
28
25
28
7
Model No. PFBM11.0 R1211B
Description
Pulley Plate
Pulley
Upright Knob
Base Foot
Platform Foot
Upright Spacer
M8 x 105mm Bolt
M4 x 10mm Screw
M8 Washer
M8 Locknut
M8 x 8mm Screw
User's Manual
